MSO8000HD-CTSUSB20 USB 2.0 Compliance Test Option

$1,399.00
Save {price}%

Description

Provides automated USB 2.0 compliance and conformance testing to USB-IF standards, simplifying certification and debug of USB devices.

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

UNI-T MSO8000HD Options Series

OVERVIEW

DOCUMENTATION

UNI-T MSO8000HD-CTSUSB20 | USB 2.0 Compliance Testing Option

Overview

The MSO8000HD-CTSUSB20 option provides comprehensive automated compliance testing for USB 2.0 High-Speed interfaces according to USB-IF (USB Implementers Forum) specifications. This professional-grade test suite automates the complex measurement procedures required for USB 2.0 compliance validation, reducing test time by up to 85% while ensuring consistent, repeatable results that meet stringent USB-IF certification requirements.

Essential for USB product development, certification, and manufacturing validation, this option delivers automated test execution, detailed compliance reporting, and comprehensive margin analysis. Engineers can validate USB PHY implementations, ensure interoperability across the USB ecosystem, and generate the professional documentation required for USB-IF certification and customer qualification processes.

MSO8804HD main unit
Professional automated USB 2.0 compliance testing

USB-IF Certification Ready

Generate USB-IF compliant test reports automatically with comprehensive eye diagram analysis, signal quality measurements, and detailed compliance margin calculations. Reduce manual testing time by 85% while ensuring 100% consistent results for certification submissions.

Key Benefits

  • USB-IF Compliant Testing — Complete test suite meeting USB 2.0 High-Speed certification requirements.
  • 85% Time Reduction — Automated procedures eliminate lengthy manual eye diagram and signal quality testing.
  • Eye Diagram Automation — Automated eye diagram capture, analysis, and compliance mask verification.
  • Professional Certification Reports — USB-IF quality documentation with detailed measurements and analysis.
  • High-Speed Focus — Specialized for 480 Mbps USB 2.0 High-Speed interface validation.
  • Manufacturing Integration — Batch testing capability for production quality control and validation.

Complete Validation Solution

Pair this Compliance Test option with the MSO8000HD-BND Protocol Analysis & Jitter Suite for end-to-end interface validation. The Compliance Test option provides automated standards conformance testing, while the bundle delivers protocol decoding and detailed signal integrity analysis.

This combination creates a comprehensive validation platform that can both verify protocol operation and certify standards compliance for interfaces. Both feature perpetual licensing with zero recurring fees, potentially saving $10,000+ over the instrument's lifetime compared to competitors' subscription models.

UNI-T MSO8000HD-CTSUSB20 Comprehensive Test Coverage

USB 2.0 High-Speed compliance testing requires dozens of precision measurements covering signal quality, timing characteristics, eye diagram parameters, and electrical specifications. Manual execution of these tests demands extensive setup time, precise calibration procedures, and detailed statistical analysis—a process that can consume multiple days per device under test.

The MSO8000HD-CTSUSB20 option automates the complete USB-IF test suite, including sophisticated eye diagram analysis with automated mask testing, signal quality measurements, and comprehensive statistical analysis. This automation ensures consistent test execution while providing the detailed documentation and margin analysis required for successful USB-IF certification submissions.

Automated compliance testing
Automated USB-IF compliant test execution and reporting

UNI-T MSO8000HD-CTSUSB20 Advanced Eye Diagram Analysis

USB 2.0 High-Speed eye diagram testing represents one of the most critical and time-consuming aspects of compliance validation. Traditional manual approaches require extensive statistical data collection, precise trigger setup, and complex mask overlay analysis that can take hours per measurement point while being susceptible to operator variations and setup errors.

The CTSUSB20 option provides fully automated eye diagram capture and analysis with built-in USB-IF compliance masks, automated statistical measurement, and comprehensive jitter decomposition. The system automatically optimizes trigger conditions, collects statistically significant datasets, and performs detailed eye opening analysis with precise margin calculations—delivering professional-quality results in minutes rather than hours.

Advanced jitter and eye diagram analysis
Automated eye diagram analysis with USB compliance masks

Compatibility Information

Compatible Models: MSO8804HD, MSO8504HD (planned release)

Installation: Software license activation - no hardware modification required

Required Accessories: UT-USB20-SQ-HD USB 2.0 Test Fixture

Test Standards: USB 2.0 High-Speed (480 Mbps) per USB-IF specifications

USB 2.0 High-Speed Test Coverage

Test Category Specific Measurements Compliance Parameters
Eye Diagram Tests Eye height, eye width, mask testing USB-IF compliance masks, statistical analysis
Signal Quality Rise/fall times, overshoot, undershoot Edge transition specifications, signal integrity
Jitter Analysis Random jitter, deterministic jitter, total jitter Jitter budgets, timing margins
Voltage Levels High/low levels, differential voltage Logic level compliance, noise margins
Packet Testing SYNC, PID, data integrity Protocol compliance, error detection
Receiver Testing Sensitivity, jitter tolerance Receiver performance margins

Automated Test Features

Feature Capability Benefit
Guided Test Setup Visual connection diagrams and configuration wizard Eliminates setup errors and reduces configuration time
Automated Eye Capture Statistical eye diagram generation with mask testing Consistent, repeatable eye diagram measurements
Real-Time Analysis Live pass/fail status during test execution Immediate feedback on compliance status
USB-IF Reports Professional compliance reports with detailed analysis Certification-ready documentation
Margin Analysis Detailed compliance margins for all parameters Design optimization and reliability assessment
Batch Processing Sequential testing of multiple devices Production testing and quality control efficiency

USB Test Patterns and Scenarios

Test Pattern Purpose Measurements
High-Speed Test Packet Standard USB-IF defined test sequence Eye diagrams, signal quality, timing
Chirp Sequence High-Speed handshake validation Timing compliance, protocol validation
PRBS Patterns Pseudo-random bit sequence testing Jitter analysis, statistical measurements
Specific Data Patterns Worst-case signal integrity scenarios ISI analysis, crosstalk evaluation

Application Examples

USB Controller Development

Validate new USB controller designs during development to ensure High-Speed interface compliance before silicon tape-out. Automated testing enables rapid design iteration with comprehensive validation at each development milestone.

USB-IF Certification Preparation

Generate professional compliance documentation required for USB-IF certification submissions. Automated test reports provide the detailed technical analysis and statistical data demanded by certification laboratories.

Production Testing Integration

Implement automated USB compliance testing in manufacturing environments to ensure consistent product quality. Batch testing capabilities enable high-volume validation with standardized pass/fail criteria.

Interoperability Validation

Verify USB device compatibility across different host controllers and hubs using standardized test procedures. Automated testing eliminates measurement variations that could mask interoperability issues.

Required Test Fixture

Accessory Function Specifications
UT-USB20-SQ-HD USB Test Fixture Standardized USB 2.0 High-Speed test interface USB-IF compliant, precision impedance, signal conditioning

Related Options

Option Synergy with MSO8000HD-CTSUSB20
MSO8000HD-USB2 USB protocol analysis complements compliance testing
MSO8000HD-JITTER Advanced jitter analysis for detailed timing characterization
MSO8000HD-8B10B NRZI encoding analysis for USB signal integrity
MSO8000HD-MD2G Extended capture for long USB test sequences

Installation & Activation

  • Software-only upgrade - no hardware modification required
  • License key provided upon purchase
  • Activation through instrument menu system
  • UT-USB20-SQ-HD test fixture required (sold separately)
  • Immediate functionality after activation and fixture connection
  • Includes comprehensive USB-IF test procedures and documentation

Frequently Asked Questions

What test fixture is required for USB 2.0 compliance testing?

The UT-USB20-SQ-HD USB 2.0 Test Fixture is required for proper compliance testing. This precision fixture provides the standardized test interface specified by USB-IF and ensures accurate, repeatable High-Speed measurements.

Are the test reports acceptable for USB-IF certification?

Yes, the automated test reports meet USB-IF requirements for certification submissions. They include comprehensive eye diagram analysis, statistical measurements, and detailed compliance documentation required by certification laboratories.

How much time does automated USB testing save?

Automated USB compliance testing reduces total test time by approximately 85% compared to manual procedures. Complex eye diagram tests that might take 4-6 hours manually can be completed in 30-45 minutes with automation.

Does this option test both transmitter and receiver compliance?

Yes, the CTSUSB20 option includes comprehensive transmitter testing (signal quality, eye diagrams) and receiver testing (sensitivity, jitter tolerance) as specified in USB-IF compliance requirements.

Is this option included in the MSO8000HD-BND Protocol Analysis & Jitter Suite?

No, this option is not included in the MSO8000HD-BND Protocol Analysis & Jitter Suite. The bundle focuses specifically on protocol analysis capabilities (15 protocol decoders) and advanced jitter analysis. However, this option complements the bundle perfectly for engineers requiring both protocol analysis and Compliance Testing. Both can be purchased together to create a comprehensive solution, and like all UNI-T software options, they feature perpetual licensing with zero recurring fees.

Warranty & Support

The MSO8000HD-CTSUSB20 option is covered under UNI-T's Exclusive 3+2 Warranty program when installed on a qualifying MSO8000HD instrument—3 years standard coverage plus an additional 2 years at no charge when you complete our free product registration.

Accelerate Your USB Certification

The MSO8000HD-CTSUSB20 option transforms complex manual USB compliance testing into efficient automated validation that delivers USB-IF quality results. Whether supporting product development, preparing for certification, or implementing production testing, this option provides the automation and professional documentation needed for successful USB 2.0 High-Speed validation.

Ready to automate your USB 2.0 compliance testing? Order the MSO8000HD-CTSUSB20 for $1,399, plus the required UT-USB20-SQ-HD test fixture.
