MSO7000X-BND Complete Options Bundle (AERO, AUDIO, CANFD, FLEX, JITTER, PWR, SENT)

MSO7000X-BND – Complete Protocol Decode Bundle

🔓 Unlock the Full Suite of Serial Bus Protocols

The MSO7000X-BND unlock enables every available protocol decode option for the UNI-T MSO7000X Series oscilloscopes. With this bundle, you gain full access to advanced triggering and real-time decoding for automotive, embedded, aerospace, sensor, and audio buses—without having to purchase each protocol individually.

Ideal for labs, universities, and developers working across industries, this all-in-one license is the fastest, most cost-effective way to transform your MSO7000X into a fully equipped protocol analysis workstation.

📦 Included Unlock Options

Note: This bundle does not include power analysis (MSO7000X-PWR), waveform generation (MSO7000X-AWG), logic analyzer (MSO7000X-LA), or jitter/eye diagram (MSO7000X-JITTER).

🧠 Real-World Use Cases

✅ Multi-Bus Automotive System Debug

Simultaneously decode CAN FD, FlexRay, and SENT data on shared trigger events. Correlate powertrain signals across multiple ECUs in hybrid or electric vehicle designs.

✅ Mixed-Protocol Validation for Embedded Systems

Capture I²S audio streams while monitoring sensor data over SENT and control messages over CAN. Ideal for DSP applications, infotainment, and multi-domain systems.

✅ University Lab Standardization

Equip student stations with full protocol coverage. No need to track or juggle individual options—MSO7000X-BND ensures access to every supported protocol.

✅ Avionics Development with Full Visibility

Decode MIL-STD-1553 and ARINC 429 alongside UART/I²C/SPI/CAN for full aerospace subsystem insight.

🔧 Features & Capabilities

• Trigger and decode across 11+ serial bus types
• Side-by-side viewing of multiple protocol overlays
• Exportable event tables with timestamps and full field detail
• Long memory support (up to 1Gpts) for deep, time-correlated captures
• Fast search tools to isolate specific IDs, data, or error conditions
• Seamless integration with logic analyzer, math, and waveform views

🛠️ Ideal Applications

• Automotive ECU testing and sensor validation
• Aerospace communication development
• Embedded systems integration labs
• University multi-protocol curriculum labs
• R&D teams supporting multiple communication standards

🔗 Related Unlock Options

• ✅ MSO7000X-PWR → – Power analysis (not included in this bundle)
• ✅ MSO7000X-JITTER → – Jitter & Eye Diagram (sold separately)
• ✅ MSO7000X-AWG → – Arbitrary waveform generator (not part of BND)
• ✅ MSO7000X-LA → – 16-channel logic analyzer support

📋 Summary of Unlockable Features – MSO7000X Series

Standard protocols included: RS-232/UART, I²C, SPI, CAN, LIN
Optional unlocks:

• MSO7000X-BND – This page
• MSO7000X-AERO – MIL-STD-1553 & ARINC 429
• MSO7000X-AUDIO – I2S, LJ, RJ, TDM
• MSO7000X-CANFD – CAN FD
• MSO7000X-FLEX – FlexRay
• MSO7000X-SENT – SENT
• MSO7000X-PWR – Power analysis tools
• MSO7000X-JITTER – Jitter and eye diagram
• MSO7000X-AWG – Arbitrary waveform generator
• MSO7000X-LA – 16-channel logic analyzer
