  • UTS5000A-NRNR demodulation analysis option for UTS5000A series

    • 5G NR Demodulation: EVM, frequency error, modulation quality.
    • Flexible Numerology: Supports 15, 30, 60, 120 kHz subcarrier spacings.
    • SSB Characterization: Synchronization Signal Block analysis for beam measurements.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $7,299.00
    Learn More

  • UTS5000A-P26Preamplifier Gain Option

    • Preamp to 26.5 GHz: Low-noise gain for improved sensitivity.
    • Improved DANL: Lower noise floor.
    • Switchable: Enable/disable from menu.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,315.00
    Learn More

  • UTS5000A-PNMPhase Noise Measurement Option

    • Phase Noise vs. Offset: Single-sideband phase noise from Hz to MHz offsets in one sweep.
    • Auto Carrier Detection: Automatically identifies the carrier frequency.
    • Integrated Phase Noise: Calculates jitter over a specified offset range.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UTS5000A-TDD-LTETDD-LTE Demodulation Analysis Option

    • TDD-LTE Demodulation: EVM, frequency error, and modulation quality per 3GPP.
    • Channel Measurements: Channel power, ACLR, spectral emission mask.
    • Constellation/EVM: Constellation diagrams and EVM for QPSK, 16QAM, 64QAM.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $6,999.00
    Learn More

  • UTS5000A-VSADigital Demodulation Analysis Option

    • Digital Demodulation: ASK, FSK, PSK, QAM, OFDM with EVM and quality measurements.
    • Constellation Diagram: Visual assessment of modulation quality and impairments.
    • EVM Measurement: Error Vector Magnitude β€” the standard modulation quality metric.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UTS5026A26.5 GHz Performance-Series Signal Analyzer

    • Frequency Range: 9kHz - 26.5GHz
    • DANL: -163dBm/Hz
    • RBW: 1Hz-3MHz (10% Steps), 4, 5, 6, 8MHz
    • Phase Noise: <-107dBc/Hz
    • RTSA: 25MHz
    $31,499.00
    Learn More

  • UTS7000A-AMAAnalog Demodulation Measurement Option

    • AM, FM, and PM demodulation: Three demodulation modes selectable from the option menu
    • Demodulation frequency range: 2 MHz to 40 GHz carrier frequency
    • Modulation rate range: 20 Hz to 100 kHz on all three modes
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UTS7000A-AMKAdvanced Measurement Kit Option

    • Channel Power measurement: Channel power and power integral density
    • T-power (time-domain power): Zero-sweep time-integral power
    • Occupied Bandwidth (OBW): Occupancy power and transmission frequency error
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,499.00
    Learn More

  • UTS7000A-B160160 MHz Real-Time Analysis Bandwidth License

    • 160 MHz real-time analysis bandwidth: Expands RTSA and I/Q analysis from the 40 MHz baseline.
    • 1 GSa/s sampling on the wide-band IF path: Up from 100 MSa/s on the 20 MHz baseline path.
    • Step in the upgrade path: The B160 path sits between the UTS7000A-B85 (85 MHz) and UTS7000A-B255 (255 MHz) licenses on the same chassis.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,999.00
    Learn More

  • UTS7000A-B255255 MHz Real-Time Analysis Bandwidth License

    • 255 MHz real-time analysis bandwidth: Expands RTSA and I/Q analysis from the 40 MHz baseline to the widest span available on the UTS7000A platform.
    • 1 GSa/s sampling on the wide-band IF path: Up from 100 MSa/s on the 20 MHz baseline path.
    • Top of the upgrade path: The B255 license supersedes the UTS7000A-B85 (85 MHz) and UTS7000A-B160 (160 MHz) options on the same chassis.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,599.00
    Learn More

  • UTS7000A-B8585 MHz Real-Time Analysis Bandwidth License

    • 85 MHz real-time analysis bandwidth: Expands RTSA and I/Q analysis from the 40 MHz baseline.
    • 1 GSa/s sampling on the wide-band IF path: Up from 100 MSa/s on the 20 MHz baseline path.
    • Step in the upgrade path: The B85 path can later be replaced by the wider UTS7000A-B160 (160 MHz) or UTS7000A-B255 (255 MHz) licenses on the same chassis.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,599.00
    Learn More

  • UTS7000A-EMIEMI Measurement Option

    • CISPR-compliant detectors: Positive peak, quasi-peak, EMI average, average, and negative peak
    • CISPR resolution bandwidths: 200 Hz, 9 kHz, 120 kHz, and 1 MHz (CISPR mode); 1 Hz to 10 MHz (general mode)
    • EMI filter: βˆ’6 dB filter bandwidth per CISPR convention (versus βˆ’3 dB Gaussian for general measurement)
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,099.00
    Learn More

  • UTS7000A-FDD-LTEFDD-LTE Demodulation Analysis Option

    • 3GPP LTE FDD demodulation: Uplink and downlink demodulation with per-resource-block EVM
    • System bandwidths: 1.4, 3, 5, 10, 15, and 20 MHz
    • Pre-defined downlink test models: TM1.1, TM2, TM2a, TM2b, TM3.1, TM3.1a, TM3.1b, TM3.2, TM3.3
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $6,399.00
    Learn More

  • UTS7000A-I/QI/Q Analyzer Option

    • Complex baseband I/Q capture: Records the in-phase and quadrature components of the signal alongside the frequency-domain view
    • Time-record length: 8,000,000 IQ sample pairs per acquisition
    • Sample rate: 1 GSa/s on the wide-band IF path (40 MHz and above); 100 MSa/s on the 20 MHz IF path
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UTS7000A-NR5G NR Demodulation Analysis Option

    • 3GPP 5G NR (FR1) demodulation: Downlink and uplink signal demodulation per 3GPP Release 15 through 18
    • System bandwidths: 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 80, 90, 100 MHz
    • Numerologies: 15 kHz and 30 kHz subcarrier spacing
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $9,599.00
    Learn More

  • UTS7000A-P1313.6 GHz Preamplifier Option for UTS7013A

    • DANL improvement of β‰ˆ13 to 17 dB: Across the chassis frequency range, with the largest gains in the mid-band where the chassis noise floor is highest
    • Preamp On/Off menu toggle: Engagement is software-controlled from the front panel; switch in for weak-signal measurement, switch out for higher-power measurements
    • Applicable frequency range: 100 kHz to 13.6 GHz (chassis-capped); the option spec covers 100 kHz to 40 GHz
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UTS7000A-P2626.5 GHz Preamplifier Option for UTS7026A

    • DANL improvement of β‰ˆ13 to 17 dB: Across the chassis frequency range, with the largest gains in the mid-band where the chassis noise floor is highest
    • Preamp On/Off menu toggle: Engagement is software-controlled from the front panel; switch in for weak-signal measurement, switch out for higher-power measurements
    • Applicable frequency range: 100 kHz to 26.5 GHz (chassis-capped); the option spec covers 100 kHz to 40 GHz
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,699.00
    Learn More

  • UTS7000A-P3232 GHz Preamplifier Option for UTS7032A

    • DANL improvement of β‰ˆ13 to 17 dB: Across the chassis frequency range, with the largest gains in the mid-band where the chassis noise floor is highest
    • Preamp On/Off menu toggle: Engagement is software-controlled from the front panel; switch in for weak-signal measurement, switch out for higher-power measurements
    • Applicable frequency range: 100 kHz to 32 GHz (chassis-capped); the option spec covers 100 kHz to 40 GHz
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,499.00
    Learn More

  • UTS7000A-P4040 GHz Preamplifier Option for UTS7040A

    • DANL improvement of β‰ˆ13 to 17 dB: Across the chassis frequency range, with the largest gains in the mid-band where the chassis noise floor is highest
    • Preamp On/Off menu toggle: Engagement is software-controlled from the front panel; switch in for weak-signal measurement, switch out for higher-power measurements
    • Applicable frequency range: 100 kHz to 40 GHz (chassis-capped); the option spec covers 100 kHz to 40 GHz
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $3,299.00
    Learn More

  • UTS7000A-PNMPhase Noise Measurement Option

    • One-touch phase noise measurement: Automated carrier search, configurable start/stop offset frequencies, and dBc/Hz log-plot output
    • Log-plot, spot-frequency, monitor, and IQ-waveform views: Four measurement views for different workflows
    • Carrier frequency range: 100 kHz to 40 GHz
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,299.00
    Learn More

  • UTS7000A-TDD-LTETDD-LTE Demodulation Analysis Option

    • 3GPP LTE TDD demodulation: Uplink and downlink demodulation with per-resource-block EVM
    • System bandwidths: 1.4, 3, 5, 10, 15, and 20 MHz
    • TDD uplink-downlink configurations: 0 through 6 (full 3GPP-defined TDD frame structure set)
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $6,399.00
    Learn More

  • UTS7000A-VSAVector Signal Analysis Option

    • Digital modulation analysis: Constellation, EVM, magnitude error, phase error, IQ diagram, eye diagrams, and symbol-table outputs
    • Modulation type coverage: PSK (BPSK, QPSK, 8PSK, OQPSK, DQPSK, D8PSK, Ο€/4-DQPSK, Ο€/8-D8PSK), QAM (16, 32, 64, 128, 256), FSK (2/4/8/16), ASK (2/4/8/16), MSK (Type1, Type2)
    • Symbol rate: 1 ksps up to the chassis analysis bandwidth divided by symbol points
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,199.00
    Learn More
  • New

    UTS7013A13.6 GHz Interceptor-Series Signal Analyzer

    • Frequency Range: 2Hz - 13.6GHz
    • DANL: -167dBm/Hz
    • RBW: 1Hz-3MHz (10% Steps), 4MHz, 5MHz, 6MHz, 8MHz, 10MHz
    • Phase Noise: <-110dBc/Hz
    • RTSA: 40MHz/255MHz
    $24,999.00
    Learn More
  • Contact Us For Lead Time

    UTS7013A-NB13GHz Interceptor-Series Signal Analyzer; 20MHz RSA

    • Frequency Range: 2Hz - 13.6GHz
    • DANL: -167dBm/Hz
    • RBW: 1Hz-3MHz (10% Steps), 4MHz, 5MHz, 6MHz, 8MHz, 10MHz
    • Phase Noise: <-110dBc/Hz
    • RTSA: 20MHz
    $22,999.00
