MSO8000HD-BND Protocol Analysis & Jitter Suite

$5,399.00
Save {price}%

Description

Bundled upgrade package combining key options like advanced jitter/eye analysis and protocol analysis, providing a cost-effective expansion path.

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

UNI-T MSO8000HD Options Series

OVERVIEW

DOCUMENTATION

UNI-T MSO8000HD-BND | Protocol Analysis & Jitter Suite

Overview

The MSO8000HD-BND Protocol Analysis & Jitter Suite represents the most cost-effective upgrade package for engineers requiring comprehensive protocol analysis capabilities. This carefully curated bundle combines the Advanced Jitter Analysis and Eye Diagram option with a complete set of protocol analysis options into a single cost-effective solution that delivers professional-grade measurement capabilities at a significant discount compared to individual option costs.

Designed for engineers working with multi-protocol systems, this bundle eliminates the compromise between capability and budget. Whether you're developing next-generation embedded systems, validating high-speed communication interfaces, or troubleshooting complex mixed-signal designs, the BND suite provides the essential protocol tools needed for comprehensive system analysis across multiple communication standards.

MSO8804HD main unit
Comprehensive protocol suite for modern design challenges

Exceptional Value Proposition

Save $10,583 - that's 66% off individual option prices!

The MSO8000HD-BND bundle delivers comprehensive protocol analysis capabilities that would cost over $15,982 if purchased individually. This package transforms your oscilloscope into a complete protocol testing laboratory, supporting everything from automotive networks to high-speed digital interfaces at a fraction of the cost of individual options or dedicated protocol analyzers.

Zero recurring fees - save $10,000+ over the instrument's lifetime

Unlike competitors who charge annual subscription fees for protocol analysis capabilities, UNI-T offers permanent licenses with your one-time purchase. This perpetual licensing model can save you $10,000 or more in recurring costs over the typical 10-year lifecycle of your oscilloscope.

Key Benefits

  • Significant Cost Savings — Save $10,583 (66% off) versus individual option purchases.
  • Zero Recurring Fees — One-time purchase saves $10,000+ over instrument lifetime compared to subscription-based alternatives.
  • Complete Protocol Suite — 15 protocol decoders covering embedded, automotive, aerospace, and high-speed digital interfaces.
  • Professional-Grade Tools — Industry-leading jitter analysis and protocol decoding.
  • Cross-Domain Analysis — Correlate timing anomalies with protocol events for faster troubleshooting.
  • Simplified Procurement — Single purchase eliminates multiple ordering and activation processes.
  • Immediate Productivity — All features available instantly after activation.
  • Budget-Optimized — Essential capabilities for modern design challenges without unnecessary extras.
  • Perpetual License — Lifetime access with no renewals required.

UNI-T MSO8000HD-BND Included Capabilities

The Protocol Analysis & Jitter Suite includes two essential capability categories that address the most demanding measurement challenges in modern electronics design. Advanced Jitter Analysis provides hardware-accelerated eye diagram generation and comprehensive timing analysis essential for high-speed digital validation, while the comprehensive Protocol Analysis package covers 15 serial communication standards from embedded systems to aerospace applications.

The combined protocol and timing analysis approach enables engineers to correlate timing anomalies with specific protocol events, rapidly identifying root causes of system failures. This integrated solution ensures optimal performance across multiple communication domains while providing the convenience of unified licensing and support.

Advanced jitter analysis
Hardware-accelerated jitter analysis included in bundle

UNI-T MSO8000HD-BND Protocol Analysis Coverage

The protocol analysis component provides comprehensive coverage of modern communication standards across embedded, automotive, aerospace, and high-speed digital applications. The suite includes essential interfaces like SMBUS and SPMI, automotive protocols including CAN-FD, FlexRay, SENT, I3C, and PSI5, and high-speed protocols such as PCIe, USB, Ethernet, and specialized aerospace standards including MIL-STD-1553 and ARINC 429.

This extensive protocol coverage eliminates the need for multiple protocol analyzers and ensures compatibility with evolving communication standards. Real-time decoding capabilities provide immediate insight into system behavior, enabling rapid identification of communication errors, timing violations, and protocol compliance issues across complex multi-protocol systems.

Comprehensive protocol support
15 protocols covering major communication standards

Compatibility Information

Compatible Models: MSO8804HD, MSO8504HD (planned release)

Installation: Software license activation - no hardware modification required

Activation: Single license key activates all included options

Performance Impact: No reduction in bandwidth, sample rate, or other specifications

Complete Bundle Contents

Included Option Key Capabilities Individual Price Recurring Cost
MSO8000HD-JITTER Hardware-accelerated jitter analysis and eye diagrams $2,999 None
MSO8000HD-CANFD CAN-FD automotive bus analysis $999 None
MSO8000HD-FLEX FlexRay automotive network analysis $999 None
MSO8000HD-SENT SENT automotive sensor bus analysis $999 None
MSO8000HD-I3C MIPI I3C sensor interface analysis $999 None
MSO8000HD-PSI5 PSI5 peripheral sensor interface analysis $999 None
MSO8000HD-USB2 USB 2.0 protocol analysis $2,999 None
MSO8000HD-PCIe2 PCIe 1.0/2.0 analysis $2,999 None
MSO8000HD-NET Ethernet analysis (10BASE-T, 100BASE-TX) $2,999 None
MSO8000HD-NRZ NRZ signal analysis $999 None
MSO8000HD-MANCH Manchester encoding analysis $999 None
MSO8000HD-8B10B 8b/10b encoding analysis $999 None
MSO8000HD-SMBUS SMBus embedded analysis $999 None
MSO8000HD-SPMI SPMI power management analysis $999 None
MSO8000HD-AUDIO Audio protocols (I2S, LJ, RJ, TDM) $999 None
MSO8000HD-AERO Aerospace protocols (MIL-STD-1553, ARINC 429) $999 None
Bundle Total Value Complete protocol and jitter analysis suite $15,982 $0 over lifetime
Your Price with Bundle Save $10,583 (66% off) $5,399 $0 over lifetime

Value Comparison Analysis

Purchase Option Initial Cost Recurring Cost (10 years) Total 10-Year Cost
Individual Options Total $15,982 $0 $15,982
MSO8000HD-BND Bundle $5,399 $0 $5,399 (Save $10,583)
Competitor A Equivalent* $8,000 $1,200/year ($12,000) $20,000
Competitor B Equivalent* $10,000 $1,500/year ($15,000) $25,000

*Estimated costs for equivalent capabilities from leading competitors who utilize subscription-based licensing models for protocol analysis features.

Application Examples

Multi-Protocol Automotive System Development

The protocol suite enables comprehensive validation of next-generation automotive electronics systems combining CAN-FD, FlexRay, and sensor interfaces. Engineers can simultaneously analyze communication across multiple vehicle networks while ensuring signal integrity through jitter analysis, accelerating development cycles and reducing integration issues.

IoT Device Validation

Modern IoT devices often combine multiple communication interfaces. The MSO8000HD-BND provides the tools to validate wireless interfaces, power management communications, and sensor interfaces while ensuring proper timing relationships across all protocols, significantly simplifying validation testing.

Aerospace & Defense System Integration

MIL-STD-1553 and ARINC 429 analysis capabilities combined with advanced jitter tools enable complete validation of mission-critical communication systems where reliability is paramount. Advanced eye diagram measurements ensure signal integrity across challenging environments.

High-Speed Interface Debug

PCIe, USB and Ethernet interfaces often require both protocol analysis and signal integrity verification. The bundle's combined approach enables engineers to rapidly correlate protocol errors with signal integrity issues, dramatically reducing debug time for complex interface problems.

Complementary Options Available Separately

Additional Option Initial Price Recurring Cost Benefit When Added to BND
MSO8000HD-MD2G $5,399 None Extended memory capture for long protocol sequences
MSO8000HD-FILTER $1,299 None Advanced filtering for noise reduction and signal isolation
MSO8000HD-PWR $2,999 None Power analysis for voltage regulators and power supplies
MSO8000HD-AWG $699 None Signal generation for protocol stimulus and response testing

Installation & Activation

  • Software-only upgrade - no hardware modification required
  • Single license key activates all included options
  • Activation through instrument menu system
  • All capabilities available immediately after activation
  • Unified support and documentation
  • Compatible with all existing probes and accessories

Frequently Asked Questions

How much can I save with the BND bundle versus individual options?

The MSO8000HD-BND bundle saves you $10,583 (66% off) compared to purchasing the same capabilities individually. The bundle costs $5,399 versus $15,982 for individual options—an exceptional value for engineers working with multiple protocols and requiring jitter analysis.

How does UNI-T's licensing model compare to competitors?

UNI-T offers perpetual licenses with a one-time purchase, while many competitors have moved to subscription-based models requiring annual fees to maintain protocol analysis capabilities. For a typical 10-year instrument lifecycle, subscription fees can add $10,000-$15,000 in additional costs for comparable protocol analysis capabilities. The MSO8000HD-BND's perpetual license model means zero recurring costs for the entire life of your instrument.

Does the bundle include memory depth upgrades?

No, the MSO8000HD-BND focuses specifically on protocol analysis and jitter measurement capabilities. The memory depth upgrade (MSO8000HD-MD2G) is available separately and can be added to complement the protocol suite for applications requiring extended waveform capture.

Can I upgrade to the bundle if I already own some individual options?

Yes, UNI-T offers upgrade pricing for customers who already own individual options and want to upgrade to the complete bundle. Contact your UNI-T representative for specific upgrade pricing based on your currently owned options.

Is technical support included for all bundled options?

Yes, the bundle includes unified technical support for all included protocol analyzers and the jitter analysis feature under UNI-T's comprehensive support program, simplifying both learning and troubleshooting across all capabilities.

Warranty & Support

The MSO8000HD-BND bundle is covered under UNI-T's Exclusive 3+2 Warranty program when installed on a qualifying MSO8000HD instrument—3 years standard coverage plus an additional 2 years at no charge when you complete our free product registration.

Optimize Your Protocol Analysis Investment

The MSO8000HD-BND Protocol Analysis & Jitter Suite represents exceptional value for engineers working with multiple communication protocols. By combining essential protocol analysis features with advanced jitter measurement capabilities in a single cost-effective package, this bundle delivers the comprehensive analysis tools demanded by modern embedded and communication system designers.

With UNI-T's perpetual licensing model, you'll never face the recurring subscription fees common with other manufacturers. The one-time purchase price provides lifetime access to all included capabilities, saving your organization thousands in recurring costs and protecting your investment for the life of the instrument.

Ready to equip your oscilloscope with comprehensive protocol capabilities and eliminate recurring software fees? Order the MSO8000HD-BND Protocol Analysis & Jitter Suite or contact our sales team for detailed pricing and configuration options.
