MSO7000X-LA

MSO7000X-LA – 16-Channel Logic Analyzer Unlock

🔌 Expand into Mixed Signal Debug with Digital Channel Capture

The MSO7000X-LA unlock enables 16 digital channels on UNI-T’s MSO7000X Series oscilloscopes when paired with the optional UT-M15 logic probe. This transforms your instrument into a powerful mixed signal oscilloscope (MSO) capable of capturing and analyzing analog and digital signals simultaneously, time-correlated on a single screen.

From embedded microcontroller buses to FPGA GPIO debug, this upgrade is essential for engineers needing full visibility across analog and digital domains without juggling multiple instruments.

🧠 Real-World Use Cases

✅ Embedded System Debugging

Probe GPIOs, chip selects, address lines, and interrupt signals from microcontrollers, SoCs, and peripheral devices. Correlate logic activity with analog power events or waveforms.

✅ Parallel Bus Inspection

Capture byte-wide or nibble-wide buses with clear bit labeling and time-aligned analog overlays. Validate handshakes, read/write timing, and bus contention.

✅ Trigger + Decode Mixed Buses

Use digital channels to capture I²C, SPI, UART, CAN, or other buses, and decode them in parallel with analog waveform activity. Great for logic analysis under system-level events.

✅ FPGA & CPLD Debug

Test custom logic designs, edge transitions, state machines, and timing diagrams directly from internal signal outputs.

🔧 Features & Capabilities

• 16 digital inputs (D0–D15) with grouped threshold controls
• Sampling rate up to 1.25 GSa/s with deep 100 Mpts memory
• Adjustable logic thresholds for TTL, CMOS, ECL, LVDS, and custom levels
• Trigger on digital patterns, edge sequences, setup/hold conditions, and more
• Mixed-domain display with analog/digital correlation and color-coded bus views
• Search and navigate across deep digital data captures quickly

📦 Requirements

• MSO7000X-LA software license (this page)
• UT-M15 logic analyzer probe (sold separately)

🛠️ Ideal Applications

• Microcontroller and SoC-based design validation
• Digital/analog interaction debugging
• FPGA and CPLD logic development
• Serial bus signal integrity and bit-level validation
• Education and training in embedded systems

🔗 Related Unlock Options

• ✅ MSO7000X-AWG → – Add waveform generation for stimulus-response testing
• ✅ MSO7000X-JITTER → – Add jitter and eye diagram tools for clock edge analysis
• ✅ MSO7000X-BND → – Add protocol decode capabilities to complement digital channels

📋 Summary of Unlockable Features – MSO7000X Series

Standard protocols included: RS-232/UART, I²C, SPI, CAN, LIN
Optional unlocks:

• MSO7000X-LA – This page
• MSO7000X-AERO – MIL-STD-1553 & ARINC 429
• MSO7000X-AUDIO – I2S, LJ, RJ, TDM
• MSO7000X-CANFD – CAN FD
• MSO7000X-FLEX – FlexRay
• MSO7000X-SENT – SENT
• MSO7000X-PWR – Power analysis tools
• MSO7000X-JITTER – Jitter and eye diagram
• MSO7000X-AWG – Arbitrary waveform generator
• MSO7000X-BND – Complete protocol bundle
