UNI-T MSO1000HD Series vs DHO900 Series
Compact 12-bit HD scopes — the MSO1000HD carries twice the memory and twice the sample rate, with a 5-year warranty.
The UNI-T MSO1000HD Series and the Rigol DHO900 Series are compact 12-bit HD oscilloscopes on a 7-inch touchscreen, and both carry 16 digital channels in the instrument that need an optional logic pod — the UT-M26 on the UNI-T, the PLA2216 on the Rigol. The MSO1000HD leads on acquisition: 100 Mpts of memory against 50, and a 2.5 GSa/s sample rate against 1.25, with an Exclusive 3+2 (5-year) warranty. The DHO900 quotes a higher UltraAcquire capture rate. Match the two by bandwidth below.
Both are 12-bit (16-bit with enhanced resolution), 7-inch touchscreen oscilloscopes aimed at compact embedded and education benches, and logic is an optional pod on both. The MSO1000HD adds deeper memory and a faster sample rate; the DHO900 leads on headline waveform-capture rate and lists a basic AWG on its -S models.
Match the models by bandwidth
| Bandwidth | Channels | UNI-T model | Rigol |
|---|---|---|---|
| 150 MHz | 4+16 | UNI-T MSO1154HD | DHO914 (125 MHz) |
| 150 MHz | 4+16 | UNI-T MSO1154HD-S | DHO914S (125 MHz, +AWG) |
| 250 MHz | 4+16 | UNI-T MSO1254HD · Compare › | DHO924 |
| 250 MHz | 4+16 | UNI-T MSO1254HD-S | DHO924S (+AWG) |
Both families carry 16 digital channels as standard hardware and both need an optional logic pod to use them (UT-M26 on the MSO1000HD, PLA2216 on the DHO900). DHO900 bandwidths are 125 and 250 MHz. UNI-T prices are shown live from each product page.
Series-level comparison
| Feature | UNI-T MSO1000HD | DHO900 Series | Advantage |
|---|---|---|---|
| Vertical resolution | 12-bit native; 16-bit with ERES | 12-bit native; 16-bit (HiRes) | Equal |
| Logic analysis | 16 digital channels standard; UT-M26 pod optional | 16 digital channels standard; PLA2216 pod optional | Equal |
| Max sample rate | 2.5 GSa/s (1-ch) | 1.25 GSa/s | UNI-T ✓ |
| Acquisition memory | 100 Mpts | 50 Mpts | UNI-T ✓ |
| Waveform capture rate | 200,000 wfms/s (1,000,000 sequence) | up to 1,000,000 wfms/s (UltraAcquire) | Rigol ✓ |
| Standard serial decode | 7 protocols incl CAN-FD, Audio | 6 protocols; CAN-FD & FlexRay optional | UNI-T ✓ |
| Warranty | 3+2 years (5 total with registration) | 3 years | UNI-T ✓ |
| Price (250 MHz, 4-ch) | See current price → | ~$769 (DHO924) | Rigol ✓ |
Twice the memory, twice the sample rate
Every MSO1000HD ships 100 Mpts of acquisition memory and samples at 2.5 GSa/s; the DHO900 ships 50 Mpts at 1.25 GSa/s. That is where these two families actually differ.
True 12-bit HD, faster sampling
12-bit native (16-bit with ERES) at 2.5 GSa/s versus the DHO900's 1.25 — more time resolution on the same HD platform.
A portable nine-function instrument
Scope, 16-ch logic (with the UT-M26 pod), spectrum, protocol analyzer, Bode, 4-digit DVM, 7-digit counter and optional power analysis, with a single-channel 25 MHz AWG on the -S models. Type-C/PD-capable at 1.56 kg.
Five-year warranty, US support
Exclusive 3+2 versus Rigol's 3, US stock and support, no subscriptions.
The bottom line
The MSO1000HD and the DHO900 tell the same logic story — channels in the instrument, pod sold separately. They part company on acquisition: 100 Mpts against 50 and 2.5 GSa/s against 1.25, plus five years of warranty against three.
Frequently Asked Questions
Is the UNI-T MSO1000HD Series a good alternative to the Rigol DHO900 Series?
Yes. Both are compact 12-bit HD scopes and both take an optional 16-channel logic pod. The MSO1000HD ships 100 Mpts of memory and samples at 2.5 GSa/s, where the DHO900 ships 50 Mpts at 1.25. The DHO900's edge is a higher UltraAcquire capture rate. Match by bandwidth (MSO1254HD to DHO924).
Is the MSO1254HD a good alternative to the Rigol DHO924?
Yes — same 250 MHz, 4 channels and 12-bit, and the MSO1254HD adds 100 Mpts of memory (vs 50) and 2.5 GSa/s sampling (vs 1.25), plus a 5-year warranty. Logic is a tie: both need an optional pod. The DHO924 lists a little lower.
Does the MSO1000HD include a logic analyzer?
The 16 digital channels are standard hardware on every MSO1000HD, and using them needs the optional UT-M26 logic probe. The DHO900 works the same way with its PLA2216 probe. There is no software licence to buy on the MSO1000HD — the logic-analyzer function is enabled in the instrument.
Are UNI-T software options subscriptions?
No. Every UNI-T software option is a permanent one-time unlock — no annual licenses, no renewal fees and no features that expire.
Ready to choose?
Compact 12-bit HD with twice the memory, twice the sample rate and a 5-year warranty.
Shop the UNI-T MSO1000HD Series →
Sources: UNI-T MSO1000HD Series datasheet (logic pod: p.9, “16-channel logic analyzer (hardware standard) can be used with the purchase of a UT-M26 logic analyzer probe (optional)”) and Rigol DHO900 Series datasheet (rigolna.com). Rigol DHO924 price from authorized US distributor listings, June 2026. UNI-T prices are read live from each product page. Competitor figures last verified 2026-09-03.
Disclaimer: RIGOL® is a registered trademark of RIGOL Technologies, Inc.. UNI-T® is a registered trademark of Uni-Trend Technology (China) Co., Ltd. The comparison provided is based on publicly available information and is intended for informational purposes only. This comparison is not endorsed by, affiliated with, or sponsored by RIGOL Technologies, Inc.. All trademarks, product names, and company names mentioned herein are the property of their respective owners.
