UPO6000LP-MIL1553 Aerospace Serial Bus Trigger and Analysis Option (MIL-STD-1553)
Overview
The UPO6000LP-MIL1553 adds MIL-STD-1553B triggering and decoding to your UPO6000LP Series oscilloscope. It decodes command, status and data words — as individual words or as data blocks — and can trigger on any field of a command or status word, down to the individual status bits.
Why it matters: 1553 is the command-and-response bus in military and aerospace platforms, and a terminal that answers late, sets the wrong status bit or produces a Manchester error can take a subsystem off the bus. Decoding the words in context with the analog waveform lets you prove a remote terminal's behavior and its electrical quality at the same time.
The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- Command Word Triggers — Sync, or a full match on remote terminal address, T/R bit, subaddress/mode, word count/mode code and parity.
- Status Word Triggers — Terminal address plus message error, instrumentation, service request, broadcast command received, busy, subsystem flag, dynamic bus control acceptance and terminal flag bits.
- Error Triggers — Parity errors, invalid sync, Manchester encoding errors and non-contiguous data.
- Event List and Export — Decoded frames appear on the trace and in a time-stamped event list (hex, decimal or binary), which can be saved as CSV, HTML or PDF to internal storage or USB for reports and offline analysis.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Remote Terminal Validation — Trigger on the command addressed to your RT and verify its status response and data words against the interface control document.
- Integration Troubleshooting — Catch the Manchester or sync error that only appears when the full system is powered, with the waveform that caused it.
Compatibility
This option is compatible with all UPO6000LP Series oscilloscopes: UPO6034LP (350 MHz, 4 ch), UPO6038LP (350 MHz, 8 ch), UPO6054LP (500 MHz, 4 ch), UPO6058LP (500 MHz, 8 ch), UPO6104LP (1 GHz, 4 ch) and UPO6108LP (1 GHz, 8 ch).
The same capability is offered on other UNI-T oscilloscope families: MSO3000HD, MSO3000X, MSO5000HD.
Frequently Asked Questions
Should I buy this individually or get a bundle?
If 1553 is the only optional protocol you need, this license covers exactly that. Aerospace work often needs ARINC 429 as well; UPO6000LP-BND includes both, plus every other optional serial bus on the UPO6000LP.
How is this option activated?
Buy the option key from your UNI-T distributor, then enter the key and the oscilloscope's serial number on the License Activation page of the UNI-T website to generate a license file. Copy the file to the root of a USB drive and activate it under Utility > Options. The Options screen then lists the option as Activated, with a duration of Permanent.
Can I try it first, and is the license permanent?
Yes to both. Every UPO6000LP option includes a 540-hour trial on the instrument, so you can prove it on your own hardware before you buy. Once activated, the license is permanent for the life of the oscilloscope — no subscriptions, no renewals and no expiration.
