MSO5000HD-AUDIO

MSO5000HD-AUDIO – Audio Bus Protocol Decode Option (I²S / LJ / RJ / TDM)

🎧 Decode Digital Audio Signals with Confidence on the MSO5000HD

The UNI-T MSO5000HD Series oscilloscope offers exceptional 12-bit resolution, 1 GHz bandwidth, and deep protocol visibility—ideal for modern audio interface debugging. With the MSO5000HD-AUDIO optional license, you can unlock real-time decoding and triggering for a range of digital audio buses including:

• I²S (Inter-IC Sound)

• LJ (Left Justified)

• RJ (Right Justified)

• TDM (Time Division Multiplexed Audio)

These protocols are widely used in embedded audio systems, consumer electronics, automotive infotainment, and digital signal processing applications. This option gives engineers a direct view into their audio data at the bit, word, and channel levels—essential for resolving tricky timing or data alignment issues.

🔍 Key Capabilities

• Decode left/right channel audio data streams in real time

• Visualize word select (WS), serial clock (SCK), and data lines (SD) with fully synchronized analysis

• Trigger on specific word values, channel ID, or data anomalies

• Automatically build event tables for frame-by-frame review

• Display waveform overlays showing timing alignment and decode results simultaneously

🧠 Benefits of MSO5000HD-AUDIO

• Time-Correlated Debugging
  View decoded audio alongside analog measurements such as power ripple, noise, or amplifier distortion—ideal for root cause analysis.

• Accelerated Development
  Rapidly identify clock skew, bit slippage, or incorrect word formatting in early-stage hardware.

• Educational Clarity
  Show students or team members real-time audio frames mapped directly onto their waveforms, making abstract data formats more intuitive.

🛠️ Ideal Applications

• Audio codec debugging (I²S / TDM buses)

• Automotive digital audio system validation

• Smart speaker, headphone, or DSP development

• Educational labs in signal processing and embedded design

• Digital audio routing systems with high channel counts

🔗 Bundle Availability

The MSO5000HD-AUDIO option is also available as part of:

• ✅ MSO5000HD-BND – Complete Decode Bundle
  This bundle includes every protocol option available for the MSO5000HD series.

For a summary of what’s included in the full bundle, view the MSO5000HD-BND product page →

🧩 Optional Unlockable Software Features – MSO5000HD Series

🔌 Protocol Decode Options

These licenses unlock triggering and decoding for specific digital protocols:

• MSO5000HD-CANFD – CAN FD (Flexible Data Rate)

• MSO5000HD-CANXL – CAN XL (next-generation automotive network)

• MSO5000HD-FLEX – FlexRay (time-deterministic automotive bus)

• MSO5000HD-SENT – SENT (Single Edge Nibble Transmission, used for sensors)

• MSO5000HD-AUDIO – I2S, Left Justified (LJ), Right Justified (RJ), and TDM audio protocols

• MSO5000HD-ARINC429 – ARINC 429 (aerospace serial bus)

• MSO5000HD-MIL1553 – MIL-STD-1553B (military avionics bus)

• MSO5000HD-MANCH – Manchester encoding protocol

• MSO5000HD-1WIRE – 1-WIRE protocol

• MSO5000HD-I3C – I3C (improved two-wire interface for embedded systems)

⚠️ RS232, UART, SPI, I2C, CAN, and LIN are included as standard and require no license.

📈 Power Analysis

MSO5000HD-PWR – Unlocks the oscilloscope’s integrated power analysis features for evaluating:

• Power quality

• Harmonic distortion

• Rds(on), switching loss

• Safe operating area

• Slew rate, ripple, transient response, and efficiency

🎛️ Function Generator & Bode Plot

MSO5000HD-AWG – Enables the dual-channel 50 MHz arbitrary waveform generator

• Used for signal injection, loop testing, and frequency response analysis

• Required for full use of the Bode Plot mode

⏱️ Timing Analysis

MSO5000HD-TIME – Unlocks the Time Sequence Analyzer

• Measures setup/hold time, edge detection, amplitude, and pulse width

• Supports test report export for buses such as I2C, SPI, CAN, and I2S

📶 Bandwidth Upgrade

Bandwidth unlocks are available to upgrade lower-tier models to higher bandwidth tiers:

• Example: Upgrade 350 MHz model to 500 MHz or 1 GHz
