UTS5000A Options

UTS5000A demodulation and analysis packages for 5G NR, FDD-LTE, TDD-LTE, EMI pre-compliance, VSA, I/Q capture, phase noise, AMA analog modulation, AMK advanced measurement, plus the P26 internal preamplifier — ten options covering the UTS5000A 26.5 GHz signal-analyzer capability stack.

View

  • UTS5000A-AMAAM/FM Analog Demodulation Option

    • AM/FM Demodulation: Real-time AM/FM demodulation with configurable carrier frequency.
    • Audio Output: Listen to demodulated signals for quick identification.
    • Modulation Measurements: AM depth and FM deviation measured automatically.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $725.00
    Learn More

  • UTS5000A-AMKAdvanced Measurement Kit Option

    • Channel Power: Total power within a defined channel bandwidth.
    • Occupied Bandwidth: Bandwidth containing 99% of transmitted power.
    • ACPR/ACLR: Adjacent channel power ratio for spectral regrowth evaluation.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,205.00
    Learn More

  • UTS5000A-EMIEMI Pre-Compliance Measurement Option

    • EMI Detectors: Quasi-peak, EMI average, peak, negative peak per CISPR 16.
    • Limit Lines: CISPR 11/22/32, FCC Part 15, EN 55011/55032, MIL-STD-461, VCCI, and more.
    • Automated Scans: Scan-search-measure workflows — peaks identified, quasi-peak measured, results compiled automatically.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,068.00
    Learn More

  • UTS5000A-FDD-LTEFDD-LTE Demodulation Analysis Option

    • FDD-LTE Demodulation: EVM, frequency error, and modulation quality per 3GPP.
    • Channel Measurements: Channel power, ACLR, spectral emission mask.
    • Constellation/EVM: Constellation diagrams and EVM for QPSK, 16QAM, 64QAM.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $6,999.00
    Learn More

  • UTS5000A-I/QI/Q Analyzer Option

    • I/Q Capture: Raw I/Q data capture and processing.
    • Dual-Domain: Time and frequency views simultaneously.
    • Export: Export I/Q data for external analysis.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $1,199.00
    Learn More

  • UTS5000A-NRNR demodulation analysis option for UTS5000A series

    • 5G NR Demodulation: EVM, frequency error, modulation quality.
    • Flexible Numerology: Supports 15, 30, 60, 120 kHz subcarrier spacings.
    • SSB Characterization: Synchronization Signal Block analysis for beam measurements.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $7,299.00
    Learn More

  • UTS5000A-P26Preamplifier Gain Option

    • Preamp to 26.5 GHz: Low-noise gain for improved sensitivity.
    • Improved DANL: Lower noise floor.
    • Switchable: Enable/disable from menu.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $2,315.00
    Learn More

  • UTS5000A-PNMPhase Noise Measurement Option

    • Phase Noise vs. Offset: Single-sideband phase noise from Hz to MHz offsets in one sweep.
    • Auto Carrier Detection: Automatically identifies the carrier frequency.
    • Integrated Phase Noise: Calculates jitter over a specified offset range.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More

  • UTS5000A-TDD-LTETDD-LTE Demodulation Analysis Option

    • TDD-LTE Demodulation: EVM, frequency error, and modulation quality per 3GPP.
    • Channel Measurements: Channel power, ACLR, spectral emission mask.
    • Constellation/EVM: Constellation diagrams and EVM for QPSK, 16QAM, 64QAM.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $6,999.00
    Learn More

  • UTS5000A-VSADigital Demodulation Analysis Option

    • Digital Demodulation: ASK, FSK, PSK, QAM, OFDM with EVM and quality measurements.
    • Constellation Diagram: Visual assessment of modulation quality and impairments.
    • EVM Measurement: Error Vector Magnitude — the standard modulation quality metric.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $999.00
    Learn More
