UTS3000A Options

UTS3000A real-time bandwidth upgrade (B40), demodulation and analysis packages for 5G NR, FDD-LTE, TDD-LTE, EMI pre-compliance, VSA, I/Q capture, phase noise, AMA analog modulation, and AMK advanced measurement — ten options covering the full UTS3000A signal-analyzer capability stack.

View

  • UTS3000A-AMAAM/FM Analog Demodulation Option

    • AM/FM Demodulation: Real-time AM/FM demodulation with configurable carrier frequency.
    • Audio Output: Listen to demodulated signals for quick identification.
    • Modulation Measurements: AM depth and FM deviation measured automatically.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $499.00
    Learn More

  • UTS3000A-AMKAdvanced Measurement Kit Option

    • Channel Power: Total power within a defined channel bandwidth.
    • Occupied Bandwidth: Bandwidth containing 99% of transmitted power.
    • ACPR/ACLR: Adjacent channel power ratio for spectral regrowth evaluation.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $599.00
    Learn More

  • UTS3000A-B4040MHz Real-Time Analysis Option

    • 40 MHz Bandwidth: Captures and processes 40 MHz instantaneous bandwidth in real time.
    • Frequency-Hopping: Captures signals that conventional swept analysis misses.
    • Transient Detection: Finds short-duration spectral events between sweeps.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,299.00
    Learn More

  • UTS3000A-EMIEMI Pre-Compliance Measurement Option

    • EMI Detectors: Quasi-peak, EMI average, peak, negative peak per CISPR 16.
    • Limit Lines: CISPR 11/22/32, FCC Part 15, EN 55011/55032, MIL-STD-461, VCCI, and more.
    • Automated Scans: Scan-search-measure workflows — peaks identified, quasi-peak measured, results compiled automatically.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $799.00
    Learn More

  • UTS3000A-FDD-LTEFDD-LTE Demodulation Analysis Option

    • FDD-LTE Demodulation: EVM, frequency error, and modulation quality per 3GPP.
    • Channel Measurements: Channel power, ACLR, spectral emission mask.
    • Constellation/EVM: Constellation diagrams and EVM for QPSK, 16QAM, 64QAM.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $6,399.00
    Learn More

  • UTS3000A-I/QI/Q Modulation Analysis Option

    • I/Q Capture: Raw I/Q data at configurable sample rates.
    • Dual-Domain Display: Time and frequency domain views simultaneously.
    • Data Export: Export I/Q data for MATLAB, Python, or external tools.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $499.00
    Learn More

  • UTS3000A-NR40UTS3000A-NR 5G 40MHz New Radio Analysis Option

    • 5G NR Demodulation: EVM, frequency error, modulation quality.
    • Flexible Numerology: Supports 15, 30, 60, 120 kHz subcarrier spacings.
    • SSB Characterization: Synchronization Signal Block analysis for beam measurements.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $9,599.00
    Learn More

  • UTS3000A-PNMPhase Noise Measurement option for UTS3000A series

    • Phase Noise vs. Offset: Single-sideband phase noise from Hz to MHz offsets in one sweep.
    • Auto Carrier Detection: Automatically identifies the carrier frequency.
    • Integrated Phase Noise: Calculates jitter over a specified offset range.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,099.00
    Learn More

  • UTS3000A-TDD-LTETDD-LTE Demodulation Analysis Option

    • TDD-LTE Demodulation: EVM, frequency error, and modulation quality per 3GPP.
    • Channel Measurements: Channel power, ACLR, spectral emission mask.
    • Constellation/EVM: Constellation diagrams and EVM for QPSK, 16QAM, 64QAM.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $6,399.00
    Learn More

  • UTS3000A-VSAVector Signal Analysis Demodulation Option

    • Digital Demodulation: ASK, FSK, PSK, QAM, OFDM with EVM and quality measurements.
    • Constellation Diagram: Visual assessment of modulation quality and impairments.
    • EVM Measurement: Error Vector Magnitude — the standard modulation quality metric.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

Resources

Documents & Downloads for the UTS3000A Signal Analyzers series

Data Sheets 1
User Manuals 10
Programming Manuals 1
Software 2
Firmware 1
Older firmware versions (3)

Extend your UNI-T UTS3000A-Series Signal Analyzer with these amazing options.
