MSO3000X-MIL1553 Aerospace MIL-STD-1553 Serial Bus Trigger and Analysis
Overview
The MSO3000X-MIL1553 adds MIL-STD-1553 protocol triggering, decoding, and search to your MSO3000X Series oscilloscope — the primary command/response bus for military avionics, weapons systems, and spacecraft.
Operating at 1 Mbit/s over redundant twisted pair, 1553 is in virtually every military aircraft. Protocol-level visibility overlaid on the electrical waveform for debugging timing and signal integrity simultaneously.
Key Features
- 1553 Triggering — Trigger on command/status/data words, RT addresses, subaddresses, or errors.
- Command/Response Decoding — Decoded transactions on the waveform — command word, status word, data words with RT address and word count.
- Response Time Measurement — Measures RT response time for compliance verification (4-12 µs requirement).
- Error Detection — Identifies sync, Manchester encoding, parity, and timeout errors.
- Software License Activation — License key applied through the instrument menu. No hardware changes, no downtime — enter the key and start decoding.
When You Need This
RT Development
Verify your remote terminal responds within the 4-12 µs window with correct status word content.
Legacy System Maintenance
Search deep captures for intermittent 1553 errors, then examine the waveform for electrical root causes.
Compatible Instruments
This option is compatible with all MSO3000X Series oscilloscopes: MSO3034X (350 MHz) and MSO3054X (500 MHz).
Own a Different Instrument?
Need MIL-STD-1553 decode on a different oscilloscope? These series also offer it: MSO3000HD, MSO5000HD.
Explore Other MSO3000X Options
- MSO3000X-BND Serial Bus Trigger and Decode Options Bundle (Includes AUTO, AUDIO, MIL-STD, ARINC429, MANCH) — $1,129
- MSO3000X-PWR Power Analysis Option — $845
- MSO3000X-AWG Arbitrary Waveform Generator option — $280
- MSO3000X-AUTO Automotive Serial Bus Trigger and Decode Options Bundle (CAN, CAN-FD, LIN, FlexRay, SENT) — $705
- MSO3000X-BW3M5T5M 500MHz Bandwidth Upgrade — upgrade 350MHz → 500MHz
Frequently Asked Questions
Should I buy this individually or get a bundle?
If you only need MIL-STD-1553, the individual license at $279 is the most economical. The BND bundle ($1,129) includes every protocol at the deepest discount.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
