UT-P21 50MHz 1000:1 High Voltage Oscilloscope Probe
Overview
50MHz (-3dB) high-voltage passive probe (1000:1 attenuation) for measuring power supply rails, inverters, and high-voltage circuits up to several kV. Compatible with UNI-T oscilloscopes and most oscilloscopes with BNC inputs.
Key Features
- 50MHz (-3dB) Bandwidth — Captures signal content up to 50MHz for accurate waveform measurement.
- 1000:1 Attenuation — Attenuation ratio suited to the probe measurement range.
- DC 15kV / AC 10kV rms Maximum Input Voltage — Rated input voltage for safe operation.
- Standard BNC Connection — Compatible with UNI-T oscilloscopes and most oscilloscopes with BNC inputs.
Warranty
This product includes a standard 1-year warranty covering manufacturing defects and component failures under normal use conditions.
UNI-T stands behind every product we sell. If you experience any issues within the warranty period, our US-based support team is here to help with troubleshooting, repair, or replacement.
| Analog Bandwidth | 50MHz |
|---|---|
| Attenuation | 1000:1 |
| Instrument Type | Passive Probe |
Full specifications (13)
| Details | |
|---|---|
| Max Input Voltage | DC 15kV / AC 10kV rms |
| Input Capacitance | 3.0pF |
| Input Resistance | 100MΩ |
| Compensation Range | 5pF-50pF |
| Connector Type | BNC |
| Cable Length | 200cm |
| Rise Time | ≤7ns |
| Features | |
| Storage Temperature | -20°C - 70°C |
| General Information | |
| Operating Temperature | 0°C - 50°C |
| Dimensions (W×H×D) | Φ75mm×340mm |
| Weight | 250 g |
| Warranty | 1 year |
| Certifications | CE |
