MSO5000HD-CANXL Automotive CAN-XL Serial Bus Trigger and Analysis
Overview
The MSO5000HD-CANXL adds CAN-XL protocol triggering, decoding, and search to your MSO5000HD Series oscilloscope. CAN-XL bridges CAN-FD and Ethernet — payloads up to 2,048 bytes at up to 20 Mbit/s for next-generation zonal vehicle architectures.
CAN-XL is emerging where higher bandwidth is needed for sensor fusion and ADAS but full automotive Ethernet isn't justified. This decode provides trigger-decode-search for CAN-XL traffic.
Key Features
- CAN-XL Triggering — Trigger on priority ID, SDU type, and data content to isolate specific transactions.
- Real-Time Frame Decoding — Decoded CAN-XL frames display on the waveform with extended payloads and electrical characteristics.
- Deep Memory Search — Search captured records for specific CAN-XL content across the full memory.
- Bus Coexistence — CAN-XL coexists with CAN-FD and classic CAN on the same physical bus.
- Software License Activation — License key applied through the instrument menu. No hardware changes, no downtime — enter the key and start decoding.
When You Need This
Zonal Gateway Development
Decode CAN-XL alongside CAN-FD from legacy ECUs to verify gateway translation and timing.
ADAS Sensor Integration
Trigger on sensor data frames to verify payload integrity and timing.
Compatible Instruments
This option is compatible with all MSO5000HD Series oscilloscopes: MSO5034HD (350 MHz), MSO5054HD (500 MHz), and MSO5104HD (1 GHz).
Explore Other MSO5000HD Options
- MSO5000HD-BND Complete Serial Analysis Bundle — $1,369
- MSO5000HD-PWR Advanced Power Analysis — $829
- MSO5000HD-AWG Dual Channel 50MHz Arbitrary Waveform Generator with Bode Plot Analysis — $279
- MSO5000HD-AUTO Automotive CAN-FD, CAN-XL, FLEX and SENT Serial Bus Trigger and Analysis — $829
- MSO5000HD-BW3M5T5M 500MHz bandwidth upgrade — upgrade 350MHz → 500MHz
Frequently Asked Questions
Should I buy this individually or get a bundle?
If you only need CAN-XL, the individual license at $279 is the most economical. The AUTO bundle ($829) adds multiple automotive protocols at a discount. The BND bundle ($1,369) includes every protocol at the deepest discount.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
