UTS3000A-FDD-LTE FDD-LTE Demodulation Analysis Option

Soft carrying bag that fits UTD Digital Storage Oscilloscopes, MSO/UPO1000/2000/3000 Mixed Signal and Ultra Phosphor Oscilloscopes, and UTS1000/3000 Spectrum Analyzers.

Kit includes 4 Pcs magnetic field near-field probes; 1 Pcs SMA-SMB cable, 1 Pcs Adapter SMA-N-KJ-T, 30MHz – 3GHz

UT-RB60 VSWR Bridge - Reflection Measurement Solution Expand Your UTS3000T+ Series Capabilities The UT-RB60 VSWR Bridge is the essential accessory for engineers and technicians who need accurate reflection measurements with their UTS3000T+ Series spectrum analyzers. This precision instrument transforms your spectrum analyzer into a comprehensive reflection measurement system, enabling critical antenna and transmission line analysis across the entire UTS3000T+ product family. Key Features Wide Frequency Coverage Operating Range: DC to 6 GHz Compatible with the complete UTS3000T+ series: UTS3015T+ (9 kHz to 1.5 GHz) UTS3032T+ (9 kHz to 3.2 GHz) UTS3036T+ (9 kHz to 3.6 GHz) UTS3084T+ (9 kHz to 8.4 GHz) Covers all major communication bands including cellular, WiFi, Bluetooth, and emerging 5G/6G frequencies Precision Measurement Capabilities VSWR (Voltage Standing Wave Ratio) measurement Return Loss analysis Reflection Coefficient determination High accuracy across the entire frequency range Professional Build Quality Robust construction for laboratory and field use Type-N connectors for reliable, low-loss connections 50Ω impedance matching for standard RF systems Compact, portable design for on-site measurements Applications Antenna Testing & Optimization Measure antenna VSWR across operating bandwidth Identify resonant frequencies and bandwidth characteristics Optimize antenna matching for maximum power transfer Transmission Line Analysis Verify cable integrity and performance Locate impedance discontinuities Assess connector quality and installation RF System Validation Component matching verification Filter and amplifier input/output characterization Quality control in manufacturing environments Technical Advantages Seamless Integration The UT-RB60 works directly with your UTS3000T+ series analyzer's built-in reflection measurement functions. Simply connect the bridge between your spectrum analyzer and the device under test - no complex setup required. Advanced Measurement Features Leverage up to 40,001 sweep points (UTS3000A/UTS3036T+/UTS3084T+ models) for high-resolution analysis Multi-touch HD control on 10.1-inch capacitive display for intuitive operation Real-time visualization with multiple trace types and detection modes Advanced triggering capabilities for capturing intermittent reflections Cost-Effective Solution Eliminate the need for expensive dedicated VSWR meters. The UT-RB60 bridge leverages your existing spectrum analyzer investment to provide professional-grade reflection measurements at a fraction of the cost. System Requirements Compatible Models: All UTS3000T+ Series Spectrum Analyzers UTS3015T+ (9 kHz to 1.5 GHz) UTS3032T+ (9 kHz to 3.2 GHz) UTS3036T+ (9 kHz to 3.6 GHz) UTS3084T+ (9 kHz to 8.4 GHz) Frequency Range: DC to 6 GHz (bridge limitation) Impedance: 50Ω nominal Connectors: Type-N female What's Included UT-RB60 VSWR Bridge Comprehensive user manual with measurement procedures Calibration guidelines for optimal accuracy Why Choose the UT-RB60? Professional Results: Achieve laboratory-grade reflection measurements with your portable spectrum analyzer setup. Versatile Applications: From antenna development to production testing, the UT-RB60 handles diverse measurement requirements. Proven Reliability: Built to UNI-T's exacting standards, ensuring consistent performance in demanding environments. Future-Proof Investment: 6 GHz coverage supports current wireless technologies including WiFi 6E, and provides compatibility across the entire UTS3000T+ analyzer family. Important Frequency Considerations Note: While the UT-RB60 bridge operates up to 6 GHz, it can be used with higher-frequency analyzers like the UTS3084T+ (8.4 GHz). For measurements above 6 GHz, the bridge becomes the limiting factor, making it ideal for most commercial wireless applications while maintaining compatibility across the entire UTS3000T+ family. Transform your UTS3000T+ spectrum analyzer into a complete RF test solution. The UT-RB60 VSWR Bridge delivers the precision reflection measurements you need for professional antenna and transmission line analysis. Ready to enhance your RF measurement capabilities? Add the UT-RB60 VSWR Bridge to your test equipment arsenal today.

N-SMA-JJ RF cable，DC-6GHz VSWR≤1.25:1@6GHz IL≤1.8dB@6GHz

N-SMA-JK adaptor，DC-6GHz VSWR≤1.15:1@6GHz IL≤0.2dB@6GHz

Spectrum Utility Kit: include NSMAJ-NJ-0.7M DC-6G Cable x1, NJ-NJ-0.7M DC-6G Cable x1, SMA-N-KJ-T DC-6GHz Adapter x2,N-BNC-JK DC-4GHz Adapter x2, 2400MHz-2500MHz Antenna x2, 824-960MHz/1710-1990MHz x2

VNA Test Cable Kit (18GHz)

Male VNA Calibration Kit (9GHz)

Female-Male VNA Calibration Kit (9GHz)

Female VNA Calibration Kit (9GHz)

2.92J-2.92J RF cable，DC-40GHz VSWR≤1.25:1@40GHz IL≤3.5dB@40GHz

N-N-JJ RF cable，DC-6GHz VSWR≤1.25:1@6GHz IL≤1.8dB@6GHz

Receiving antenna，working frequency 824MHz-960MHz，Gain<2dBi

Receiving antenna，working frequency 2400MHz-2500MHz，Gain<2dBi

UT-W03-40GHz (1pc),UT-C04-40GHz(2pcs),UT-C03-18GHz (1pc)

2.92-KKG adaptor，DC-40GHz VSWR≤1.20:1@40GHz IL≤0.3dB@40GHz

SMA-N-KJG adaptor，DC-18GHz VSWR≤1.15:1@18GHz IL≤0.3dB@18GHz

N-BNC-JK adaptor，DC-4GHz VSWR≤1.15:1@4GHz IL≤0.2dB@4GHz
