Compatibility Information
Compatible Models: MSO8804HD, MSO8504HD (planned release)
Installation: Software license activation - no hardware modification required
Supported Protocols: I²S, Left Justified (LJ), Right Justified (RJ), TDM
Channel Support: Up to 32 audio channels in TDM mode
Bundle Savings Opportunity
This option is included in the MSO8000HD-BND Protocol Analysis & Jitter Suite! Get this capability plus 15 other protocol analysis options and jitter analysis for just $5,399 - saving you $10,583 (66% off) compared to purchasing options individually.
The bundle features perpetual licensing with zero recurring fees, potentially saving $10,000+ over the instrument's lifetime compared to competitors' subscription models.
Application Examples
Consumer Electronics Audio Validation
Debug I²S interfaces in smartphones, tablets, and portable audio devices to ensure proper communication between application processors, audio codecs, and amplifiers. Validate sample rate conversion, channel routing, and power management timing to prevent audio glitches and optimize battery life.
Automotive Infotainment Systems
Analyze TDM audio buses in automotive head units and amplifier systems where multiple audio sources must be mixed and routed to various speakers. Validate channel assignments, monitor cross-talk between audio streams, and ensure proper synchronization of navigation prompts, phone calls, and entertainment audio.
Professional Audio Equipment Development
Validate digital audio interfaces in mixing consoles, audio processors, and recording equipment where audio quality is paramount. Analyze Left/Right Justified formats, monitor multi-channel audio routing, and ensure timing precision that maintains professional audio fidelity standards.
Audio Codec and DAC Integration
Troubleshoot communication between digital signal processors and audio converters in high-end audio systems. Validate bit clock generation, word select timing, and data format compatibility to ensure optimal audio performance and prevent compatibility issues between different manufacturers' components.
Frequently Asked Questions
What's the difference between I²S and the justified formats?
I²S delays data by one bit clock for easier processing, Left Justified aligns the MSB with the word select edge for immediate processing, and Right Justified aligns the LSB for compatibility with certain legacy systems. Each format serves different implementation requirements.
How many TDM channels can be analyzed simultaneously?
The MSO8000HD-AUDIO option supports analysis of up to 32 TDM audio channels, making it suitable for complex automotive and professional audio systems with extensive multi-channel requirements.
Can this option detect audio-specific timing violations?
Yes, the option specifically validates timing relationships critical to audio quality, including bit clock stability, word select timing, and data setup/hold requirements that can cause audio artifacts if violated.
Is audio protocol analysis included in bundle packages?
Yes, comprehensive audio protocol analysis is included in the MSO8000HD-BND Protocol Analysis & Jitter Suite. The bundle provides 15 protocol analysis options plus advanced jitter analysis at a single price of $5,399 - saving 66% compared to purchasing options individually. As with all UNI-T software options, the bundle features a perpetual license with zero recurring fees, providing lifetime access without subscription costs that can save $10,000+ over the instrument's lifetime.
Perfect Your Digital Audio Systems
The MSO8000HD-AUDIO option provides the specialized analysis capabilities required for modern digital audio systems where timing precision directly impacts sound quality. Whether developing consumer electronics, automotive infotainment systems, or professional audio equipment, this option delivers the insight needed to ensure flawless audio performance.
Ready to analyze your digital audio interfaces? Order the MSO8000HD-AUDIO or explore the comprehensive MSO8000HD-BND Complete Suite for maximum protocol analysis capability.
