UPO7000L-SENT – Automotive Sensor Bus Decode Option (SENT)

πŸ”§ Unlock High-Precision Sensor Bus Debugging on Your UPO7000L Oscilloscope

The UPO7000L-SENT software unlock adds decoding and trigger capabilities for SENT (Single Edge Nibble Transmission) protocol to your UPO7000L Series oscilloscope. SENT is a unidirectional, point-to-point digital communication protocol commonly used in automotive environments to transmit high-resolution sensor data from components such as throttle position sensors, pressure sensors, and temperature monitors.

With this option, you can decode and analyze SENT messages at the bit levelβ€”including fast channel data, slow channel updates, status bits, CRC values, and more.


πŸ” What You Can Do with SENT Decode

Feature Description & Application
Trigger on SENT Frame Isolate specific sensor outputs based on sync, status, or data values. πŸ“Œ Used to identify failing sensors or unexpected value changes.
View Nibble-Level Timing Analyze the time between falling edges for each nibble. πŸ“Œ Essential for identifying timing drift or ECU decoding errors.
Decode Fast & Slow Channels Decode standard fast channel data and extended diagnostics over the slow channel. πŸ“Œ Used for full system validation and sensor feedback monitoring.
CRC and Status Monitoring Automatically validate checksum and flag corrupted frames. πŸ“Œ Critical for production testing and long-term field reliability.
Exportable Event Table Log all decoded SENT messages with timestamps. πŸ“Œ Used in debugging intermittent sensor faults or comparing against ECU logs.

🧠 Real-World Use Cases

βœ… Throttle Position & Pedal Sensors

Use SENT decoding to monitor analog-to-digital transmission from position sensors. Confirm that nibbles are transmitted with valid CRC and that status bits correctly indicate fault or drift conditions.

βœ… Pressure & Temperature Monitoring

Decode real-time feedback from manifold or coolant pressure sensors. Validate that the slow channel diagnostic data matches sensor calibration and health reporting.

βœ… Sensor Bus Debug in Harsh Environments

SENT is designed for use in electrically noisy, high-vibration environments. Combine decode analysis with analog waveform monitoring to uncover issues due to ground shifts, load dumps, or EMI.

βœ… ECU Integration and Trigger-Based Testing

Use the oscilloscope’s trigger system to capture precise sensor events and correlate them with CAN or FlexRay network activityβ€”ideal for gateway or domain controller validation.


πŸ”§ Technical Features

  • Trigger on sync pulse, nibble value, CRC, status flags, or frame length

  • Decode both fast and slow channel message formats

  • Visual overlay of decoded fields on waveform trace

  • Support for user-defined tick times and nibble mappings

  • Exportable decoded frame logs with time-correlated events

  • Long capture support for full system testing or startup event analysis


πŸ› οΈ Ideal Applications

  • Automotive throttle, pressure, and temperature sensor diagnostics

  • ECU integration and validation with real-world sensor data

  • EMI validation and noise tolerance testing

  • In-vehicle testing and validation of sensor wiring integrity

  • Teaching and demonstration of low-level automotive data formats


πŸ”— Related Unlock Options


πŸ“‹ Unlock Summary – UPO7000L Series

Standard protocols included: RS-232/UART, IΒ²C, SPI, CAN, LIN
Available unlocks:

  • UPO7000L-SENT – This page

  • UPO7000L-CANFD – CAN FD decode

  • UPO7000L-FLEX – FlexRay decode

  • UPO7000L-AUDIO – Audio protocol decoding

  • UPO7000L-AREO – MIL-STD-1553 and ARINC 429 decode

  • UPO7000L-PWR – Power analysis toolkit

  • UPO7000L-JIT – Jitter and Eye Diagram tools

  • UPO7000L-AWG – 1-channel function generator

  • UPO7000L-BND – Full feature unlock bundle
