UPO7000L-JITTER Jitter Analysis and Eye Diagram Option
Overview
The UPO7000L-JITTER adds advanced jitter analysis and eye diagram measurements for signal integrity assessment in high-speed serial links and clock systems.
For PCIe, USB, HDMI, DDR, or custom serial links — decompose timing variations and verify receiver requirements with eye diagrams.
Key Features
- Jitter Decomposition — Separates RJ, DJ, PJ, DDJ, and DCD for root-cause analysis.
- Eye Diagram — Statistical eye from serial data for signal quality — eye height, width, mask margin.
- Bathtub Curve — BER vs. sampling position for link margin prediction.
- Clock Jitter — Period jitter, cycle-to-cycle, and TIE for clock characterization.
- Software License Activation — License key via instrument menu. No hardware changes.
When You Need This
Serial Link Validation
Intermittent bit errors. Generate eye diagram for quality assessment, decompose jitter to find the source.
Clock Characterization
Measure period/cycle-to-cycle jitter on an oscillator for PLL and data converter requirements.
Compatible Instruments
This option is compatible with all UPO7000L Series oscilloscopes: UPO7104L (1 GHz) and UPO7204L (2 GHz).
Own a Different Instrument?
Need Jitter analysis and eye diagram on a different oscilloscope? These series also offer it: MSO7000X, MSO8000HD.
Explore Other UPO7000L Options
- UPO7000L-BND Complete Analysis Bundle Option (JITTER, PWR, CANFD, FLEX, SENT, AUDIO, AERO) — $2,399
- UPO7000L-PWR Advanced Power Analysis Option — $999
- UPO7000L-AWG Single-Channel 60MHz Arbitrary Waveform Generator Option — $489
- UPO7000L-BW-10T20 UPO7104L Bandwidth Upgrade from 1GHz to 2GHz Option — upgrade 1GHz → 2GHz
Frequently Asked Questions
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
