MSO/UPO2000-COM PC serial bus trigger and analysis (RS232/UART)
Overview
The MSO/UPO2000-COM adds RS232/UART serial bus triggering, decoding, and search to your MSO/UPO2000 Series oscilloscope — the most fundamental serial interface in electronics, used for debug consoles, GPS modules, Bluetooth modules, and inter-processor communication.
See what's actually happening on a serial port — not just what a terminal shows, but electrical signal and decoded data together. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- UART/RS232 Triggering — Trigger on data bytes, parity errors, framing errors, or break conditions.
- Real-Time Frame Decoding — Decoded UART frames display on the waveform with data bytes, parity, and framing identified.
- Configurable Parameters — Standard baud rates (1200 to 921600+), 5-9 data bits, parity, 1-2 stop bits.
- Dual TX/RX Decoding — Decode both transmit and receive lines for full-duplex analysis.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Debug Console Capture — Trigger on a specific error string in UART boot messages and capture surrounding traffic with full waveform context.
- GPS Module Integration — Decode NMEA sentences to verify baud rate and data integrity when the module won't communicate with the host.
Compatibility
This option is compatible with all MSO/UPO2000 Series oscilloscopes (MSO/UPO2102, 2104, 2202, 2204 and -S variants). The same capability is offered on other UNI-T oscilloscope families: MSO/UPO3000CS.
Frequently Asked Questions
Should I buy this individually or get a bundle?
If you only need RS232/UART, the individual license covers exactly that protocol. The BND bundle includes every protocol in the series.
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
