MSO/UPO3000 Options

MSO/UPO3000 serial bus trigger and decode for I²C, SPI, UART, CAN, CAN-FD, LIN, FlexRay, automotive embedded, and communications bundles, plus Bode plot analysis and extended 16-channel logic analyzer module across twelve options shared between the MSO3000CS and UPO3000CS series.

View

  • MSO/UPO3000CS-AUTOSerial Bus Decode Bundle (incl. CAN, CAN-FD, LIN, FlexRay)

    • What's Included: 4 protocols with full trigger, decode, and search: CAN (Controller Area Network) — $236 individually CAN-FD — $236 individually LIN (Local Interconnect Network) — $236 individually FlexRay — $236 individually
    • Save $469 (49% Off): Bundle pricing vs. purchasing individually.
    • Single License Key: One key unlocks all protocols. No managing separate licenses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $475.00
    Learn More

  • MSO/UPO3000CS-BNDDecode Options Bundle (Includes EMBD and Auto)

    • What's Included: 7 protocols with full trigger, decode, and search: CAN (Controller Area Network) — $236 individually CAN-FD — $236 individually RS232/UART — $236 individually I2C — $236 individually SPI — $236 individually LIN (Local Interconnect Network) — $236 individually FlexRay — $236 individually
    • Save $937 (56% Off): Bundle pricing vs. purchasing individually.
    • Single License Key: One key unlocks all protocols. No managing separate licenses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $715.00
    Learn More

  • MSO/UPO3000CS-CANAuto serial bus trigger and analysis-CAN

    • Protocol-Aware Triggering: Trigger on specific CAN conditions — frame ID, data content, error frames, remote frames, or overload frames — to isolate the exact bus activity you're investigating.
    • Real-Time Frame Decoding: Decoded CAN frames (arbitration ID, DLC, data payload, CRC, acknowledge) display directly on the waveform trace for signal-protocol correlation.
    • Deep Memory Protocol Search: Search captured records for specific message IDs, data patterns, or error conditions across the full acquisition memory.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $236.00
    Learn More

  • MSO/UPO3000CS-CAN FDAuto serial bus trigger and analysis-CAN-FD

    • Protocol-Aware Triggering: Trigger on CAN-FD conditions — frame ID, data content, error frames, or bit rate switch events.
    • Real-Time Frame Decoding: Decoded CAN-FD frames display on the waveform trace in real time for protocol-electrical correlation.
    • Deep Memory Protocol Search: Search captured records for specific message IDs, data patterns, or error conditions.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $236.00
    Learn More

  • MSO/UPO3000CS-COMPC serial bus trigger and analysis (RS232/UART)

    • UART/RS232 Triggering: Trigger on data bytes, parity errors, framing errors, or break conditions.
    • Real-Time Frame Decoding: Decoded UART frames display on the waveform with data bytes, parity, and framing identified.
    • Configurable Parameters: Standard baud rates (1200 to 921600+), 5-9 data bits, parity, 1-2 stop bits.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $236.00
    Learn More

  • MSO/UPO3000CS-EMBDSerial Bus Trigger and Decode Option (incl. RS232, UART, I2C, SPI)

    • What's Included: 3 protocols with full trigger, decode, and search: RS232/UART — $236 individually I2C — $236 individually SPI — $236 individually
    • Save $233 (32% Off): Bundle pricing vs. purchasing individually.
    • Single License Key: One key unlocks all protocols. No managing separate licenses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $475.00
    Learn More

  • MSO/UPO3000CS-FlexRayAuto serial bus trigger and analysis-FlexRay

    • FlexRay Triggering: Trigger on frame ID, cycle count, payload data, indicator bits, null frames, or errors.
    • Real-Time Frame Decoding: Decoded frames display with ID, payload, CRC, and cycle info alongside the analog signal.
    • Static/Dynamic Visibility: Identifies static vs. dynamic segment frames for schedule verification.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $236.00
    Learn More

  • MSO/UPO3000CS-I2CEmbedded serial bus trigger and analysis-I2C

    • I2C Triggering: Trigger on start/stop, device addresses, data values, ACK/NAK, or missing acknowledges.
    • Real-Time Decoding: Decoded I2C transactions on the waveform — address (7/10-bit), R/W, data bytes, ACK/NAK status.
    • Bus Contention Detection: Identifies multi-master arbitration events and SDA/SCL conflicts.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $236.00
    Learn More

  • MSO/UPO3000CS-LINAuto serial bus trigger and analysis-LIN

    • LIN Triggering: Trigger on frame IDs, data content, checksum errors, or sync break fields.
    • Real-Time Frame Decoding: Decoded LIN frames (sync, PID, data, checksum) display on the waveform trace.
    • Master-Slave Timing: Shows master header and slave response timing for diagnosing timeouts and schedule issues.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $236.00
    Learn More

  • MSO/UPO3000CS-SPIEmbedded serial bus trigger and analysis-SPI

    • SPI Triggering: Trigger on data patterns on MOSI or MISO, or chip select edges for specific transactions.
    • Simultaneous MOSI/MISO: Decodes both master-out and master-in data in parallel — full-duplex visibility.
    • Configurable Clock Modes: All four SPI modes (CPOL/CPHA combinations) for correct data alignment.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $236.00
    Learn More

  • MSO3000CS-S-BODEBode Plot Option for -S models

    • Automated Bode Plot: Define frequency range and stimulus amplitude. Oscilloscope sweeps, measures, and plots gain and phase.
    • Uses Built-In Generator: Works with the signal generator already in your -S model. No external equipment.
    • Filter/Amplifier Characterization: Verify cutoff, roll-off, passband flatness, and bandwidth.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $299.00
    Learn More

  • UPO3000CS-LA16UPO3000CS/E-LA16 Logic Analyzer Software Option (requires UT-M15)

    • 16 Digital Channels: Parallel bus capture alongside analog channels.
    • Time-Aligned Display: Digital and analog share the same time base for comprehensive debugging.
    • Protocol Correlation: Digital bus activity alongside serial decodes and analog measurements.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $345.00
    Learn More
