MSO8000HD-PSI5 Automotive PSI5 Serial Bus Option

$999.00
Save {price}%

Description

Supports PSI5 bus analysis, a protocol widely used in automotive sensor systems.

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

UNI-T MSO8000HD Options Series

OVERVIEW

DOCUMENTATION

UNI-T MSO8000HD-PSI5 | Automotive Serial Bus Analysis Option

Overview

The UNI-T MSO8000HD-PSI5 option provides comprehensive PSI5 (Peripheral Sensor Interface 5) protocol analysis capabilities, enabling engineers to decode, trigger on, and analyze PSI5 communications used extensively in automotive sensor applications. PSI5 is a specialized two-wire interface standard designed for automotive sensors including pressure sensors, temperature sensors, and position sensors, making this analysis capability essential for modern automotive electronic control unit (ECU) development and validation.

Designed specifically for automotive engineers working with sensor integration, ECU development, and vehicle system validation, the PSI5 option combines advanced protocol decoding with the MSO8000HD's exceptional signal integrity analysis capabilities. This integration enables simultaneous analysis of PSI5 sensor data content and physical layer characteristics, providing complete visibility into both sensor communication and signal quality for robust automotive system development.

UNI-T MSO8000HD Protocol Analysis
Advanced PSI5 protocol analysis for automotive sensor communication validation

Key Features

• Complete PSI5 protocol decoding and sensor data analysis
• Current-modulated communication analysis with precise timing measurements
• Multi-sensor PSI5 bus analysis with individual sensor identification
• Advanced triggering on PSI5-specific events and sensor data patterns
• Sensor synchronization and timing validation capabilities
• Power supply modulation analysis for PSI5 current communication
• Error detection and communication reliability assessment
• Integration with signal integrity analysis for automotive EMC validation
• Protocol search and navigation through extensive PSI5 sensor data
• Automated sensor calibration and configuration analysis
• Temperature compensation and sensor drift analysis capabilities
• Seamless integration with MSO8000HD's automotive analysis ecosystem

Compatibility Information

Compatible Models: MSO8804HD, MSO8504HD

Installation: Software license activation - no hardware modification required

Supported Standards: PSI5 Version 1.3 and 2.1 specifications

Signal Requirements: PSI5 current-modulated signals with power supply monitoring

Bundle Savings Opportunity

This option is included in the MSO8000HD-BND Protocol Analysis & Jitter Suite! Get this capability plus 15 other protocol analysis options and jitter analysis for just $5,399 - saving you $10,583 (66% off) compared to purchasing options individually.

The bundle features perpetual licensing with zero recurring fees, potentially saving $10,000+ over the instrument's lifetime compared to competitors' subscription models.

UNI-T MSO8000HD-PSI5 Analysis Capabilities

Advanced PSI5 Protocol Decoding

The PSI5 option provides sophisticated analysis of the unique current-modulated communication protocol used by PSI5 sensors. Unlike traditional voltage-based communication, PSI5 sensors modulate their supply current to transmit data, requiring specialized analysis techniques to decode sensor information, timing parameters, and communication status.

The analyzer automatically recognizes PSI5 frame structures, decodes sensor data packets, and validates timing relationships essential for proper sensor operation. Advanced current modulation analysis enables precise measurement of communication amplitude, rise/fall times, and signal integrity parameters specific to PSI5's current-based signaling method.

MSO8000HD Signal Integrity Analysis
Precise signal integrity analysis for PSI5 current modulation characteristics

Multi-Sensor Bus Analysis

Automotive applications often utilize multiple PSI5 sensors on a shared bus, requiring sophisticated analysis to distinguish individual sensor communications and validate proper bus arbitration. The PSI5 option provides comprehensive multi-sensor analysis capabilities that track individual sensor identities, monitor communication conflicts, and validate proper timing coordination between multiple sensors.

Advanced sensor synchronization analysis ensures proper timing relationships between sensors, validates synchronization pulse timing, and monitors for communication collisions that could affect sensor data reliability. This capability is essential for complex automotive sensor networks where multiple sensors must operate harmoniously.

Automotive-Specific Sensor Analysis

The PSI5 option includes specialized analysis features tailored for common automotive sensor applications including pressure sensors for engine management, temperature sensors for thermal monitoring, and position sensors for various automotive actuators. The analyzer can decode sensor-specific data formats, validate calibration parameters, and analyze sensor response characteristics.

Temperature compensation analysis enables validation of sensor accuracy across automotive temperature ranges, while drift analysis capabilities help identify long-term sensor stability issues that could affect vehicle performance and reliability. These features are particularly valuable for automotive sensor qualification and production testing.

EMC and Signal Integrity Integration

Automotive environments present unique EMC challenges that can affect PSI5 sensor communication reliability. The integration with MSO8000HD's advanced signal integrity capabilities enables correlation between PSI5 communication errors and EMC events, helping engineers identify and mitigate electromagnetic interference effects on sensor communication.

Professional Applications

Automotive ECU Development and Validation

Validate PSI5 sensor integration in electronic control units across engine management, transmission control, chassis systems, and body electronics. The PSI5 option enables comprehensive analysis of sensor communication timing, data accuracy, and system reliability essential for automotive safety and performance requirements.

Automotive Sensor Development and Testing

Engineers developing PSI5-compatible sensors can utilize the PSI5 option to validate protocol compliance, optimize communication parameters, and ensure robust operation under automotive environmental conditions. The detailed protocol analysis capabilities enable optimization of sensor design for maximum reliability and performance.

Vehicle System Integration and Troubleshooting

Diagnose and resolve PSI5 sensor communication issues in complete vehicle systems, including sensor network validation, EMC troubleshooting, and performance optimization. The comprehensive analysis capabilities enable identification of intermittent sensor issues and validation of sensor network reliability under real-world operating conditions.

Automotive Production Testing and Quality Control

Implement automated PSI5 sensor testing in automotive production environments to ensure consistent sensor communication quality and reliability. The detailed protocol analysis and automated testing capabilities enable high-volume sensor validation with standardized pass/fail criteria essential for automotive quality standards.

Technical Specifications

PSI5 Protocol Support

Parameter Specification
PSI5 Versions PSI5 Version 1.3, PSI5 Version 2.1
Communication Method Current modulation on power supply line
Data Rate 125 kbps, 189 kbps (user-configurable)
Current Modulation 7-14 mA modulation amplitude (typical)
Frame Structure Synchronization, sensor data, status, and error frames
Multi-Sensor Support Up to 3 sensors per PSI5 bus (Version 2.1)

Analysis Capabilities

Feature Description Applications
Current Modulation Analysis Amplitude, timing, and waveform quality measurements Signal integrity validation, EMC analysis
Sensor Data Decoding Automatic decoding of sensor measurement data Sensor calibration, performance validation
Timing Analysis Frame timing, synchronization pulse validation Protocol compliance, timing optimization
Multi-Sensor Coordination Bus arbitration and sensor identification Complex sensor network validation
Error Detection Communication errors, timing violations System reliability assessment

Automotive-Specific Features

Feature Capability
Temperature Compensation Analysis of sensor temperature correction algorithms
Calibration Validation Sensor calibration parameter verification
Sensor Drift Analysis Long-term stability and aging characterization
EMC Correlation Communication reliability under EMC stress conditions
Automotive Environment Testing Performance validation across automotive temperature and voltage ranges

Related Options

Option Synergy with MSO8000HD-PSI5
MSO8000HD-CANFD Complete automotive network analysis combining sensor and CAN communication
MSO8000HD-SENT Comprehensive automotive sensor protocol analysis including SENT and PSI5
MSO8000HD-LA Mixed-signal analysis of PSI5 sensors with digital control and status signals
MSO8000HD-PWR Power supply analysis correlated with PSI5 current modulation effects
MSO8000HD-JITTER Timing analysis for PSI5 synchronization and communication reliability

Installation & Activation

  • Software-only upgrade - no hardware modification required
  • License key provided upon purchase
  • Activation through instrument menu system
  • Immediate functionality after activation
  • Integration with all oscilloscope and automotive analysis capabilities
  • Comprehensive user documentation and PSI5 analysis examples included

Frequently Asked Questions

What makes PSI5 different from other automotive sensor interfaces?

PSI5 uses current modulation on the power supply line rather than voltage-based communication, enabling two-wire sensor connections that reduce harness complexity and cost. The MSO8000HD-PSI5 option includes specialized analysis techniques for current-modulated communication that are not available with standard protocol analyzers.

Can the PSI5 option analyze multiple sensors on the same bus simultaneously?

Yes, the PSI5 option supports analysis of multi-sensor PSI5 buses with up to 3 sensors per bus (PSI5 Version 2.1). The analyzer can distinguish individual sensor communications, track sensor timing coordination, and validate proper bus arbitration between sensors.

How does the option handle PSI5's unique current modulation signaling?

The PSI5 option includes specialized current modulation analysis that measures modulation amplitude, timing characteristics, and signal quality specific to PSI5's current-based communication method. This analysis is essential for validating PSI5 sensor performance and EMC compliance.

Does the PSI5 analysis work with both PSI5 Version 1.3 and 2.1?

Yes, the MSO8000HD-PSI5 option supports both PSI5 Version 1.3 and PSI5 Version 2.1 specifications, including the enhanced multi-sensor capabilities and improved timing specifications introduced in Version 2.1.

Can I correlate PSI5 sensor data with other automotive communication protocols?

Yes, the PSI5 option integrates seamlessly with other MSO8000HD automotive protocol options, enabling correlation between PSI5 sensor data and CAN/CAN-FD network communications, SENT sensor data, and other automotive protocols for complete system analysis.

Is PSI5 analysis included in the bundle package?

Yes, PSI5 analysis is included in the MSO8000HD-BND Protocol Analysis & Jitter Suite. The bundle provides 15 protocol analysis options plus advanced jitter analysis at a single price of $5,399 - saving 66% compared to purchasing options individually. As with all UNI-T software options, the bundle features a perpetual license with zero recurring fees, providing lifetime access without subscription costs that can save $10,000+ over the instrument's lifetime.

Warranty & Support

The MSO8000HD-PSI5 option is covered under UNI-T's Exclusive 3+2 Warranty program when installed on a qualifying MSO8000HD instrument—3 years standard coverage plus an additional 2 years at no charge when you complete our free product registration.

Master Automotive Sensor Communication

The MSO8000HD-PSI5 option provides the specialized analysis capabilities essential for validating PSI5 sensor communications in modern automotive applications. Whether developing new sensor technologies, integrating sensors into ECUs, or troubleshooting automotive sensor networks, this option delivers the insight needed to ensure reliable sensor communication and optimal automotive system performance under demanding automotive environmental conditions.

Ready to analyze your automotive PSI5 sensor systems? Order the MSO8000HD-PSI5 or get it included in the MSO8000HD-BND Complete Suite and save significantly on comprehensive automotive protocol analysis capabilities.
