MSO8000HD-8B10B 8b/10b Signal Analysis Option
Overview
The MSO8000HD-8B10B decodes 8b/10b encoded data streams used in PCIe Gen 1/2, SATA, Fibre Channel, and other high-speed serial interfaces. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- 8b/10b Decoding — Decodes K-characters, data symbols, and running disparity.
- Triggering — Trigger on specific symbols, control characters, or disparity errors.
- Error Detection — Identifies encoding violations and disparity errors.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- PCIe Debug — Verify link training sequences and decode TLP/DLLP packets.
- SATA Analysis — Decode SATA link layer traffic for storage interface debug.
Compatibility
This option is compatible with the MSO8000HD Series: MSO8804HD (8 GHz).
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
