UPO6000LP-BND All Serial Bus Trigger and Decode Options (including EMBD, AUTO, Audio, MIL-STD, ARINC, Manchester)
Overview
The UPO6000LP-BND unlocks every optional serial bus trigger and decode on your UPO6000LP Series oscilloscope in one license: CAN, CAN-FD, LIN, FlexRay, SENT, audio (I²S, LJ, RJ, TDM), MIL-STD-1553, ARINC 429 and Manchester. RS-232/422/485/UART, I²C and SPI are already standard.
Why it matters: the UPO6000LP is a 1U rack-mount scope built for test systems, and a test system outlives the project it was bought for. With every protocol licensed, the instrument can be reassigned between automotive, aerospace, audio and embedded work without a new purchase order each time, and the bundle costs less than licensing the same protocols one at a time.
The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- Every Optional Protocol — Automotive (CAN, CAN-FD, LIN, FlexRay, SENT), audio (I²S, LJ, RJ, TDM), aerospace (MIL-STD-1553, ARINC 429) and Manchester.
- On Top of the Standard Set — RS-232/422/485/UART, I²C and SPI decode and trigger are included with every UPO6000LP.
- Four Decoders at Once — Decode up to four buses simultaneously, each with its own event list exportable as CSV, HTML or PDF.
- One Purchase — A single order line instead of nine separate licenses — simpler to budget and manage across a fleet of rack instruments.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Shared and Rack-Mounted Instruments — A scope in a test rack or lab pool that serves automotive, avionics and audio teams over its life.
- Long-Lived Test Cells — An instrument commissioned for a programme whose buses are not all known on day one.
Compatibility
This option is compatible with all UPO6000LP Series oscilloscopes: UPO6034LP (350 MHz, 4 ch), UPO6038LP (350 MHz, 8 ch), UPO6054LP (500 MHz, 4 ch), UPO6058LP (500 MHz, 8 ch), UPO6104LP (1 GHz, 4 ch) and UPO6108LP (1 GHz, 8 ch).
The same capability is offered on other UNI-T oscilloscope families: MSO2000X, MSO3000HD, MSO5000HD, MSO7000X, MSO8000HD, UPO7000L.
Frequently Asked Questions
Should I buy this individually or get a bundle?
This is the full bundle. If your work is only automotive, UPO6000LP-AUTO is the smaller and cheaper choice; if you need exactly one protocol, buy that license on its own. Note that the generator, power analysis and timing analysis options are separate licenses and are not part of this bundle.
How is this option activated?
Buy the option key from your UNI-T distributor, then enter the key and the oscilloscope's serial number on the License Activation page of the UNI-T website to generate a license file. Copy the file to the root of a USB drive and activate it under Utility > Options. The Options screen then lists the option as Activated, with a duration of Permanent.
Can I try it first, and is the license permanent?
Yes to both. Every UPO6000LP option includes a 540-hour trial on the instrument, so you can prove it on your own hardware before you buy. Once activated, the license is permanent for the life of the oscilloscope — no subscriptions, no renewals and no expiration.
