MSO5000HD-AUTO

$829.00
Save {price}%

Description

Add Automotive CAN-FD, CAN-XL, FLEX and SENT Serial Bus Triggers and Analysis to your MSO5000HD with this option

Top Specifications

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

OVERVIEW

DOCUMENTATION

MSO5000HD-AUTO – Automotive Protocol Decode Bundle

🚗 Everything You Need to Decode Modern Vehicle Networks

The UNI-T MSO5000HD Series is an advanced mixed-signal oscilloscope that combines high-resolution analog performance with powerful serial protocol tools. With the MSO5000HD-AUTO software bundle, you gain a full suite of unlockable protocol decoders tailored specifically for modern and next-generation automotive systems.

From classic buses like CAN and LIN to emerging high-speed networks like CAN XL and FlexRay, this bundle enables you to analyze, trigger on, and debug communication across the entire in-vehicle data infrastructure—all without external analyzers or conversion tools.


🔍 Included in the MSO5000HD-AUTO Bundle

This bundle includes licenses for the following automotive-focused protocol decode options:

  • MSO5000HD-CANFD – Decode high-speed CAN FD (Flexible Data Rate) messages

  • MSO5000HD-CANXL – Decode next-generation CAN XL networks with payloads up to 2048 bytes

  • MSO5000HD-FLEX – FlexRay support for deterministic, time-triggered communication

  • MSO5000HD-SENT – Decode Single Edge Nibble Transmission data from automotive sensors

  • MSO5000HD-LINIncluded as standard, no license required

  • MSO5000HD-CANIncluded as standard, no license required

Each protocol is fully integrated into the MSO5000HD’s decode engine, with waveform overlays, event tables, search tools, and exportable logs—ideal for time-correlated debugging of digital and analog behavior.


🧠 Benefits of the MSO5000HD-AUTO Bundle

  • Comprehensive Automotive Bus Coverage
    Unlock all key communication protocols used in engine control units, body electronics, battery management, and infotainment.

  • Time-Synchronized Debugging
    See decoded digital messages right alongside analog anomalies such as voltage drops, transient noise, or power loss.

  • Efficient Workflow
    No need to purchase and manage separate licenses—this bundle consolidates all automotive protocols into a single unlock.

  • Cost Savings vs. Individual Licenses
    Purchasing the AUTO bundle costs significantly less than buying each protocol separately.


🛠️ Ideal For

  • Automotive ECU and sensor developers

  • Tier 1 system integrators and test engineers

  • Electric vehicle and ADAS R&D teams

  • Pre-compliance and production QA labs

  • Embedded engineers working on vehicle gateways, safety systems, and zonal networks


🔗 Explore Each Option in Detail

Each license in this bundle is also available as a standalone unlock:

Looking for even more protocol support, including aerospace, digital audio, and embedded sensor interfaces?

Check out the full MSO5000HD-BND complete decode bundle →
