MSO5000HD-SENT – SENT Protocol Decode Option

🚗 Sensor Signal Decoding for Automotive Embedded Systems

The UNI-T MSO5000HD Series oscilloscope is purpose-built for automotive electronics and sensor interface validation. With its 12-bit vertical resolution, up to 1 GHz bandwidth, and deep 500 Mpts memory depth, it provides the clarity and precision needed to analyze modern serial buses. The MSO5000HD-SENT option unlocks decoding and triggering for SENT (Single Edge Nibble Transmission)—a unidirectional automotive sensor protocol widely used for transmitting high-resolution data from pressure, temperature, and position sensors.

SENT provides a low-cost alternative to analog signaling or CAN for time-critical sensor data, especially in safety-critical applications like airbags, throttle position, or exhaust monitoring. With this decode license, your MSO5000HD becomes an intelligent SENT analyzer with full timing and content visibility.


🔍 Key Capabilities

  • Decode Fast Channel and Slow Channel data formats

  • Trigger on status nibble, CRC error, synchronization faults, or specific data patterns

  • View full waveform overlays with decoded nibble values, tick timing, and message structure

  • Detect checksum mismatches, noise-induced errors, or missing pulses

  • Use the event table for review of long captures and specific event filtering

  • Capture timing issues across the entire SENT frame including Sync, Data, and Pause segments


🧠 Benefits of MSO5000HD-SENT

  • Simplified Sensor Interface Debug
    Decode unidirectional data from sensors without external tools or protocol analyzers.

  • Time-Aligned Signal Analysis
    See how power fluctuations, EMI, or logic interference correlate with data or CRC errors.

  • High Confidence in Safety Systems
    Validate frame timing, synchronization, and error detection in brake pressure or throttle applications.


🛠️ Ideal Applications

  • Throttle position and manifold pressure sensor debugging

  • Exhaust aftertreatment system validation

  • Crankshaft/camshaft position sensors

  • Automotive safety system design (airbags, stability control)

  • Tier 1 sensor module integration


🔗 Bundle Availability

The MSO5000HD-SENT decode option is also included in:

  • MSO5000HD-AUTO – for engineers working with automotive serial buses (CAN-FD, LIN, SENT, FlexRay, and more)

  • MSO5000HD-BND – full unlock for all protocol options available on the MSO5000HD series

Learn more:


🧩 Optional Unlockable Software Features – MSO5000HD Series

🔌 Protocol Decode Options

These licenses unlock triggering and decoding for specific digital protocols:

  • MSO5000HD-CANFD – CAN FD (Flexible Data Rate)

  • MSO5000HD-CANXL – CAN XL (next-generation automotive network)

  • MSO5000HD-FLEX – FlexRay (time-deterministic automotive bus)

  • MSO5000HD-SENT – SENT (Single Edge Nibble Transmission, used for sensors)

  • MSO5000HD-AUDIO – I2S, Left Justified (LJ), Right Justified (RJ), and TDM audio protocols

  • MSO5000HD-ARINC429 – ARINC 429 (aerospace serial bus)

  • MSO5000HD-MIL1553 – MIL-STD-1553B (military avionics bus)

  • MSO5000HD-MANCH – Manchester encoding protocol

  • MSO5000HD-1WIRE – 1-WIRE protocol

  • MSO5000HD-I3C – I3C (improved two-wire interface for embedded systems)

⚠️ RS232, UART, SPI, I2C, CAN, and LIN are included as standard and require no license.


📈 Power Analysis

MSO5000HD-PWR – Unlocks the oscilloscope’s integrated power analysis features for evaluating:

  • Power quality

  • Harmonic distortion

  • Rds(on), switching loss

  • Safe operating area

  • Slew rate, ripple, transient response, and efficiency


🎛️ Function Generator & Bode Plot

MSO5000HD-AWG – Enables the dual-channel 50 MHz arbitrary waveform generator

  • Used for signal injection, loop testing, and frequency response analysis

  • Required for full use of the Bode Plot mode


⏱️ Timing Analysis

MSO5000HD-TIME – Unlocks the Time Sequence Analyzer

  • Measures setup/hold time, edge detection, amplitude, and pulse width

  • Supports test report export for buses such as I2C, SPI, CAN, and I2S


📶 Bandwidth Upgrade

Bandwidth unlocks are available to upgrade lower-tier models to higher bandwidth tiers:

  • Example: Upgrade 350 MHz model to 500 MHz or 1 GHz
