MSO8000HD-CANFD Automotive CAN-FD Serial Bus Option

$999.00
Save {price}%

Description

Enables triggering and decoding of CAN-FD frames for automotive ECU and in-vehicle network validation.

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

UNI-T MSO8000HD Options Series

OVERVIEW

DOCUMENTATION

UNI-T MSO8000HD-CANFD | CAN-FD (CAN with Flexible Data Rate) Analysis Option

Overview

The MSO8000HD-CANFD option provides comprehensive analysis and decoding capabilities for CAN-FD (CAN with Flexible Data Rate), the next-generation automotive communication protocol that extends traditional CAN bus capabilities with higher data rates and increased payload capacity. Essential for modern automotive system development, this option enables real-time protocol decoding, error detection, and comprehensive validation of CAN-FD network behavior.

Critical for automotive ECU development, network integration, and system troubleshooting, the CANFD option delivers immediate insight into message content, timing relationships, and protocol compliance. Engineers can validate CAN-FD implementations, debug network issues, and ensure reliable communication in safety-critical automotive systems where protocol failures can have serious consequences.

MSO8804HD main unit
Professional CAN-FD protocol analysis for automotive development

Key Benefits

  • Next-Generation CAN Analysis — Complete support for CAN-FD protocol extensions and enhancements.
  • Variable Data Rate Decoding — Handles both arbitration phase and high-speed data phase timing.
  • Extended Payload Support — Analyzes up to 64-byte CAN-FD message payloads versus 8-byte classic CAN.
  • Real-Time Protocol Validation — Immediate identification of CAN-FD specific errors and violations.
  • Mixed Network Analysis — Supports networks with both classic CAN and CAN-FD nodes.
  • Automotive System Debug — Essential for modern vehicle network troubleshooting and integration.

UNI-T MSO8000HD-CANFD Advanced Protocol Analysis

CAN-FD represents a significant evolution of the Controller Area Network protocol, introducing variable bit rates and extended data lengths that enable higher bandwidth communication while maintaining backward compatibility with classic CAN nodes. The protocol's dual-phase operation—slow arbitration phase for network access and high-speed data phase for payload transmission—requires sophisticated analysis capabilities to validate proper implementation.

The MSO8000HD-CANFD option provides complete protocol analysis including arbitration phase decoding, data rate switching validation, extended payload interpretation, and CAN-FD specific error detection. Engineers can monitor bit rate switching behavior, validate CRC calculations, and identify timing violations that could cause network errors or reduce system reliability in automotive applications.

Protocol analysis capabilities
Real-time CAN-FD protocol decoding and validation

UNI-T MSO8000HD-CANFD Network Integration Validation

Modern automotive networks often combine classic CAN and CAN-FD nodes in mixed configurations where protocol compatibility and timing relationships are critical for system operation. CAN-FD nodes must seamlessly coexist with legacy CAN controllers while providing enhanced performance for applications requiring higher data throughput or extended message payloads.

The CANFD analysis option enables comprehensive validation of mixed-protocol networks, monitoring how CAN-FD nodes handle backward compatibility requirements and ensuring proper protocol fallback behavior. Engineers can validate network-wide timing relationships, monitor error propagation between different protocol versions, and ensure that CAN-FD enhancements don't introduce compatibility issues with existing automotive systems.

High-resolution signal analysis
Precise timing analysis for CAN-FD bit rate switching

Compatibility Information

Compatible Models: MSO8804HD, MSO8504HD (planned release)

Installation: Software license activation - no hardware modification required

Supported Protocols: CAN-FD (ISO 11898-1), Classic CAN compatibility

Signal Requirements: Differential or single-ended CAN signal access

Bundle Savings Opportunity

This option is included in the MSO8000HD-BND Protocol Analysis & Jitter Suite! Get this capability plus 15 other protocol analysis options and jitter analysis for just $5,399 - saving you $10,583 (66% off) compared to purchasing options individually.

The bundle features perpetual licensing with zero recurring fees, potentially saving $10,000+ over the instrument's lifetime compared to competitors' subscription models.

CAN-FD Technical Specifications

Parameter Specification
Supported Standard ISO 11898-1 CAN-FD, Classic CAN compatibility
Arbitration Phase Bit Rates 10 kbps to 1 Mbps (classic CAN rates)
Data Phase Bit Rates 500 kbps to 8 Mbps (CAN-FD enhanced rates)
Data Length Code (DLC) 0 to 15 (supports up to 64 bytes payload)
Frame Types CAN-FD data frames, remote frames, error frames
Identifier Support 11-bit standard, 29-bit extended identifiers
Signal Types CAN_H, CAN_L differential; single-ended monitoring
Error Detection CRC errors, bit stuffing violations, format errors

CAN vs CAN-FD Comparison

Feature Classic CAN CAN-FD
Maximum Data Length 8 bytes 64 bytes
Bit Rate Up to 1 Mbps Up to 8 Mbps (data phase)
Data Rate Switching Fixed bit rate Variable: slow arbitration, fast data
Error Detection 15-bit CRC 17/21-bit CRC (improved)
Network Compatibility CAN only Mixed CAN/CAN-FD networks
Throughput Limited by 8-byte payload 8x higher effective throughput

Application Examples

Electric Vehicle Powertrain Control

Validate CAN-FD communication between battery management systems, motor controllers, and charging systems where high-bandwidth data exchange is essential for optimal performance and safety. The extended payload capability enables transmission of detailed battery cell data, motor parameters, and thermal management information in single messages.

Advanced Driver Assistance Systems (ADAS)

Debug CAN-FD networks connecting cameras, radar sensors, and central processing units in ADAS applications where large sensor datasets must be transmitted with minimal latency. The higher data rates enable real-time sharing of processed vision and radar data between distributed processing nodes.

Infotainment and Connectivity Systems

Analyze CAN-FD communication in automotive head units and connectivity modules where software updates, multimedia content, and diagnostic data require high-bandwidth transmission. The extended message payloads reduce protocol overhead and improve system responsiveness.

Body Control and Comfort Systems

Troubleshoot mixed CAN/CAN-FD networks in body control applications where legacy comfort modules must coexist with new CAN-FD enabled systems. Validate backward compatibility and ensure proper network segmentation between different protocol versions.

Related Options

Option Synergy with MSO8000HD-CANFD
Standard CAN Analysis Complete classic CAN analysis for mixed networks
MSO8000HD-FLEX FlexRay analysis for high-end automotive applications
MSO8000HD-SENT SENT sensor protocol analysis for automotive sensors
MSO8000HD-MD2G Extended capture of long CAN-FD message sequences

Installation & Activation

  • Software-only upgrade - no hardware modification required
  • License key provided upon purchase
  • Activation through instrument menu system
  • Immediate functionality after activation
  • Integrates with existing trigger and measurement systems
  • Compatible with automotive probing and coupling solutions

Frequently Asked Questions

What's the main advantage of CAN-FD over classic CAN?

CAN-FD provides up to 8x higher effective throughput through variable bit rates (up to 8 Mbps in data phase) and extended payloads (up to 64 bytes vs 8 bytes). This enables more efficient data transfer while maintaining compatibility with existing CAN networks.

Can CAN-FD and classic CAN nodes coexist on the same network?

Yes, CAN-FD is designed for backward compatibility. CAN-FD nodes can communicate with classic CAN nodes on the same network, though they'll operate at classic CAN data rates when communicating with legacy nodes.

Does this option analyze both arbitration and data phases?

Yes, the MSO8000HD-CANFD option provides complete analysis of both the arbitration phase (slow, classic CAN compatible) and the data phase (high-speed CAN-FD) including bit rate switching validation and timing analysis.

Is CAN-FD analysis included in the bundle package?

Yes, CAN-FD analysis is included in the MSO8000HD-BND Protocol Analysis & Jitter Suite. The bundle provides 15 protocol analysis options plus advanced jitter analysis at a single price of $5,399 - saving 66% compared to purchasing options individually. As with all UNI-T software options, the bundle features a perpetual license with zero recurring fees, providing lifetime access without subscription costs that can save $10,000+ over the instrument's lifetime.

Warranty & Support

The MSO8000HD-CANFD option is covered under UNI-T's Exclusive 3+2 Warranty program when installed on a qualifying MSO8000HD instrument—3 years standard coverage plus an additional 2 years at no charge when you complete our free product registration.

Master Next-Generation Automotive Networks

The MSO8000HD-CANFD option provides the specialized analysis capabilities required for modern automotive systems adopting CAN-FD technology. Whether developing electric vehicle powertrains, advanced driver assistance systems, or next-generation infotainment platforms, this option delivers the insight needed to ensure reliable, high-performance automotive communication networks.

Ready to analyze your CAN-FD networks? Order the MSO8000HD-CANFD for $999, or get it included in the MSO8000HD-BND Complete Suite and save $15,291.
