UPO7000L Options

UPO7000L rack-mount oscilloscope serial bus trigger and decode for automotive (CAN-FD, FlexRay, SENT), aerospace, and audio protocols, jitter analysis, arbitrary waveform generator, advanced power analysis, and bandwidth upgrade options across ten packages for the 1U rack-mount platform.

View

  • UPO7000L-AEROMIL-STD-1553 and ARINC 429 Serial Bus Trigger and Analysis Option

    • MIL-STD-1553 Decode: Trigger and decode command words, status words, data words, RT addresses, errors.
    • ARINC 429 Decode: Trigger and decode 32-bit words with label, SDI, data, SSM, parity.
    • Combined License: Both protocols in a single key — no separate purchases.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UPO7000L-AUDIOAudio Serial Bus Trigger and Analysis Option (I2S, LJ, RJ, TDM)

    • Multi-Format Support: Decodes I2S, LJ, RJ, and TDM. Configurable word size (16/24/32-bit) and channel count.
    • Sample-Level Triggering: Trigger on specific audio sample values or ranges — capture clipping, silence, or test tones.
    • Real-Time Decoding: Decoded samples display aligned with BCLK, LRCLK/WS, and data for timing verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UPO7000L-AWGSingle-Channel 60MHz Arbitrary Waveform Generator Option

    • Built-In AWG: Independent output channels with sine, square, ramp, pulse, noise, DC, and arbitrary waveforms. No external generator needed.
    • Bode Plot Analysis: Automated frequency response — define start/stop frequency and stimulus amplitude, get gain and phase plots. Essential for filter, amplifier, and loop stability verification.
    • Stimulus-Response: Generate and capture on the same instrument. No sync issues or ground loops.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $489.00
    Learn More

  • UPO7000L-BNDComplete Options Bundle (AERO, AUDIO, CANFD, FLEX, JITTER, PWR, SENT)

    • What's Included: 7 protocols with full trigger, decode, and search: CAN-FD — $999 individually FlexRay — $999 individually SENT (SAE J2716) — $999 individually Audio Serial Bus (I2S, LJ, RJ, TDM) — $999 individually Aerospace Bus (MIL-STD-1553 + ARINC 429) — $999 individually JITTER — $999 individually PWR — $999 individually
    • Save $4,594 (65% Off): Bundle pricing vs. purchasing individually.
    • Single License Key: One key unlocks all protocols. No managing separate licenses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,399.00
    Learn More

  • UPO7000L-BW-10T20UPO7104L Bandwidth Upgrade from 1GHz to 2GHz Option

    • 1GHz → 2GHz Bandwidth: Upgrades all analog channels on your UPO7104L.
    • Faster Rise Times: Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
    • No Hardware Changes: Bandwidth is software-defined. Enter the key and operate at 2GHz immediately.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $3,699.00
    Learn More

  • UPO7000L-CANFDCAN-FD Serial Bus Trigger and Analysis Option

    • Protocol-Aware Triggering: Trigger on CAN-FD conditions — frame ID, data, error frames, or bit rate switch events.
    • Real-Time Frame Decoding: Decoded CAN-FD frames (ID, DLC, data, CRC, ACK) display on the waveform for protocol-electrical correlation.
    • Deep Memory Search: Search captured records for specific message IDs, data patterns, or errors across the full memory.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UPO7000L-FLEXFlexRay Serial Bus Trigger and Analysis Option

    • FlexRay Triggering: Trigger on frame ID, cycle count, payload data, indicator bits, null frames, or errors.
    • Real-Time Frame Decoding: Decoded frames display with ID, payload, header CRC, and cycle info alongside the analog signal.
    • Static/Dynamic Segment Visibility: Identifies static vs. dynamic segment frames for schedule table verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UPO7000L-JITTERJitter Analysis and Eye Diagram Option

    • Jitter Decomposition: Separates RJ, DJ, PJ, DDJ, and DCD for root-cause analysis.
    • Eye Diagram: Statistical eye from serial data for signal quality — eye height, width, mask margin.
    • Bathtub Curve: BER vs. sampling position for link margin prediction.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UPO7000L-PWRAdvanced Power Analysis Option

    • Switching Loss: Calculates energy per switching transition for MOSFETs, IGBTs. Essential for thermal design and efficiency.
    • Safe Operating Area: Plots V×I trajectories against device limits during transients, startup, and faults.
    • Ripple Analysis: Output ripple amplitude and frequency content. Identifies sources: switching frequency, ESR, load transients.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UPO7000L-SENTAutomotive SENT Sensor Bus Trigger and Analysis Option

    • SENT Triggering: Trigger on fast channel data, slow channel messages, or error conditions.
    • Fast and Slow Channel Decoding: Decodes fast channel (primary sensor data) and slow channel (config/diagnostics).
    • Nibble-Level Display: Individual nibble values and timing overlaid on the waveform for SAE J2716 verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More
