MSO3000HD-MANCH Manchester Wireless Communication Serial Bus Trigger and Analysis
Overview
The MSO3000HD-MANCH adds Manchester encoding trigger and decode to your MSO3000HD Series oscilloscope — a self-clocking line code used in 10BASE-T Ethernet, RFID, NFC, and industrial protocols.
Decodes data content directly on screen, saving manual transition interpretation.
Key Features
- Manchester Decode — Decodes Manchester and Differential Manchester data with bit values on the waveform.
- Configurable Parameters — Set bit rate, idle polarity, and convention (IEEE 802.3 or G.E. Thomas).
- Pattern Triggering — Trigger on specific data patterns in the encoded stream.
- Error Detection — Identifies encoding violations at mid-bit boundaries.
- Software License Activation — License key applied through the instrument menu. No hardware changes, no downtime — enter the key and start decoding.
When You Need This
RFID Debug
Decode reader-to-tag and tag-to-reader Manchester communication for command/response verification.
Industrial Sensor
Custom sensor uses Manchester encoding. Decode to verify data content and timing.
Compatible Instruments
This option is compatible with all MSO3000HD Series oscilloscopes: MSO3024HD (200 MHz), MSO3034HD (350 MHz), MSO3054HD (500 MHz).
Own a Different Instrument?
Need Manchester decode on a different oscilloscope? These series also offer it: MSO3000X, MSO5000HD, MSO8000HD.
Explore Other MSO3000HD Options
- MSO3000HD-BND Serial Bus Trigger and Decode Options Bundle (Includes AUTO, AUDIO, MIL-STD, ARINC429, MANCH) — $1,109
- MSO3000HD-PWR Power Analysis Option — $829
- MSO3000HD-AWG Arbitrary Waveform Generator option — $279
- MSO3000HD-AUTO Automotive Serial Bus Trigger and Decode Options Bundle (CAN, CAN-FD, LIN, FlexRay, SENT) — $689
- MSO3000HD-BW2MT3M5 350MHz Bandwidth Upgrade — upgrade 200MHz → 350MHz
Frequently Asked Questions
Should I buy this individually or get a bundle?
If you only need Manchester, the individual license at $279 is the most economical. The BND bundle ($1,109) includes every protocol at the deepest discount.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
