MSO7000X-BW-10T20

MSO7000X-BW-10T20 – Bandwidth Upgrade: 1GHz → 2GHz

🚀 Double Your Oscilloscope’s Bandwidth, Expand Your Visibility

The MSO7000X-BW-10T20 unlock enables a bandwidth upgrade from 1GHz to 2GHz on supported UNI-T MSO7000X Series oscilloscopes. This powerful software-based enhancement unleashes the full hardware performance of your instrument—instantly expanding its ability to capture high-speed signals, fast transients, and intricate edge transitions without distortion.

Ideal for high-speed digital validation, RF envelope analysis, advanced serial protocol debugging, and next-gen power systems, this upgrade prepares your MSO7000X for tomorrow’s signal integrity challenges.

📈 Upgrade Details

This upgrade is license-based. No hardware changes or recalibration are required.

🧠 Real-World Use Cases

✅ High-Speed Serial Bus Validation

Decode and verify ultra-fast signals such as USB 2.0, LVDS, HDMI, or MIPI interfaces. Ensure timing margins and rise/fall performance meet protocol specs.

✅ Advanced Power Device Characterization

Capture fast-switching GaN or SiC device waveforms with greater clarity. Analyze dv/dt, current spikes, and EMI-critical behavior.

✅ Signal Integrity & Crosstalk Debugging

Observe high-frequency ringing, reflections, or transmission line mismatches that 1GHz bandwidth might otherwise mask.

✅ RF and Mixed-Domain Measurements

Expand measurement fidelity for radar pulse analysis, envelope tracking, or digital modulation schemes.

🔧 Benefits of Upgrading

• Double the frequency coverage without replacing your hardware
• Maximize the value of your MSO7104X investment by accessing MSO7204X-class performance
• Enhanced edge resolution for jitter, crosstalk, or glitch detection
• No downtime — activation is software-based and instantaneous

📌 Compatibility

• This unlock is valid only for MSO7104X (1GHz) models
• Once applied, the scope becomes equivalent to the MSO7204X (2GHz)

🔗 Related Unlock Options

• ✅ MSO7000X-JITTER → – Jitter and Eye Diagram analysis benefits from higher bandwidth
• ✅ MSO7000X-PWR → – Power analysis tools for GaN/SiC switch testing
• ✅ MSO7000X-LA → – 16-channel digital capture for timing correlation

📋 Summary of Unlockable Features – MSO7000X Series

Standard protocols included: RS-232/UART, I²C, SPI, CAN, LIN
Optional unlocks:

• MSO7000X-BW-10T20 – This page
• MSO7000X-AERO – MIL-STD-1553 & ARINC 429
• MSO7000X-AUDIO – I2S, LJ, RJ, TDM
• MSO7000X-CANFD – CAN FD
• MSO7000X-FLEX – FlexRay
• MSO7000X-SENT – SENT
• MSO7000X-PWR – Power analysis tools
• MSO7000X-JITTER – Jitter and eye diagram
• MSO7000X-AWG – Arbitrary waveform generator
• MSO7000X-LA – 16-channel logic analyzer
• MSO7000X-BND – Complete protocol bundle (bandwidth upgrade not included)
