UT196

Solar Pro TRMS Multimeter

$228.00
Sale Contact Us For Lead Time

52 in stock

REQUEST A QUOTE

True RMS multimeter rated to 1700V DC / 1500V AC, CAT III 1000V/CAT IV 600V. Purpose-built for solar installers and PV maintenance professionals.

View full details

UNI-T UT196 Solar PV True-RMS Multimeter

Overview

The UT196 is a True-RMS multimeter built for photovoltaic work, rated to 1700 V DC and 1500 V AC with CAT III 1000 V / CAT IV 600 V safety — the voltage headroom string and combiner measurements need. It's sealed to IP65 and survives a 2 m drop, with a dual display, analog bar graph, and built-in flashlight for rooftop and outdoor use.

True-RMS reads AC accurately on distorted waveforms, a low-pass filter helps on inverter outputs, and an optional clamp sensor extends AC current measurement to 3000 A. Non-contact voltage detection, resistance to 60 MΩ, and capacitance to 60 mF round out the field set. It's backed by UNI-T's nearly 40 years of test-meter manufacturing.

Key Features

  • Rated 1700 V DC / 1500 V AC for PV strings and combiners
  • True-RMS measurement with dual display and analog bar graph
  • CAT III 1000 V / CAT IV 600 V safety rating
  • IP65 sealing and 2 m drop protection
  • AC current to 3000 A with optional clamp sensor
  • Low-pass filter (LPF) for inverter outputs
  • Non-contact voltage (NCV) detection
  • Resistance to 60 MΩ; capacitance to 60 mF; built-in flashlight

UT196 Details

Built for PV Voltages

Photovoltaic strings sit well above ordinary mains levels. The UT196 measures up to 1700 V DC and 1500 V AC, so string and combiner voltages stay on-scale and within the meter's safety rating.

True-RMS & Inverter Work

True-RMS sensing keeps AC accurate on the distorted waveforms around inverters, and a low-pass filter strips high-frequency content to read the fundamental on an inverter output.

Field-Sealed Build

An IP65-sealed body and 2 m drop rating handle rooftops and outdoor arrays, while a dual display, analog bar graph, and built-in flashlight keep readings clear in the field.

Extended Current & Safety

An optional clamp sensor extends AC current measurement to 3000 A for string and feeder work, and non-contact voltage detection flags live conductors before you probe.

Applications

Solar PV installation and commissioning; string, combiner, and inverter measurement; rooftop and ground-mount maintenance; and outdoor electrical work where high DC voltage, sealing, and drop resistance matter.

Frequently Asked Questions

Why does the UT196 measure to 1700 V DC?

Photovoltaic strings operate well above ordinary mains voltage; the 1700 V DC range keeps string and combiner measurements within the meter's safety rating.

Is it suitable for outdoor use?

Yes — it is IP65-sealed, rated for a 2 m drop, and has a built-in flashlight for low-light work.

Can it measure high current?

Yes — AC current up to 3000 A with an optional clamp sensor.

Warranty

This product includes a standard 1-year warranty covering manufacturing defects and component failures under normal use conditions.

UNI-T stands behind every product we sell. If you experience any issues within the warranty period, our US-based support team is here to help with troubleshooting, repair, or replacement.
