UPO2000HD Options

UPO2000HD bandwidth upgrade options spanning 70 MHz to 200 MHz, plus the dedicated power analysis package — four upgrade paths for the 12-bit HD scope platform.

View

  • UPO2000HD-BW1MT2MBandwidth Upgrade to 200MHz

    • 100MHz → 200MHz Bandwidth: Upgrades all analog channels on your UPO2102HD.
    • Faster Rise Times: Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
    • No Hardware Changes: Bandwidth is software-defined. Enter the key and operate at 200MHz immediately.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $299.00
    Learn More

  • UPO2000HD-BW7T1MBandwidth Upgrade to 100MHz

    • 70MHz → 100MHz Bandwidth: Upgrades all analog channels on your UPO2072HD.
    • Faster Rise Times: Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
    • No Hardware Changes: Bandwidth is software-defined. Enter the key and operate at 100MHz immediately.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $199.00
    Learn More

  • UPO2000HD-BW7T2MBandwidth Upgrade to 200MHz

    • 70MHz → 200MHz Bandwidth: Upgrades all analog channels on your UPO2072HD.
    • Faster Rise Times: Higher bandwidth means accurately capturing faster edges — critical for signal integrity on high-speed interfaces.
    • No Hardware Changes: Bandwidth is software-defined. Enter the key and operate at 200MHz immediately.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $499.00
    Learn More

  • UPO2000HD-PWRPower Analysis Option for UPO2000HD

    • Switching Loss: Calculates energy per switching transition for MOSFETs, IGBTs. Essential for thermal design and efficiency.
    • Safe Operating Area: Plots V×I trajectories against device limits during transients, startup, and faults.
    • Ripple Analysis: Output ripple amplitude and frequency content. Identifies sources: switching frequency, ESR, load transients.
    • Lifetime License Activation: Activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
    $279.00
    Learn More
