MSO3000HD Options

MSO3000HD bandwidth upgrades from 200 MHz to 500 MHz, serial bus trigger and decode for automotive (CAN, CAN-FD, LIN, FlexRay), aerospace (ARINC 429, MIL-STD-1553, Manchester), audio bus, and high-speed protocols, plus arbitrary waveform generator and power analysis options across sixteen package upgrades for the four-channel HD oscilloscope platform.

View

  • MSO3000HD-ARINC429Aerospace ARINC429 Serial Bus Trigger and Analysis

    • ARINC 429 Triggering: Trigger on label numbers, SDI, data content, SSM, or parity errors.
    • 32-Bit Word Decoding: Decoded words with label, SDI, data, SSM, and parity fields clearly identified.
    • BNR and BCD Interpretation: Automatically interprets Binary and BCD data formats per ARINC 429 spec.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-AUDIOSerial Bus Trigger and Analysis Option (I2S, LJ, RJ, TDM)

    • Multi-Format Support: Decodes I2S, LJ, RJ, and TDM. Configurable word size (16/24/32-bit) and channel count.
    • Sample-Level Triggering: Trigger on specific audio sample values or ranges — capture clipping, silence, or test tones.
    • Real-Time Decoding: Decoded samples display aligned with BCLK, LRCLK/WS, and data for timing verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-AUTOSerial Bus Trigger and Decode Bundle (CAN, CAN-FD, LIN, FlexRay, SENT)

    • What's Included: 5 protocols with full trigger, decode, and search: CAN (Controller Area Network) — $279 individually CAN-FD — $279 individually FlexRay — $279 individually SENT (SAE J2716) — $279 individually LIN (Local Interconnect Network) — $279 individually
    • Save $706 (50% Off): Bundle pricing vs. purchasing individually.
    • Single License Key: One key unlocks all protocols. No managing separate licenses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $689.00
    Learn More

  • MSO3000HD-AWGArbitrary Waveform Generator option

    • Built-In AWG: Independent output channels with sine, square, ramp, pulse, noise, DC, and arbitrary waveforms. No external generator needed.
    • Bode Plot Analysis: Automated frequency response — define start/stop frequency and stimulus amplitude, get gain and phase plots. Essential for filter, amplifier, and loop stability verification.
    • Stimulus-Response: Generate and capture on the same instrument. No sync issues or ground loops.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-BNDSerial Bus Trigger and Decode Bundle (incl. AUTO, AUDIO, MIL-STD, ARINC429, MANCH)

    • What's Included: 9 protocols with full trigger, decode, and search: CAN (Controller Area Network) — $279 individually CAN-FD — $279 individually FlexRay — $279 individually SENT (SAE J2716) — $279 individually LIN (Local Interconnect Network) — $279 individually Audio Serial Bus (I2S, LJ, RJ, TDM) — $279 individually MIL-STD-1553 — $279 individually ARINC 429 — $279 individually Manchester Encoding — $279 individually
    • Save $1,402 (55% Off): Bundle pricing vs. purchasing individually.
    • Single License Key: One key unlocks all protocols. No managing separate licenses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,109.00
    Learn More

  • MSO3000HD-BW2MT3M5350MHz Bandwidth Upgrade

    • 200MHz → 350MHz Bandwidth: Upgrades all analog channels on your MSO3024HD.
    • Faster Rise Times: Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
    • No Hardware Changes: Bandwidth is software-defined. Enter the key and operate at 350MHz immediately.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $499.00
    Learn More

  • MSO3000HD-BW2MT5M500MHz Bandwidth Upgrade

    • 200MHz → 500MHz Bandwidth: Upgrades all analog channels on your MSO3024HD.
    • Faster Rise Times: Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
    • No Hardware Changes: Bandwidth is software-defined. Enter the key and operate at 500MHz immediately.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,599.00
    Learn More

  • MSO3000HD-BW3M5T5M500MHz Bandwidth Upgrade

    • 350MHz → 500MHz Bandwidth: Upgrades all analog channels on your MSO3034HD.
    • Faster Rise Times: Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
    • No Hardware Changes: Bandwidth is software-defined. Enter the key and operate at 500MHz immediately.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,099.00
    Learn More

  • MSO3000HD-CANAutomotive CAN Serial Bus Trigger and Analysis

    • Protocol-Aware Triggering: Trigger on specific CAN conditions — frame ID, data content, error frames, remote frames, or overload frames — to isolate the exact bus activity you're investigating.
    • Real-Time Frame Decoding: Decoded CAN frames (arbitration ID, DLC, data payload, CRC, acknowledge) display directly on the waveform trace for signal-protocol correlation.
    • Deep Memory Protocol Search: Search captured records for specific message IDs, data patterns, or error conditions across the full acquisition memory.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-CANFDAutomotive CAN-FD Serial Bus Trigger and Analysis

    • Protocol-Aware Triggering: Trigger on CAN-FD conditions — frame ID, data, error frames, or bit rate switch events.
    • Real-Time Frame Decoding: Decoded CAN-FD frames (ID, DLC, data, CRC, ACK) display on the waveform for protocol-electrical correlation.
    • Deep Memory Search: Search captured records for specific message IDs, data patterns, or errors across the full memory.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-FLEXAutomotive FlexRay Serial Bus Trigger and Analysis

    • FlexRay Triggering: Trigger on frame ID, cycle count, payload data, indicator bits, null frames, or errors.
    • Real-Time Frame Decoding: Decoded frames display with ID, payload, header CRC, and cycle info alongside the analog signal.
    • Static/Dynamic Segment Visibility: Identifies static vs. dynamic segment frames for schedule table verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-LINAutomotive LIN Serial Bus Trigger and Analysis

    • LIN Triggering: Trigger on frame IDs, data content, checksum errors, or sync break fields.
    • Real-Time Frame Decoding: Decoded LIN frames (sync, PID, data, checksum) display on the waveform trace.
    • Master-Slave Timing: Shows master header and slave response timing for diagnosing timeouts and schedule issues.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-MANCHManchester Serial Bus Trigger and Analysis Option

    • Manchester Decode: Decodes Manchester and Differential Manchester data with bit values on the waveform.
    • Configurable Parameters: Set bit rate, idle polarity, and convention (IEEE 802.3 or G.E. Thomas).
    • Pattern Triggering: Trigger on specific data patterns in the encoded stream.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-MIL1553MIL-STD-1553 Serial Bus Trigger and Analysis Option

    • 1553 Triggering: Trigger on command/status/data words, RT addresses, subaddresses, or errors.
    • Command/Response Decoding: Decoded transactions on the waveform — command word, status word, data words with RT address and word count.
    • Response Time Measurement: Measures RT response time for compliance verification (4-12 µs requirement).
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

  • MSO3000HD-PWRPower Analysis Option

    • Switching Loss: Calculates energy per switching transition for MOSFETs, IGBTs. Essential for thermal design and efficiency.
    • Safe Operating Area: Plots V×I trajectories against device limits during transients, startup, and faults.
    • Ripple Analysis: Output ripple amplitude and frequency content. Identifies sources: switching frequency, ESR, load transients.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $829.00
    Learn More

  • MSO3000HD-SENTAutomotive SENT Sensor Bus Trigger and Analysis

    • SENT Triggering: Trigger on fast channel data, slow channel messages, or error conditions.
    • Fast and Slow Channel Decoding: Decodes fast channel (primary sensor data) and slow channel (config/diagnostics).
    • Nibble-Level Display: Individual nibble values and timing overlaid on the waveform for SAE J2716 verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More

Resources

MSO3000HD Options Documents and Downloads

Datasheets, manuals, software

Extend your UNI-T MSO3000HD-Series Oscilloscope with these amazing options.
