UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)

UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
Uni-T UPO2204 200MHz 4Ch MSO (w/o Logic Pod) Isometric Image
Uni-T UPO2204 200MHz 4Ch MSO (w/o Logic Pod) Back Image
UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    Uni-T UPO2204 200MHz 4Ch MSO (w/o Logic Pod) Isometric Image
    Uni-T UPO2204 200MHz 4Ch MSO (w/o Logic Pod) Back Image
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    UPO2204 200MHz 4Ch Mixed Signal Oscilloscope (w/o Logic Pod)
    approvals
    When you need to analyze analog waveforms, the UNI-T UPO2204 is a great choice! Add the UT-M15 to decode digital bus signals.
    200MHz
    Bandwidth
    		 4Ch
    Channels
    2.0GSa/s
    Sample Rate
    		 56Mpts
    Max. Memory Depth
    1,000,000wfms/s
    Waveform Capture Rate
    		 Optional
    Digital Channels
    $1,075.00
    Save {price}%

    26 items in stock

    Includes 5-Year Warranty*

    (click for details) 3 years standard warranty. Get 2 free years when you register your instrument!
    Register today for a 15% EDU Discount
    Find a Distributor

    Guarantee safe & secure checkout

    trust2

    OVERVIEW

    SPECIFICATIONS

    DOCUMENTATION

    OPTIONS
    ACCESSORIES
    UPO2000E-Display

    Digital fluorescent display

    256-level grayscale display capability, timely reflecting the probability of the appearance of the waveform, and the waveform change is clearly visible.

    Excellent storage depth

    Up to 56Mpts storage depth, users can capture longer Time signal without losing waveform details.

    		UPO2000E-Memory
    UPO2000E-Capture

    Up to 80,000wfms/s waveform capture rate

    Up to 80,000wfms/s waveform capture rate, discover occasional problems in time, greatly improve the ability to capture extremely low-probability events, and observe signal jitter and glitches more intuitively

    Independent time base adjustable

    The time base of each channel is independently adjustable, which is convenient for users to observe four channels of frequencies at the same time Significantly different signals

    		 UPO2000E-Base
    UPO2000E-Measures

    Rich data measurement functions

    Support 34 kinds of automatic measurement parameter functions, Support Zoom, Math, statistics and advanced calculation functions.
    Feature Specification
    Model Number UPO2204
    Scope Type MSO
    Bandwidth 200MHz
    Channels 4Ch
    Scope Sample Rate 2.0GSa/s
    Memory Depth 56Mpts
    Refresh Rate 1,000,000wfms/s
    Vertical Scale @1MΩ 500μV/div to 20V/div
    # Automatic Measurements 36
    Included Bus Protocols None
    Optional Bus Protocols RS232 UART I2C SPI CAN CAN-FD LIN FlexRay
    Logic Pod Included Optional
    Signal Generator Function Not Available
    Frequency Meter 7-bit
    Display Size (in) 8in
    Touchscreen Yes
    Warranty 3 years
    Product Dimensions (L x W x H) 15 in x 5 in x 7 in
    Product Weight 10 lb
    Certifications CE/cETLus/UKCA
    Documents English download guide, multi-language safety manual, calibration report (COC)
    Included Accessories Oscilloscope probe (UT-P05)*4
    Standard Accessories Power cord, USB2.0 printing cable
    approvals
    DATA SHEETS and MANUALS
    Click here to download UPO2204 documents
    SOFTWARE/FIRMWARE DOWNLOADS
    Click here to download UPO2204 Software and/or Firmware updates
    2025_Catalog_th
    UNI-T 2025 Instruments Catalog
    2025_SelectionGuide_th
    UNI-T 2025 Instruments Selection Guide
    Need to add specific functionality to your Uni-Trend Mixed Signal Oscilloscope? You're in the right place. Here are our options for specific applications and measurement types. Have a question? Feel free to contact us at
