MSO5000HD-BW5MT1G 1GHz bandwidth upgrade
Overview
The MSO5000HD-BW5MT1G upgrades your MSO5054HD from 500MHz to 1GHz bandwidth — capturing faster edges and higher-frequency content without replacing the instrument. The upgrade is a software license key; the hardware already supports 1GHz.
A 500MHz oscilloscope faithfully reproduces signals up to roughly 500MHz. Clock signals, digital buses, or switching transients with content above that are attenuated — rounded edges, reduced amplitude. Upgrading to 1GHz gives you the headroom to see what's actually happening.
Key Features
- 500MHz → 1GHz Bandwidth — Upgrades all analog channels on your MSO5054HD.
- Faster Rise Times — Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
- No Hardware Changes — Bandwidth is software-defined. Enter the key and operate at 1GHz immediately.
- Instant Activation — System → Options → Install. No reboot, no factory calibration.
- Investment Protection — Start with a lower bandwidth at a lower price, upgrade as requirements grow.
When You Need This
Growing Requirements
A new project needs more than 500MHz bandwidth. Upgrade instead of buying a new oscilloscope.
Signal Integrity
Compliance testing requires capturing fast edges accurately. The 1GHz upgrade gives you bandwidth to see the true signal shape.
Compatible Instruments
This upgrade applies only to the MSO5054HD (500MHz). Not needed if your instrument already has 1GHz bandwidth or higher.
Other Bandwidth Upgrades
Other MSO5000HD bandwidth upgrades: MSO5000HD-BW3M5T5M 500MHz bandwidth upgrade (350MHz → 500MHz for MSO5034HD), MSO5000HD-BW3M5T1G 1GHz bandwidth upgrade (350MHz → 1GHz for MSO5034HD).
Explore Other MSO5000HD Options
- MSO5000HD-BND Complete Serial Analysis Bundle — $1,369
- MSO5000HD-PWR Advanced Power Analysis — $829
- MSO5000HD-AWG Dual Channel 50MHz Arbitrary Waveform Generator with Bode Plot Analysis — $279
- MSO5000HD-AUTO Automotive CAN-FD, CAN-XL, FLEX and SENT Serial Bus Trigger and Analysis — $829
- MSO5000HD-BW3M5T5M 500MHz bandwidth upgrade — upgrade 350MHz → 500MHz
Frequently Asked Questions
Which model does this apply to?
Exclusively the MSO5054HD (500MHz). If your instrument already has 1GHz bandwidth or higher, this upgrade is not needed.
Does bandwidth affect sample rate or memory?
No. Sample rate and memory depth are unchanged. Only analog bandwidth is unlocked.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
