UPO7000L-AWG

UPO7000L-AWG – Single-Channel Arbitrary Waveform Generator Unlock

🎛️ Add Integrated Signal Generation to Your UPO7000L Oscilloscope

Unlock real-time signal injection and waveform creation with the UPO7000L-AWG option for UNI-T’s UPO7000L Series digital phosphor oscilloscopes. This upgrade enables a built-in 1-channel arbitrary waveform generator—ideal for testing analog circuits, simulating sensors, performing sweep analysis, or injecting waveforms for control loop validation.

With up to 60 MHz output frequency, high-resolution waveform shaping, and modulation support, this option turns your oscilloscope into a complete source-and-measure solution—saving bench space and improving workflow efficiency.

🔧 Technical Specifications

📈 Compatible with Bode Plot & Power Loop Analysis

When paired with the UPO7000L-PWR option, the AWG output supports loop gain and stability testing, enabling:

• Open-loop and closed-loop Bode plot analysis

• Gain margin and phase margin measurement

• Fast verification of regulator compensation and filter design

🧠 Why Choose the UPO7000L-AWG Option

• All-in-One Testing
  Stimulus and measurement from the same instrument streamlines setup and saves bench space.

• Real-Time Design Feedback
  Inject waveforms while monitoring system response to optimize tuning in real time.

• Custom Waveform Creation
  Load or build test signals for unique circuit responses, including ramp-up/down or glitch conditions.

• Bode Plot Ready
  Essential for engineers working on switching regulators, feedback loops, or control systems.

🛠️ Ideal Applications

• Frequency response analysis (with UPO7000L-PWR)

• Signal injection into analog circuits and filters

• Sensor signal emulation in embedded systems

• Loop tuning and verification in switching power supplies

• Educational demonstrations of waveform theory and modulation

🔗 Additional UPO7000L Unlock Options

Standard protocol decoders included: RS-232/UART, I²C, SPI, CAN, LIN
Optional software unlocks available separately:

• ✅ UPO7000L-PWR – Power analysis (switching loss, SOA, harmonics, ripple, efficiency)

• ✅ UPO7000L-JITTER – Jitter and eye diagram analysis

• ✅ UPO7000L-CANFD – Automotive CAN FD decode

• ✅ UPO7000L-FLEX – FlexRay protocol decode

• ✅ UPO7000L-SENT – SENT (Single Edge Nibble Transmission) protocol decode

• ✅ UPO7000L-AUDIO – Audio protocol decoding (I2S, LJ, RJ, TDM)

• ✅ UPO7000L-AREO – Aerospace bundle (MIL-STD-1553 + ARINC 429)

• ✅ UPO7000L-BND – Complete bundle (includes all unlocks listed above)
