MSO5000HD-CANFD – CAN FD Protocol Decode Option

🚗 Decode Next-Generation Automotive Networks on the MSO5000HD

The UNI-T MSO5000HD Series oscilloscope is built for engineers working on high-speed embedded and automotive systems. With up to 1 GHz bandwidth, 12-bit vertical resolution, and deep 500 Mpts memory, it offers exceptional visibility into both analog and digital domains. The MSO5000HD-CANFD unlocks full triggering and decode capabilities for CAN FD (Flexible Data-rate)—the evolution of the classic CAN protocol now widely used in modern ECUs, EVs, ADAS, and gateway modules.

While the MSO5000HD includes standard CAN decoding out of the box, this license is required to analyze CAN FD frames, which allow for much higher data throughput and longer payloads (up to 64 bytes).

🔍 Key Capabilities

• Supports both arbitration and data phases of the CAN FD protocol

• Decode extended data payloads up to 64 bytes

• Trigger on identifier fields, data length code (DLC), control bits, or specific data patterns

• Event table view with timestamped frame breakdown

• Analyze errors including stuff bits, CRC faults, or missing ACKs

• Seamless correlation with analog anomalies such as power dips or noise bursts

🧠 Benefits of MSO5000HD-CANFD

• Accelerated Debugging for High-Speed Vehicles
  Decode hundreds of high-throughput messages per second without a standalone CAN FD sniffer.

• Layer 1 + Layer 2 Visibility
  See not only what data was transmitted, but how waveform integrity may have impacted communication success.

• Flexible Triggering Options
  Narrow down waveform captures by frame ID, byte pattern, or field value to quickly isolate errors.

🛠️ Ideal Applications

• CAN FD ECU development and validation

• Automotive gateway and radar/LiDAR module debugging

• Battery management systems (BMS) in EVs

• Reverse engineering of modern automotive communication

• Automotive compliance and diagnostics labs

🔗 Bundle Availability

The MSO5000HD-CANFD decode option is also available as part of:

• ✅ MSO5000HD-AUTO – includes all popular automotive protocols (CAN-FD, LIN, FlexRay, SENT, CAN-XL, and more)

• ✅ MSO5000HD-BND – complete bundle with every protocol available for the MSO5000HD

For bundle details, see:

• MSO5000HD-AUTO product page →

• MSO5000HD-BND product page →

🧩 Optional Unlockable Software Features – MSO5000HD Series

🔌 Protocol Decode Options

These licenses unlock triggering and decoding for specific digital protocols:

• MSO5000HD-CANFD – CAN FD (Flexible Data Rate)

• MSO5000HD-CANXL – CAN XL (next-generation automotive network)

• MSO5000HD-FLEX – FlexRay (time-deterministic automotive bus)

• MSO5000HD-SENT – SENT (Single Edge Nibble Transmission, used for sensors)

• MSO5000HD-AUDIO – I2S, Left Justified (LJ), Right Justified (RJ), and TDM audio protocols

• MSO5000HD-ARINC429 – ARINC 429 (aerospace serial bus)

• MSO5000HD-MIL1553 – MIL-STD-1553B (military avionics bus)

• MSO5000HD-MANCH – Manchester encoding protocol

• MSO5000HD-1WIRE – 1-WIRE protocol

• MSO5000HD-I3C – I3C (improved two-wire interface for embedded systems)

⚠️ RS232, UART, SPI, I2C, CAN, and LIN are included as standard and require no license.

📈 Power Analysis

MSO5000HD-PWR – Unlocks the oscilloscope’s integrated power analysis features for evaluating:

• Power quality

• Harmonic distortion

• Rds(on), switching loss

• Safe operating area

• Slew rate, ripple, transient response, and efficiency

🎛️ Function Generator & Bode Plot

MSO5000HD-AWG – Enables the dual-channel 50 MHz arbitrary waveform generator

• Used for signal injection, loop testing, and frequency response analysis

• Required for full use of the Bode Plot mode

⏱️ Timing Analysis

MSO5000HD-TIME – Unlocks the Time Sequence Analyzer

• Measures setup/hold time, edge detection, amplitude, and pulse width

• Supports test report export for buses such as I2C, SPI, CAN, and I2S

📶 Bandwidth Upgrade

Bandwidth unlocks are available to upgrade lower-tier models to higher bandwidth tiers:

• Example: Upgrade 350 MHz model to 500 MHz or 1 GHz
