MSO7000X-AWG

MSO7000X-AWG – Dual-Channel Arbitrary Waveform Generator Option

🎛️ Integrated Signal Generation for Embedded Testing & Bode Plot Analysis

The MSO7000X-AWG unlock adds a powerful, dual-channel 60 MHz arbitrary waveform generator to your UNI-T MSO7000X Series oscilloscope. It transforms the instrument into a full-featured source and measurement platform, enabling test engineers and educators to stimulate and verify circuits with ease—all from a single device.

Perfect for mixed-signal debugging, power supply loop response testing, and filter design, this unlock eliminates the need for a separate function generator, saving space on the bench and simplifying test automation workflows.

⚙️ Generator Specifications

🧠 Real-World Use Cases

✅ Power Supply Bode Plot Analysis

Inject stimulus signals into DC-DC converter feedback loops and use the oscilloscope to generate Bode plots for stability evaluation. When paired with the MSO7000X-PWR software and UT-ISOT isolation transformer, full-loop gain and phase margin testing is possible.

✅ Sensor Simulation for Embedded Systems

Simulate real-world analog input signals like temperature sensors, piezo sensors, or audio tones. Great for validating input channels and test routines.

✅ Filter and Amplifier Characterization

Generate precision sweeps or noise inputs to evaluate analog filter designs and gain profiles. Perfect for analog electronics and education labs.

✅ Trigger-Based Signal Injection

Use the oscilloscope’s trigger system to initiate custom waveform bursts or test patterns in response to system events.

🔧 Features & Capabilities

• Waveform editor for designing and importing user-defined signals
• Arbitrary waveform playback from oscilloscope captures
• Integrated modulation controls for communication system simulation
• Time-aligned generation and acquisition using shared trigger and clock sources
• Bode plot support when combined with MSO7000X-PWR option
• Dual-channel output with independent or synchronous mode

🛠️ Ideal Applications

• Mixed-signal circuit validation
• Control loop and filter response testing
• Waveform playback and fault injection
• Power electronics and SMPS development
• Educational signal generation exercises

🔗 Related Unlock Options

• ✅ MSO7000X-PWR → – Power analysis tools for Bode plots and switching losses
• ✅ MSO7000X-LA → – Logic analyzer for synchronized digital + waveform debugging
• ✅ MSO7000X-BND → – Complete software bundle (protocol-only; AWG not included)

📋 Summary of Unlockable Features – MSO7000X Series

Standard protocols included: RS-232/UART, I²C, SPI, CAN, LIN
Optional unlocks:

• MSO7000X-AWG – This page
• MSO7000X-AERO – MIL-STD-1553 & ARINC 429
• MSO7000X-AUDIO – I2S, LJ, RJ, TDM
• MSO7000X-CANFD – CAN FD
• MSO7000X-FLEX – FlexRay
• MSO7000X-SENT – SENT
• MSO7000X-PWR – Power analysis tools
• MSO7000X-JITTER – Jitter and eye diagram
• MSO7000X-LA – 16-channel logic analyzer
• MSO7000X-BND – Complete protocol + feature bundle (does not include AWG or PWR)
