MSO8000HD Options

MSO8000HD bandwidth upgrades, serial bus trigger and decode options, power analysis, jitter and eye-diagram analysis, USB 2.0 and PCIe 2.0 compliance packages, MATLAB integration, and the 32-channel logic analyzer module. Twenty-five options cover automotive, aerospace, audio, and high-speed serial bus protocols including CAN-FD, FlexRay, MIL-STD-1553, ARINC 429, 8b/10b, NRZ, and PSI5.

View

  • MSO8000HD-8B10B8b/10b Signal Analysis Option

    • 8b/10b Decoding: Decodes K-characters, data symbols, and running disparity.
    • Triggering: Trigger on specific symbols, control characters, or disparity errors.
    • Error Detection: Identifies encoding violations and disparity errors.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-AEROAerospace Serial Bus Trigger Package Option

    • MIL-STD-1553 Decode: Trigger and decode command words, status words, data words, RT addresses, errors.
    • ARINC 429 Decode: Trigger and decode 32-bit words with label, SDI, data, SSM, parity.
    • Combined License: Both protocols in a single key — no separate purchases.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-AUDIOAudio Serial Bus Option

    • Multi-Format Support: Decodes I2S, LJ, RJ, and TDM. Configurable word size (16/24/32-bit) and channel count.
    • Sample-Level Triggering: Trigger on specific audio sample values or ranges — capture clipping, silence, or test tones.
    • Real-Time Decoding: Decoded samples display aligned with BCLK, LRCLK/WS, and data for timing verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-AWGArbitrary Waveform Generator Option

    • Built-In AWG: Independent output channels with sine, square, ramp, pulse, noise, DC, and arbitrary waveforms. No external generator needed.
    • Bode Plot Analysis: Automated frequency response — define start/stop frequency and stimulus amplitude, get gain and phase plots. Essential for filter, amplifier, and loop stability verification.
    • Stimulus-Response: Generate and capture on the same instrument. No sync issues or ground loops.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $699.00
    Learn More

  • MSO8000HD-BNDProtocol Analysis and Jitter Suite

    • What's Included: 11 protocols with full trigger, decode, and search: CAN-FD — $999 individually FlexRay — $999 individually SENT (SAE J2716) — $999 individually Audio Serial Bus (I2S, LJ, RJ, TDM) — $999 individually Aerospace Bus (MIL-STD-1553 + ARINC 429) — $999 individually JITTER — $2,999 individually PSI5 (Peripheral Sensor Interface 5) — $999 individually Manchester Encoding — $999 individually I3C (MIPI I3C) — $999 individually SMBus — $999 individually SPMI — $999 individually
    • Save $7,590 (58% Off): Bundle pricing vs. purchasing individually.
    • Single License Key: One key unlocks all protocols. No managing separate licenses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $5,399.00
    Learn More

  • MSO8000HD-CANFDAutomotive CAN-FD Serial Bus Option

    • Protocol-Aware Triggering: Trigger on CAN-FD conditions — frame ID, data, error frames, or bit rate switch events.
    • Real-Time Frame Decoding: Decoded CAN-FD frames (ID, DLC, data, CRC, ACK) display on the waveform for protocol-electrical correlation.
    • Deep Memory Search: Search captured records for specific message IDs, data patterns, or errors across the full memory.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-CTS100100MBASE-Tx Ethernet Compliance Test Option

    • IEEE 802.3 Compliance: Automated measurements per 100BASE-Tx physical layer specifications.
    • Template (Mask) Test: Pass/fail testing against the standard eye mask.
    • Signal Quality Metrics: Jitter, rise/fall time, amplitude, and symmetry measurements.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,999.00
    Learn More

  • MSO8000HD-CTSUSB20USB 2.0 Compliance Test Option

    • USB 2.0 Compliance: Automated measurements per USB 2.0 electrical specs for HS (480 Mbps) and FS (12 Mbps).
    • Eye Diagram: Pass/fail testing against USB 2.0 eye mask templates.
    • Signal Quality: Rise/fall time, amplitude, and impedance measurements.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,399.00
    Learn More

  • MSO8000HD-FILTERAdvanced Filter Designer Option

    • Custom Filter Design: Low-pass, high-pass, band-pass, band-stop with configurable cutoff and order.
    • Real-Time Filtering: Apply to live acquisitions alongside the unfiltered signal.
    • FIR and IIR: Choose linear phase (FIR) or sharper rolloff (IIR) topologies.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,299.00
    Learn More

  • MSO8000HD-FLEXAutomotive FlexRay Serial Bus Option

    • FlexRay Triggering: Trigger on frame ID, cycle count, payload data, indicator bits, null frames, or errors.
    • Real-Time Frame Decoding: Decoded frames display with ID, payload, header CRC, and cycle info alongside the analog signal.
    • Static/Dynamic Segment Visibility: Identifies static vs. dynamic segment frames for schedule table verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-I3CEmbedded I3C Option

    • I3C Triggering: Trigger on dynamic address assignment, in-band interrupts, CCCs, and private transfers.
    • Real-Time Decoding: Decoded I3C transactions — addresses, CCCs, payload, ACK/T-bit status.
    • I2C Backward Compatibility: Identifies and decodes legacy I2C devices sharing the bus.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-JITTERAdvanced Jitter Analysis and Eye Diagram Option

    • Jitter Decomposition: Separates RJ, DJ, PJ, DDJ, and DCD for root-cause analysis.
    • Eye Diagram: Statistical eye from serial data for signal quality — eye height, width, mask margin.
    • Bathtub Curve: BER vs. sampling position for link margin prediction.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,999.00
    Learn More

  • MSO8000HD-LA16-Channel Logic Analyzer Option

    • 16 Digital Channels: Parallel bus capture alongside analog channels.
    • Time-Aligned Display: Digital and analog share the same time base for comprehensive debugging.
    • Protocol Correlation: Digital bus activity alongside serial decodes and analog measurements.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $399.00
    Learn More

  • MSO8000HD-MANCHSerial Bus Manchester Option

    • Manchester Decode: Decodes Manchester and Differential Manchester data with bit values on the waveform.
    • Configurable Parameters: Set bit rate, idle polarity, and convention (IEEE 802.3 or G.E. Thomas).
    • Pattern Triggering: Trigger on specific data patterns in the encoded stream.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-MATMatlab Embedded Programming Option

    • On-Instrument MATLAB: Run scripts directly without PC data transfer overhead.
    • Instrument Data Access: Scripts access waveform data, measurements, and settings directly.
    • Custom Analysis: Proprietary algorithms, custom measurements, automated sequences.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,299.00
    Learn More

  • MSO8000HD-MD2GDouble the MSO8000HD Memory to 2Gpts

    • 2 Gpts Memory: Doubles standard 1 Gpt across all channels.
    • Longer Full-Speed Captures: Twice the duration at maximum sample rate.
    • Deep Protocol Search: Search longer captures for intermittent errors over extended periods.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $5,399.00
    Learn More

  • MSO8000HD-NET10BASE-T, 100BASE-TX Ethernet Bus Analysis Option

    • Ethernet Frame Decode: Trigger and decode Ethernet frames including preamble, MAC addresses, type/length, data, and FCS.
    • Error Detection: Identifies FCS errors, runt frames, and jabber conditions.
    • Triggering: Trigger on MAC addresses, frame types, or specific data patterns.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,999.00
    Learn More

  • MSO8000HD-NRZNRZ Signal Analysis Option

    • NRZ Decoding: Decode NRZ data streams with configurable bit rate and threshold.
    • Eye Diagram: Generate eye diagrams for NRZ signal quality assessment.
    • Pattern Triggering: Trigger on specific bit patterns in the NRZ stream.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-PCIe2PCIe Bus Trigger and Analysis Option

    • PCIe Protocol Decode: Trigger and decode PCIe Gen 1/2 transactions.
    • Link Training: Capture and decode LTSSM state transitions.
    • TLP/DLLP Decode: Transaction and data link layer packet decoding.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,999.00
    Learn More

  • MSO8000HD-PSI5Automotive PSI5 Serial Bus Option

    • PSI5 Decoding: Sensor data frames with sync pulses, data bits, status, and CRC.
    • Current-Modulated Support: Interprets data from current waveforms captured through a current probe.
    • Triggering: Trigger on sensor data values, errors, or sync patterns.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-PWRAdvanced power analysis for MSO8504HD

    • Switching Loss: Calculates energy per switching transition for MOSFETs, IGBTs. Essential for thermal design and efficiency.
    • Safe Operating Area: Plots V×I trajectories against device limits during transients, startup, and faults.
    • Ripple Analysis: Output ripple amplitude and frequency content. Identifies sources: switching frequency, ESR, load transients.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,999.00
    Learn More

  • MSO8000HD-SENTAutomotive SENT Serial Bus Option

    • SENT Triggering: Trigger on fast channel data, slow channel messages, or error conditions.
    • Fast and Slow Channel Decoding: Decodes fast channel (primary sensor data) and slow channel (config/diagnostics).
    • Nibble-Level Display: Individual nibble values and timing overlaid on the waveform for SAE J2716 verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-SMBUSEmbedded Serial Bus SMBus Option

    • SMBus Decoding: Quick Command, Send/Receive Byte, Read/Write Word, Block transfers, Process Call.
    • PEC Verification: Validates Packet Error Checking CRC — not available in standard I2C decode.
    • Host Notify and Alert: Decodes SMBus alert protocol and host notification events.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • MSO8000HD-SPMIPower Management Serial Option

    • SPMI Decoding: Command sequences, register read/write, master/slave transactions.
    • Triggering: Trigger on slave addresses, register addresses, data values, or command types.
    • Multi-Master Support: Identifies transactions from multiple bus masters.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

Resources

MSO8000HD Options Documents and Downloads

Datasheets, manuals, software

Extend your UNI-T MSO8000HD-Series Oscilloscope with these amazing options.
