MSO3000HD-BW2MT3M5 350MHz Bandwidth Upgrade
Overview
The MSO3000HD-BW2MT3M5 upgrades your MSO3024HD from 200MHz to 350MHz bandwidth — capturing faster edges and higher-frequency content without replacing the instrument. The upgrade is a software license key; the hardware already supports 350MHz.
A 200MHz oscilloscope faithfully reproduces signals up to roughly 200MHz. Clock signals, digital buses, or switching transients with content above that are attenuated — rounded edges, reduced amplitude. Upgrading to 350MHz gives you the headroom to see what's actually happening.
Key Features
- 200MHz → 350MHz Bandwidth — Upgrades all analog channels on your MSO3024HD.
- Faster Rise Times — Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
- No Hardware Changes — Bandwidth is software-defined. Enter the key and operate at 350MHz immediately.
- Instant Activation — System → Options → Install. No reboot, no factory calibration.
- Investment Protection — Start with a lower bandwidth at a lower price, upgrade as requirements grow.
When You Need This
Growing Requirements
A new project needs more than 200MHz bandwidth. Upgrade instead of buying a new oscilloscope.
Signal Integrity
Compliance testing requires capturing fast edges accurately. The 350MHz upgrade gives you bandwidth to see the true signal shape.
Compatible Instruments
This upgrade applies only to the MSO3024HD (200MHz). Not needed if your instrument already has 350MHz bandwidth or higher.
Other Bandwidth Upgrades
Other MSO3000HD bandwidth upgrades: MSO3000HD-BW2MT5M 500MHz Bandwidth Upgrade (200MHz → 500MHz for MSO3024HD), MSO3000HD-BW3M5T5M 500MHz Bandwidth Upgrade (350MHz → 500MHz for MSO3034HD).
Explore Other MSO3000HD Options
- MSO3000HD-BND Serial Bus Trigger and Decode Options Bundle (Includes AUTO, AUDIO, MIL-STD, ARINC429, MANCH) — $1,109
- MSO3000HD-PWR Power Analysis Option — $829
- MSO3000HD-AWG Arbitrary Waveform Generator option — $279
- MSO3000HD-AUTO Automotive Serial Bus Trigger and Decode Options Bundle (CAN, CAN-FD, LIN, FlexRay, SENT) — $689
- MSO3000HD-BW2MT5M 500MHz Bandwidth Upgrade — upgrade 200MHz → 500MHz
Frequently Asked Questions
Which model does this apply to?
Exclusively the MSO3024HD (200MHz). If your instrument already has 350MHz bandwidth or higher, this upgrade is not needed.
Does bandwidth affect sample rate or memory?
No. Sample rate and memory depth are unchanged. Only analog bandwidth is unlocked.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
