UTS7026A-NB

26GHz Interceptor-Series Signal Analyzer; 20MHz RSA

Name: UTS7026A-NB 26GHz Interceptor-Series Signal Analyzer; 20MHz RSA
Brand: UNI-T
SKU: 181200100066X
Price: 28999.00 USD
Availability: OutOfStock

$28,999.00

Sale Contact Us For Lead Time

Backordered. Contact us for lead time.

REQUEST A QUOTE

Compare

UTS7026A-NB (26GHz) - Fixed 20MHz RTSA Optimized for 5G mmWave testing, satellite communications analysis, and automotive radar development teams. Ensures 100% Probability of Intercept with 20MHz real-time bandwidth for reliable detection of transient signals in mmWave applications.

View full details

Warranty

This instrument is backed by UNI-T's 3+2 Year Warranty — 3 years of standard coverage, plus 2 additional years free when you register your product. That's 5 years of total protection at no extra cost.

The warranty covers manufacturing defects and component failures under normal use conditions. UNI-T instruments are built for professional daily use, and our warranty reflects that commitment to long-term reliability.

Key Specifications

Frequency Range

2 Hz to 26.5 GHz

DANL

-167dBm/Hz · 49 values · Preamp Off / Preamp On

Preamp Off
100 kHz to 1 MHz · Typical	-140 dBm
1 MHz to 20 MHz	-145 dBm
1 MHz to 20 MHz · Typical	-151 dBm
20 MHz to 1.5 GHz	-147 dBm
20 MHz to 1.5 GHz · Typical	-153 dBm
1.5 GHz to 3 GHz	-146 dBm
1.5 GHz to 3 GHz · Typical	-151 dBm
3 GHz to 4.5 GHz	-146 dBm
3 GHz to 4.5 GHz · Typical	-152 dBm
4.5 GHz to 7.5 GHz	-140 dBm
4.5 GHz to 7.5 GHz · Typical	-145 dBm
7.5 GHz to 9.5 GHz	-143 dBm
7.5 GHz to 9.5 GHz · Typical	-149 dBm
9.5 GHz to 12.3 GHz	-138 dBm
9.5 GHz to 12.3 GHz · Typical	-146 dBm
12.3 GHz to 15.5 GHz	-142 dBm
12.3 GHz to 15.5 GHz · Typical	-147 dBm
15.5 GHz to 19.3 GHz	-140 dBm
15.5 GHz to 19.3 GHz · Typical	-145 dBm
19.3 GHz to 21 GHz	-140 dBm
19.3 GHz to 21 GHz · Typical	-148 dBm
21 GHz to 22.8 GHz	-138 dBm
21 GHz to 22.8 GHz · Typical	-145 dBm
22.8 GHz to 26.5 GHz	-138 dBm
22.8 GHz to 26.5 GHz · Typical	-145 dBm
Preamp On
1 MHz to 20 MHz	-160 dBm
1 MHz to 20 MHz · Typical	-166 dBm
20 MHz to 1.5 GHz	-162 dBm
20 MHz to 1.5 GHz · Typical	-167 dBm
1.5 GHz to 3 GHz	-160 dBm
1.5 GHz to 3 GHz · Typical	-165 dBm
3 GHz to 4.5 GHz	-160 dBm
3 GHz to 4.5 GHz · Typical	-165 dBm
4.5 GHz to 7.5 GHz	-153 dBm
4.5 GHz to 7.5 GHz · Typical	-159 dBm
7.5 GHz to 9.5 GHz	-156 dBm
7.5 GHz to 9.5 GHz · Typical	-160 dBm
9.5 GHz to 12.3 GHz	-153 dBm
9.5 GHz to 12.3 GHz · Typical	-161 dBm
12.3 GHz to 15.5 GHz	-155 dBm
12.3 GHz to 15.5 GHz · Typical	-162 dBm
15.5 GHz to 19.3 GHz	-153 dBm
15.5 GHz to 19.3 GHz · Typical	-158 dBm
19.3 GHz to 21 GHz	-153 dBm
19.3 GHz to 21 GHz · Typical	-158 dBm
21 GHz to 22.8 GHz	-150 dBm
21 GHz to 22.8 GHz · Typical	-155 dBm
22.8 GHz to 26.5 GHz	-152 dBm
22.8 GHz to 26.5 GHz · Typical	-159 dBm

RBW

1Hz-3MHz (10% Steps), 4MHz, 5MHz, 6MHz, 8MHz, 10MHz

Phase Noise

<-110dBc/Hz · 9 values · 5 groups

100 Hz
Nominal	-80 dBc/Hz
1 kHz
1 kHz	-102 dBc/Hz
Typical	-104 dBc/Hz
10 kHz
10 kHz	-108 dBc/Hz
Typical	-110 dBc/Hz
100 kHz
100 kHz	-108 dBc/Hz
Typical	-110 dBc/Hz
1 MHz
1 MHz	-122 dBc/Hz
Typical	-124 dBc/Hz

Tracking Generator

Not Available

Real-Time Analysis

20MHz

Realtime Bandwidth

20 MHz

RTSA Analysis Bandwidth

5 kHz to 20 MHz

IQ Analysis Bandwidth

10 Hz to 20 MHz

Max Sampling Rate

100 MSa/s

Instrument Type

Signal Analyzer

Features

Touch Screen

Full specifications (17)

Details

Amplitude flatness

Preamp Off
2 Hz to 9 kHz	±0.50 dB
2 Hz to 9 kHz · 95% (2 sigma)	±0.30 dB
9 kHz to 10 MHz	±0.50 dB
9 kHz to 10 MHz · 95% (2 sigma)	±0.40 dB
10 MHz to 3 GHz	±0.65 dB
10 MHz to 3 GHz · 95% (2 sigma)	±0.65 dB
3 GHz to 13.6 GHz	±1.30 dB
3 GHz to 13.6 GHz · 95% (2 sigma)	±0.80 dB
13.6 GHz to 19.3 GHz	±1.50 dB
13.6 GHz to 19.3 GHz · 95% (2 sigma)	±1.00 dB
19.3 GHz to 24.2 GHz	±1.80 dB
19.3 GHz to 24.2 GHz · 95% (2 sigma)	±1.30 dB
24.2 GHz to 26.5 GHz	±2.50 dB
24.2 GHz to 26.5 GHz · 95% (2 sigma)	±1.40 dB
26.5 GHz to 32 GHz	±2.60 dB
26.5 GHz to 32 GHz · 95% (2 sigma)	±2.00 dB
32 GHz to 40.0 GHz	±2.80 dB
32 GHz to 40.0 GHz · 95% (2 sigma)	±2.30 dB
Preamp On
100 kHz to 10 MHz	±0.60 dB
100 kHz to 10 MHz · 95% (2 sigma)	±0.50 dB
10 MHz to 3 GHz	±1.10 dB
10 MHz to 3 GHz · 95% (2 sigma)	±1.00 dB
3 GHz to 7.5 GHz	±1.40 dB
3 GHz to 7.5 GHz · 95% (2 sigma)	±1.20 dB
7.5 GHz to 13.6 GHz	±1.50 dB
7.5 GHz to 13.6 GHz · 95% (2 sigma)	±1.20 dB
13.6 GHz to 21 GHz	±1.60 dB
13.6 GHz to 21 GHz · 95% (2 sigma)	±1.20 dB
21 GHz to 24.2 GHz	±2.00 dB
21 GHz to 24.2 GHz · 95% (2 sigma)	±1.80 dB
24.2 GHz to 26.5 GHz	±2.80 dB
24.2 GHz to 26.5 GHz · 95% (2 sigma)	±2.40 dB
26.5 GHz to 32 GHz	±3.00 dB
26.5 GHz to 32 GHz · 95% (2 sigma)	±2.60 dB
32 GHz to 40.0 GHz	±3.20 dB
32 GHz to 40.0 GHz · 95% (2 sigma)	±2.80 dB

Sweep Points

100,001

Traces

6

Frequency Resolution

0.001Hz

Channels

1

Features

Input Attenuator Range

0 to 75 dB, 5 dB Steps

1 dB gain compression

Preamp Off
10 MHz to 7.5 GHz · Nominal	+6 dBm
7.5 GHz to 13.5 GHz · Nominal	+4 dBm
13.5 GHz to 26.5 GHz · Nominal	+2 dBm
26.5 GHz to 40 GHz · Nominal	-2 dBm
Preamp On
10 MHz to 7.5 GHz · Nominal	-15 dBm
7.5 GHz to 26.5 GHz · Nominal	-19 dBm
26.5 GHz to 40 GHz · Nominal	-32 dBm
