MSO3000HD-BW2MT5M

$1,599.00
Save {price}%

Description

Push your MSO3024HD to top speed with this 500MHz Bandwidth Upgrade

Top Specifications

Register today for a 15% EDU Discount

Guarantee safe & secure checkout

trust2

OVERVIEW

DOCUMENTATION

MSO3000HD-BW2MT5M – Bandwidth Upgrade (200 MHz → 500 MHz)

🚀 Expand Your Frequency Reach and Diagnostic Power

The MSO3000HD-BW2MT5M unlock boosts the analog bandwidth of your eligible 200 MHz UNI-T MSO3000HD oscilloscope to a full 500 MHz, delivering high-speed visibility for today’s fastest embedded systems, switching converters, and serial buses.

With deeper insight into rising edges, overshoot, harmonics, and clocking noise, this upgrade makes your scope ready for next-gen signal integrity and power electronics design.

⚠️ Compatible only with MSO3000HD models originally configured at 200 MHz.


🧩 What You Unlock with 500 MHz Bandwidth

Feature What It Enables
Higher Frequency Capture Measure signals up to 500 MHz with accuracy. 📌 Ideal for fast switching and digital clocks.
Sharpened Edge Resolution Improved rise-time detection—capture faster transitions and glitches. 📌 Crucial for timing-critical debug.
Advanced Harmonic Insight Analyze high-order components and spectral distortion. 📌 Used in RF, PWM, and EMI testing.
Support for High-Speed Buses Validate and time-align high-frequency I/O. 📌 Suitable for DDR, SPI, and power switch monitoring.

🧠 Real-World Use Cases

SiC / GaN Power Switching

Capture fast transitions with 1 ns rise times and characterize energy loss with precision.

Clock Distribution Debug

Trace high-speed clocks or PLL outputs in embedded systems and MCUs above 100 MHz.

Mixed Signal Bus Validation

Analyze SPI or memory buses with sharp edges and timing glitches. Compare analog noise with digital behavior.

EMC Pre-Compliance

Observe harmonic profiles of switch-mode power supplies or microcontroller boards up to the 10th harmonic range.


🔧 Technical Comparison

Feature 200 MHz Model With Upgrade (500 MHz)
-3 dB Bandwidth 200 MHz 500 MHz
Rise Time (typical) ~1.75 ns ~700 ps
Viewable Harmonics 3rd–5th 5th–10th+
Signal Fidelity Moderate High edge accuracy & detail

🎯 Why Upgrade?

  • Expand diagnostic headroom for faster signal types

  • Eliminate the need for an external higher-bandwidth scope

  • Improve waveform fidelity and overshoot detection

  • Future-proof your bench for evolving design needs


🔐 Software-Based Activation

No shipping. No downtime. Just enter your license key to unlock instantly.
