When you need to decode digital bus signals and generate and analyze analog waveforms, the Uni-T MSO2204-S is a great choice!

Top Specifications

200 MHz, 4+16 CH, Digital Logic Probe Included, 2 GSa/s, Memory Depth: 56 Mpts, 1,000,000wfms/s, 8in touch screen, built-in 2CH, 50 MHz signal generator
Register for up to 15% EDU Discount

Guarantee safe & secure checkout

trust2

See more in: Mixed-Signal Oscilloscopes

OVERVIEW

SPECIFICATIONS

DOCUMENTATION

OPTIONS
ACCESSORIES

Uni-T MSO2204-S Mixed Signal Oscilloscope (MSO): Your Precision Measurement Partner

MSO2204-S Oscilloscope AWG Function
MSO2204-S Oscilloscope AWG Function

Elevate your measurement precision with the Uni-T MSO2204-S Mixed Signal Oscilloscope (MSO), a multifunctional powerhouse built on UNI-T's original Ultra Phosphor technology. This high-performance oscilloscope combines ease of use, outstanding technical indicators, and an array of functional features to accelerate your measurement tasks across diverse fields, including communication, semiconductor, computer, instrumentation, industrial electronics, consumer electronics, automotive electronics, on-site maintenance, and education.

Uni-T MSO2204-S Mixed Signal Oscilloscope Key Specifications:

    • BANDWIDTH: 200MHz
    • ANALOG CHANNELS: 4
    • DIGITAL CHANNELS: 16 (UT-M15 Logic probe included)
    • FUNCTION GENERATOR: 50MHz ARB Included
    • REAL-TIME SAMPLE RATE: 2GSa/s
    • MAX. MEMORY DEPTH: 56Mpts
    • WAVEFORM CAPTURE RATE: 1,000,000wfms/s
MSO2204-S Oscilloscope 4M pts enhanced FFT
MSO2204-S Oscilloscope 4M pts enhanced FFT
  • DISPLAY: 8in Multi-point Capacitive Touchscreen

Impressive 200MHz Bandwidth: The Uni-T MSO2204-S Mixed Signal Oscilloscope offers a bandwidth of 200MHz, ensuring you have the necessary speed to evaluate a wide range of devices. Follow the "Rule of Five" by selecting an oscilloscope with 5 times the bandwidth of your fastest signal, making it suitable for applications at 40MHz and below.

4 Analog Input Channels: With four channels, the Uni-T MSO2204-S Mixed Signal Oscilloscope allows simultaneous measurement of multiple signals, making it invaluable for debugging circuits, serial protocol analysis, and video signal assessment.

Function Arbitrary Waveform Generator: Enjoy the Uni-T MSO2204-S Mixed Signal Oscilloscope’s convenience of the built-in dual-channel function arbitrary waveform generator capable of outputting sine waves, square waves, ramp waves, pulse waves, arbitrary waves, noise, and DC. Achieve a maximum frequency output of 50MHz for sine waves.

Bode Plot Function: The MSO2204-S includes a Bode plot function, an essential tool for characterizing the frequency response (gain, phase, and frequency) of electronic designs, including passive filters, amplifier circuits, and negative feedback networks for switch-mode power supplies.

Enhanced FFT Analysis: Leverage the power of full-screen, split-screen, and waterfall chart views to gain rapid and comprehensive frequency domain measurement information. With the Uni-T MSO2204-S Mixed Signal Oscilloscope you can Utilize FFT (Fast Fourier Transform) mathematical operations to seamlessly convert time-domain signals (YT) into frequency-domain signals, facilitating the analysis of harmonic content, distortion, noise features, and vibration characteristics.

MSO2204-S Oscilloscope LA Logic Analyzer
MSO2204-S Oscilloscope LA Logic Analyzer

Rich Trigger Functions: Benefit from a plethora of advanced trigger options on the Uni-T MSO2204-S Mixed Signal Oscilloscope, including edge, pulse width, video, ramp, runt pulse, over-amplitude pulse, delay, timeout, duration, setup hold, Nth edge, and pattern triggers, ensuring precise capture and display of signals of interest.

Logic Analysis Probe UT-M15: Simplify digital signal analysis with the included UT-M15, featuring two 8-channel probes designed for easy device connections via square pins. Enjoy excellent electrical characteristics, including an input impedance of 101kΩ and a capacitive load of only 9.0pF.

Robust Logic Analysis: The Uni-T MSO2204-S Mixed Signal Oscilloscope excels in parallel bus analysis, protocol decoding, and precise timing measurements, enhancing your analytical capabilities with features like Rank Selection, Data Bus Setting, Group Setting, Event Lists, and more.

Full Memory Hardware Decoding: Experience rapid decoding performance with full-memory hardware decoding capabilities, even when working with deep storage of 56Mpts. Reduce decoding time from seconds to milliseconds, ensuring real-time decoding and significantly improving problem diagnosis efficiency. The recorded waveform also supports full-memory hardware real-time decoding.

Generous Memory Depth: Maintain a high sampling rate across a broader time base range while considering overall waveform details, greatly improving the capture rate of abnormal waveforms.

User-Friendly Interface: Utilizing Multi-Scopes technology, the Uni-T MSO2204-S Mixed Signal Oscilloscope offers an intuitive waveform display, allowing users to explore and analyze details effortlessly. Customize each channel with different frequency, amplitude, and waveform settings.

MSO2204-S Oscilloscope Channel split screen function
MSO2204-S Oscilloscope Channel split screen function

Vivid Grayscale Display: Rely on the original Ultra Phosphor display technology for extended observation of waveform details and occasional abnormalities.

High Capture Rate: Powered by innovative digital signal parallel processing technology, the Uni-T MSO2204-S Mixed Signal Oscilloscope achieves an ultra-high capture rate of 200,000wfms/s in normal sampling and 1,000,000wfms/s in Fast Acquire mode, ensuring efficient capture of occasional signals.

XY Mode: Expedite phase difference measurements with the Uni-T MSO2204-S Mixed Signal Oscilloscope between two signals with the XY mode cursor measurement function.

Diverse Measurement Functions: Access up to 36 automatic parameter measurements, significantly enhancing measurement efficiency and accuracy.

Intuitive Interaction: The 8-inch touch screen of the Uni-T MSO2204-S Mixed Signal Oscilloscope supports various gesture operations, including click, slide, zoom, edit, and drag, ensuring a smoother and more convenient measurement experience. Retaining traditional button and knob operations further optimizes the interactive experience.

Rely on the Uni-T MSO2204-S Mixed Signal Oscilloscope (MSO) as your trusted partner for mastering precise measurements and analysis across a wide range of applications.


MSO2204-S Oscilloscope Rich trigger function
MSO2204-S Oscilloscope Rich trigger function
MSO2204-S Oscilloscope Logic Analysis Probe
MSO2204-S Oscilloscope Logic Analysis Probe
MSO2204-S Oscilloscope Bode plot
MSO2204-S Oscilloscope Bode plot
MSO2204-S Oscilloscope Area trigger
MSO2204-S Oscilloscope Area trigger
MSO2204-S Oscilloscope Full memory hardware decoding
MSO2204-S Oscilloscope Full memory hardware decoding
MSO2204-S Oscilloscope Memory depth 56Mpts per channel
MSO2204-S Oscilloscope Memory depth 56Mpts per channel
MSO2204-S Oscilloscope 256-level grayscale display
MSO2204-S Oscilloscope 256-level grayscale display
MSO2204-S Oscilloscope Ultra high capture rate
MSO2204-S Oscilloscope Ultra high capture rate
MSO2204-S Oscilloscope XY mode
MSO2204-S Oscilloscope XY mode
MSO2204-S Oscilloscope Rich measurement functions
MSO2204-S Oscilloscope Rich measurement functions
MSO2204-S Oscilloscope Brand new interactive experience
MSO2204-S Oscilloscope Brand new interactive experience
FeatureSpecification
Model Number MSO2204-S
Scope Type MSO
Bandwidth 200MHz
Channels 4Ch
Scope Sample Rate 2.0GSa/S
Memory Depth 56Mpts
Refresh Rate 1,00,000wfms/s
Logic Pod Included true
Signal Generator Function true
Display Size (in) 8in
Touchscreen true
Warranty 3 years
Product Dimmensions (L x W x H) 15 in x 5 in x 7 in
Product Weight 10 lb
Documents English download guide, multi-language safety manual, calibration report (COC)
Included Accessories Power cord, USB2.0 printing cable, Oscilloscope probe (UT-P05)*4, logic probe (UT-M15), BNC straight-through cable, BNC to alligator clip cable
