UPO1002X-1MT2M 200MHz Bandwidth Upgrade
Overview
The UPO1002X-1MT2M upgrades your UPO1102 from 100MHz to 200MHz bandwidth — capturing faster edges and higher-frequency content without replacing the instrument. The upgrade is a software license key; the hardware already supports 200MHz.
A 100MHz oscilloscope faithfully reproduces signals up to roughly 100MHz. Clock signals, digital buses, or switching transients with content above that are attenuated — rounded edges, reduced amplitude. Upgrading to 200MHz gives you the headroom to see what's actually happening.
Key Features
- 100MHz → 200MHz Bandwidth — Upgrades all analog channels on your UPO1102.
- Faster Rise Times — Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
- No Hardware Changes — Bandwidth is software-defined. Enter the key and operate at 200MHz immediately.
- Instant Activation — System → Options → Install. No reboot, no factory calibration.
- Investment Protection — Start with a lower bandwidth at a lower price, upgrade as requirements grow.
When You Need This
Growing Requirements
A new project needs more than 100MHz bandwidth. Upgrade instead of buying a new oscilloscope.
Signal Integrity
Compliance testing requires capturing fast edges accurately. The 200MHz upgrade gives you bandwidth to see the true signal shape.
Compatible Instruments
This upgrade applies only to the UPO1102 (100MHz). Not needed if your instrument already has 200MHz bandwidth or higher.
Other Bandwidth Upgrades
No other bandwidth upgrades for this series.
Frequently Asked Questions
Which model does this apply to?
Exclusively the UPO1102 (100MHz). If your instrument already has 200MHz bandwidth or higher, this upgrade is not needed.
Does bandwidth affect sample rate or memory?
No. Sample rate and memory depth are unchanged. Only analog bandwidth is unlocked.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
