UTE310H 1000V High-Performance Digital Power Meter

UNI-T UTE310H AC/DC Power Meter

As energy-efficiency standards evolve, engineers face growing pressure to enhance the performance of both consumer and industrial equipment. From household appliances to large-scale industrial systems, optimizing energy-saving features is crucial in staying competitive. The UNI-T UTE310H AC/DC Power Meter is the ultimate tool for precise energy measurement and analysis, designed to meet the rigorous demands of professional engineers working with high-power applications. With its high accuracy, extensive measurement range, and versatile features, the UTE310H ensures engineers can confidently assess and improve energy efficiency across various heavy-duty applications.

UNI-T UTE310H Overview

The UNI-T UTE310H is a high-accuracy digital power meter offering top-tier performance for measuring voltage, current, and power in demanding high-power environments. With a 4.3-inch full-color display and advanced waveform visualization, this tool provides a streamlined user experience. The wide measurement range (10mA–50A / 75mV–1000V) and broad 300kHz bandwidth make the UTE310H perfect for R&D, testing, and production environments requiring higher power measurements.

This power meter excels in assessing DC and single-phase AC systems, high-power household appliances, industrial machinery like frequency converters and large air conditioners, and other applications requiring measurements of larger currents and voltages.

Key Specifications

• AC and DC voltage: 15V, 30V, 60, 150V, 300V, 600V, 1000V
• AC and DC current: 1A, 2A, 5A, 10A, 20A, 50A
• AC and DC power: 15W–50000W
• Frequency Measurement: 0-300kHz
• Integration power: 0–10000 hours
• Four operations: A+B, A-B, AxB, A/B, A/B^2, A^2/B
• RMS measurement range: 10mA–50A / 75mV–1000V
• Highest resolution: 1mV/0.1uA/0.001mW
• Basic accuracy of voltage, current and power: 0.1%
• Measurement bandwidth: DC, 0.1Hz–300kHz
• Sampling rate: 1MHz
• Rich communication interfaces: USB, GPIB, LAN
• Supports both Modbus and SCPI communication protocols
• Display wave function: Voltage, current
• 50th harmonic measurement (Supports IEC61000-4-7 standard, 50th harmonic analysis)
• Rich math operations
• D/A output for measurement recording
• Comparator function
• Memory: USB data storage
• Display: 4.3" TFT-LCD resolution 480*272
• Warranty: 5 Years (with free registration)

UTE310H Benefits for Engineers

4.3-inch LCD Display

A vivid 4.3-inch full-color TFT LCD allows you to view three display interfaces simultaneously, providing more parameter information in a single glance. This large, crisp display reduces the need for multiple tools and enhances overall efficiency during testing and analysis.

Enhanced Power Range (15W-50000W)

The UTE310H features an impressive power measurement range from 15W up to 50000W, making it ideal for industrial applications and high-power equipment testing. This extended range allows engineers to work with much larger systems without the need for additional equipment or workarounds.

Higher Voltage and Current Capabilities

With expanded voltage measurements up to 1000V and current measurements up to 50A, the UTE310H is equipped to handle industrial-grade power systems and high-current applications that would exceed the capabilities of standard power meters.

300kHz Bandwidth

The UTE310H boasts a 300kHz bandwidth, allowing you to capture higher-frequency signals even in high-power environments. This ensures your measurements are comprehensive and able to handle a wide range of signals for diverse applications, from high-performance R&D environments to complex industrial testing.

50th Harmonic Measurement

Engineers can analyze up to the 50th harmonic, fully supporting IEC61000-4-7 standards. This is especially crucial when analyzing high-power equipment that produces harmonic distortion, such as industrial motors or large power converters. The built-in harmonic analysis provides vital insights into system performance and efficiency.

Real-Time Waveform Display

The UTE310H offers real-time waveform visualization of voltage and current, helping engineers quickly identify abnormalities in high-power systems. With automatic peak-to-peak value measurement, engineers can better understand dynamic behaviors and ensure industrial systems meet desired specifications.

External Input

For applications requiring even higher voltages or currents beyond the UTE310H's already impressive range, external sensors can be connected, further extending its measurement capabilities. This feature makes the UTE310H adaptable to the broadest spectrum of engineering tasks, from the most demanding industrial systems to specialized high-power applications.

Integral Function

The power meter's integral function supports both average active power and current integration, which is essential for long-term power consumption testing in high-power industrial environments. This is crucial for R&D engineers focused on optimizing energy-saving technologies and improving overall efficiency in industrial-scale systems.

D/A Output for Real-Time Control

The UTE310H's D/A output enables real-time communication with industrial control systems. By sending measured values directly to a test platform, engineers can make real-time adjustments, monitor high-power performance, and automate controls for superior management of industrial-scale systems.

Applications

The UNI-T UTE310H is specifically designed for engineers working with high-power systems -

• Industrial Equipment: Comprehensive power analysis for large-scale industrial machinery, motors, frequency converters, and heavy-duty air conditioning systems.
• Power Generation: Monitor and analyze performance in power generation equipment and distribution systems.
• High-Power Home Appliances: Precise power measurements for industrial and commercial heating systems, large air conditioners, and high-power induction equipment.
• Energy-Saving Technologies: Analyze the performance of industrial-grade LEDs, high-capacity power supplies, and large battery systems.
• Manufacturing Equipment: Monitor power consumption and efficiency in production line equipment and heavy machinery.

With its extended measurement capabilities, high precision, and specialized features for high-power applications, the UNI-T UTE310H is an indispensable tool for electrical engineers working with industrial-grade equipment and systems where standard power meters would be insufficient.
