MSO5000HD-AWG Dual Channel 50MHz Arbitrary Waveform Generator with Bode Plot Analysis
Overview
The MSO5000HD-AWG adds a built-in arbitrary waveform generator and Bode plot analysis. Generate stimulus signals and capture responses on the same instrument — no external function generator needed.
The Bode plot function sweeps a stimulus across frequencies, measures gain and phase, and plots the diagram on screen. The fastest way to characterize filters, amplifiers, and feedback loops. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- Built-In AWG — Independent output channels with sine, square, ramp, pulse, noise, DC, and arbitrary waveforms. No external generator needed.
- Bode Plot Analysis — Automated frequency response — define start/stop frequency and stimulus amplitude, get gain and phase plots. Essential for filter, amplifier, and loop stability verification.
- Stimulus-Response — Generate and capture on the same instrument. No sync issues or ground loops.
- Arbitrary Waveforms — Load custom shapes for specialized testing.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Loop Stability — Verify DC-DC converter feedback loop phase margin. Sweep 10 Hz to the AWG limit and read gain/phase margin directly.
- Filter Characterization — Verify cutoff, roll-off, and passband flatness against simulation automatically.
Compatibility
This option is compatible with all MSO5000HD Series oscilloscopes: MSO5034HD (350 MHz), MSO5054HD (500 MHz), and MSO5104HD (1 GHz). The same capability is offered on other UNI-T oscilloscope families: MSO2000X, MSO3000HD, MSO3000X, MSO7000X, MSO8000HD, UPO7000L.
Frequently Asked Questions
Is this a standalone generator replacement?
The built-in AWG handles common stimulus-response tasks. For higher amplitude, better fidelity, and complex modulation, a dedicated waveform generator is recommended.
Is Bode plot included with AWG?
Yes. Bode plot uses the AWG outputs as stimulus, so the AWG license is required. Bode plot is included at no extra cost.
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
