MSO3000HD-AUDIO

$279.00
Save {price}%

Description

Add Audio Serial Bus Trigger and Analysis Options (I2S, LJ, RJ, TDM) to your MSO3000HD

Top Specifications

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

OVERVIEW

DOCUMENTATION

MSO3000HD-AUDIO – I²S / LJ / RJ / TDM Protocol Decode Option

🎧 Decode Audio Bus Communication with Clarity and Confidence

The MSO3000HD-AUDIO unlock enables triggering and decoding for popular digital audio protocols—including I²S, Left Justified (LJ), Right Justified (RJ), and Time Division Multiplexing (TDM)—on your UNI-T MSO3000HD Series oscilloscope.

This option is ideal for engineers working on automotive infotainment systems, embedded voice interfaces, DSP development, or audio codec integration. Decode and verify high-resolution audio data streams directly at the physical layer—no need for separate logic analyzers or protocol analyzers.


✅ Standard Protocols (Included Without License)

All MSO3000HD scopes come standard with decoding for:

  • RS-232 / UART

  • I²C

  • SPI

🧩 I²S, LJ, RJ, and TDM decoding requires the MSO3000HD-AUDIO unlock.


🔓 What You Unlock with MSO3000HD-AUDIO

Supported Protocol Description & Use Case Example
I²S Industry-standard stereo audio link between DSPs and codecs. 📌 Used in embedded systems, head units, audio processing ICs.
LJ / RJ Left and Right Justified audio formats with alternative word alignment. 📌 Found in legacy hardware and DAC/ADC testing.
TDM Time-division multiplexed audio data for multichannel applications. 📌 Common in automotive and professional audio mixers.

🧠 Real-World Use Cases

Infotainment System Debug

Verify that head units transmit properly formatted I²S streams to external amplifiers. Trigger on audio word alignment or bit clock irregularities.

Microphone Array Integration

Use TDM decode to confirm correct slot mapping and sample sequencing in digital microphone arrays or voice-activated products.

Embedded Audio Codec Development

Monitor Left/Right Justified or I²S streams to confirm signal timing and data content across BCLK, WS, and DATA lines.

Audio Quality Assurance

Identify dropped frames, jitter, or incorrect sample widths that could degrade sound quality in car audio or consumer electronics.


🔧 Features & Capabilities

  • Decode I²S, LJ, RJ, and TDM audio signals

  • Trigger on word select transitions, data patterns, or framing errors

  • Adjustable data length, format, and justification settings

  • Visual overlay of protocol data on waveform view

  • Time-correlated decode across analog and digital channels

  • Export decoded data for analysis or documentation


🛠️ Ideal Applications

  • Automotive infotainment and speaker integration

  • Embedded voice assistant and DSP designs

  • Codec, DAC, and ADC validation

  • Education on digital audio formats

  • Multichannel AV system development


🔗 Related Unlock Options


📋 Optional Software Summary – MSO3000HD Series

Standard with all models:
✔ RS-232 / UART
✔ I²C
✔ SPI

Available Unlocks:

  • MSO3000HD-CAN

  • MSO3000HD-CAN-FD

  • MSO3000HD-FLEX

  • MSO3000HD-LIN

  • MSO3000HD-SENT

  • MSO3000HD-AUDIO – This page

  • MSO3000HD-MIL1553

  • MSO3000HD-ARINC429

  • MSO3000HD-MANCH

  • MSO3000HD-PWR

  • MSO3000HD-AWG

  • MSO3000HD-AUTO

  • MSO3000HD-BND
