MSO3000HD-AUTO

$689.00
Save {price}%

Description

Add Automotive Serial Bus Trigger and Decode Options (CAN, CAN-FD, LIN, FlexRay, SENT) to your MSO3000HD

Top Specifications

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

OVERVIEW

DOCUMENTATION

MSO3000HD-AUTO – Automotive Protocol Decode Bundle

πŸš— Unlock a Complete Toolkit for Vehicle Bus Debugging

The MSO3000HD-AUTO bundle unlocks five of the most important automotive serial protocols for your UNI-T MSO3000HD Series oscilloscope. Instead of purchasing each protocol individually, this bundle gives you instant access to a full suite of automotive-focused decoding toolsβ€”optimized for modern vehicles, EV platforms, and advanced driver-assistance systems (ADAS).

Whether you’re working on sensors, ECUs, gateways, or body control modules, this bundle equips you to decode and analyze every communication bus that matters in today’s automotive networks.


βœ… Included Protocols with the MSO3000HD-AUTO Bundle

Protocol Description & Example Application
MSO3000HD-CAN Classic CAN Bus – used in nearly all vehicles for ECU communications
MSO3000HD-CAN-FD CAN FD (Flexible Data Rate) – next-gen automotive bus for high-speed data
MSO3000HD-LIN Local Interconnect Network – used in lighting, seats, and sensors
MSO3000HD-FLEX FlexRay – high-speed, deterministic bus for brake-by-wire and steering systems
MSO3000HD-SENT Single Edge Nibble Transmission – for digital sensor communication

🧠 All included options are available separately. View individual pages for detailed use cases and feature lists.


πŸ” Why Choose the AUTO Bundle?

βœ… Best Value

Unlock five protocols at once for less than buying them individually.

βœ… Streamlined Activation

One license key covers all five optionsβ€”no multiple codes or installations to manage.

βœ… Bench-Ready for Every Vehicle Project

Whether you're working on ADAS, infotainment, or powertrain control, this bundle ensures you're always equipped.

βœ… Optimized for Multi-Bus Systems

Decode and correlate messages across multiple buses simultaneously, with time-aligned views for system-level debugging.


🧠 Real-World Use Cases

  • Validate ECU communication across CAN and CAN FD domains

  • Debug LIN-based body control modules like mirrors, windows, and HVAC

  • Analyze sensor data streams over SENT for throttle, pressure, or temp inputs

  • Test FlexRay gateways for time-synchronized ADAS coordination

  • Equip a lab or vehicle teardown bench for full protocol visibility


πŸ› οΈ Perfect for:

  • Tier 1 automotive suppliers

  • Electric vehicle system designers

  • ADAS & control system developers

  • Gateway, ECU, or sensor manufacturers

  • Embedded engineering educators


πŸ”— Related Unlock Options


πŸ“‹ Unlockable Feature Summary – MSO3000HD Series

Included (Standard):
βœ” RS-232 / UART
βœ” IΒ²C
βœ” SPI

MSO3000HD-AUTO Includes:
βœ” MSO3000HD-CAN
βœ” MSO3000HD-CAN-FD
βœ” MSO3000HD-LIN
βœ” MSO3000HD-FLEX
βœ” MSO3000HD-SENT

Other Available Unlocks:

  • MSO3000HD-AUDIO

  • MSO3000HD-MIL1553

  • MSO3000HD-ARINC429

  • MSO3000HD-MANCH

  • MSO3000HD-PWR

  • MSO3000HD-AWG

  • MSO3000HD-BND
