UPO2000-LA16 Logic Analyzer Software Option (requires UT-M15)
Overview
The UPO2000-LA16 enables 16 digital channels for mixed-signal analysis — digital bus states time-aligned with analog waveforms. Requires UT-M15 or UT-M26 logic probe pod (sold separately).
See analog signals and digital bus states on the same time base. Essential for microprocessor, FPGA, and parallel bus debugging.
Key Features
- 16 Digital Channels — Parallel bus capture alongside analog channels.
- Time-Aligned Display — Digital and analog share the same time base for comprehensive debugging.
- Protocol Correlation — Digital bus activity alongside serial decodes and analog measurements.
- Requires Probe Pod — UT-M15 or UT-M26 connects to the digital input port. License enables the channels; probe captures signals.
- Software License Activation — License key via instrument menu. No hardware changes.
When You Need This
Microprocessor Debug
Capture address/data bus on digital channels while probing power and clocks on analog.
FPGA Interface
Verify parallel data bus timing between FPGA and peripherals.
Compatible Instruments
This option is compatible with MSO/UPO2000 Series oscilloscopes.
Own a Different Instrument?
Need 16-channel logic analyzer on a different oscilloscope? These series also offer it: MSO7000X, MSO8000HD.
Frequently Asked Questions
Do I need the probe pod separately?
Yes. The LA license enables 16 digital channels in software. The UT-M15 or UT-M26 probe pod (sold separately) provides the physical connections.
How is this option activated?
You receive a license key after purchase. Enter the key in the instrument's menu under System → Options → Install. The capability is available immediately — no reboot, no hardware modification, no factory service required.
Is the license permanent or subscription-based?
All UNI-T software option licenses are permanent, one-time purchases. Once activated, the option remains available for the life of the instrument. No annual renewals or subscription fees.
