MSO/UPO2000-FlexRay Auto serial bus trigger and analysis-FlexRay
Overview
The MSO/UPO2000-FlexRay adds FlexRay protocol triggering, decoding, and search to your MSO/UPO2000 Series oscilloscope. FlexRay is a deterministic, fault-tolerant bus for safety-critical chassis control, braking, and drive-by-wire.
Dual-channel redundancy and guaranteed time slots for critical messages. Decoded protocol content overlays the physical signal.
Key Features
- FlexRay Triggering — Trigger on frame ID, cycle count, payload data, indicator bits, null frames, or errors.
- Real-Time Frame Decoding — Decoded frames display with ID, payload, CRC, and cycle info alongside the analog signal.
- Static/Dynamic Visibility — Identifies static vs. dynamic segment frames for schedule verification.
- Deep Memory Search — Search acquisitions for specific frame IDs, data patterns, or errors.
- Software License Activation — License key applied through the instrument menu. No hardware changes, no downtime — enter the key and start decoding.
When You Need This
Chassis Control Debug
Verify FlexRay timing — trigger on static slots and check protocol timing and signal integrity.
Redundancy Validation
Capture both Channel A and B to verify redundant message consistency.
Compatible Instruments
This option is compatible with all MSO/UPO2000 Series oscilloscopes (MSO/UPO2102, 2104, 2202, 2204 and -S variants).
Own a Different Instrument?
Need FlexRay decode on a different oscilloscope? These series also offer it: MSO/UPO3000CS.
Explore Other MSO/UPO2000 Options
Frequently Asked Questions
Should I buy this individually or get a bundle?
If you only need FlexRay, the individual license at $219 is the most economical. The AUTO bundle ($359) adds multiple automotive protocols at a discount. The BND bundle ($595) includes every protocol at the deepest discount.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
