USG5000-PG

Narrow Pulse Generator Option

$299.00
Sale Contact Us For Lead Time
REQUEST A QUOTE

Narrow pulse generator option that enables generation of pulses as narrow as 20 ns with 10 ns resolution for radar and pulse testing applications with USG5000M/V series generators.

View full details

USG5000-PG Narrow Pulse Generator Option

Overview

The USG5000-PG adds narrow pulse generation for radar, TDR, and applications requiring fast, precisely controlled pulses. The option is enabled by a software license keyed to the RF signal generator's serial number and is permanent for the life of the instrument.

Key Features

  • Narrow Pulses — Precisely controlled width, period, and amplitude.
  • Fast Edges — Sub-nanosecond rise/fall times.
  • Configurable — Width, period, delay, amplitude from front panel or remote.
  • Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.

When You Need This Option

The option fits the following workflows:

  • Radar Testing — Generate narrow pulses to simulate radar returns.
  • TDR Stimulus — Narrow pulses for time-domain reflectometry on cables.

Compatibility

This option is compatible with all USG5000M and USG5000V RF signal generators. The same capability is offered on other UNI-T RF signal generator families: USG3000.

Frequently Asked Questions

How is this option activated?

The option is enabled by a software license keyed to the RF signal generator's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the RF signal generator from a USB drive through the option-install menu. Refer to the RF signal generator's user manual for the step-by-step procedure.

Is the license permanent, or does it require renewal?

The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
