USG3000 Options

These options are the same for our USG3000M and USG3000V series RF Generators

View

  • USG3000-GPIBGPIB Adapter Option

    • GPIB Interface: IEEE 488.2 connectivity for remote control.
    • SCPI Support: Full SCPI command set over GPIB.
    • ATE Integration: Connect to automated test platforms.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $359.00
    Learn More

  • USG3000-PGNarrow Pulse Generator Option

    • Narrow Pulses: Precisely controlled width, period, and amplitude.
    • Fast Edges: Sub-nanosecond rise/fall times.
    • Configurable: Width, period, delay, amplitude from front panel or remote.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $229.00
    Learn More

  • USG3000-PKPower Meter Option

    • Power Measurement: Measures output power on the generator directly.
    • Line Loss Calibration: Compensates for cable/connector losses.
    • Accurate Level at DUT: Signal level at the DUT matches configured output regardless of losses.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $599.00
    Learn More

  • USG3000-PMPulse Modulation Option

    • Pulse Modulation: Configurable pulse width, period, and duty cycle.
    • Internal/External Trigger: Pulse timing from internal generator or external sync.
    • Fast On/Off Ratio: Clean edges and deep off-state suppression.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $399.00
    Learn More
